MS-080OR Mouse and MX-080 Dongle User's Manual

1. Battery install

A. Refer below photo(A),Press Button Open and take out the battery box.

B. Put AA battery inside of the battery Box (photoB).

C. Put the battery box inside of the wireless mouse,Red LED indicate the battery be

successfully installed.

Open button

(A)

Dongle(MX-080)

A. Insert the USB receiver into the USB port of PC or Notebook.

B. Receiver's Indicator green LED will light about 3 seconds then off.

C. Press the Link button of the receiver ,Green LED will glitter.

D. Press the link button of the wireless mouse,Green LED of the receiver will glitter

quickly.

E. Link success

★ Remarks: press the link button for 4seconds,mouse will enter into sleep

situation;press the link button be able to wake up the mouse again;This step will

save the battery life.

Mouse working speed be able to adjust by yourself, press the right and left button together for

3seconds,Blue LED of the Scroll wheel flash speed indicate the different solution,slowly flash

indicate 800dpi resolution,quick flash indicate 1600dpi resolution.

(C)

Link

Link button

(B)

Link button

Power switch

Table of Contents

Do you have a question about the MS-080OR and is the answer not in the manual?

Page 1 MS-080OR Mouse and MX-080 Dongle User’s Manual 1. Battery install A. Refer below photo(A),Press Button Open and take out the battery box. B. Put AA battery inside of the battery Box (photoB). C. Put the battery box inside of the wireless mouse,Red LED indicate the battery be successfully installed.
Page 2 Dongle(MX-080) Built-in Refer the below photo,insert the receiver into the slot of the mouse bottom,power will be fully cut off. 5. System Requirements Works with windows 9X/ME/2000/XP/VISTA FCC statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 3 This equipment complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
