Genz Benz GBE 600 Quick Reference Manual

GENERAL SAFTEY INFORMATION
IEC POWER INLET/ FUSE HOLDER — The power is supplied through
an IEC type detachable cord set. The mains fuse holder is located in the
bottom of this socket. The fuse resides in a pull-out drawer along with
storage for an extra fuse.
CAUTIONS:
• Never expose this unit to moisture or rain, or excessive heat
(over 115 degrees F) or without a properly grounded A.C. power
source.
• Never remove the ground pin from the A.C. power connector.
• Never set the GBE 600 on anything that may collapse under its
own weight.
• The GBE 600 is capable of producing sound pressure levels that
may cause permanent hearing loss. Always protect your
ears!!
• There are no user serviceable parts inside these units.
consult a qualified service repair facility for service.
THE HEATSINK IN THE REAR OF THE GBE 600 MAY
BECOME EXTREMELY HOT!!!
TAKE CAUTION!!!
DO NOT TOUCH WHEN HOT!!!
WARRANTY
Genz Benz provides a
Transferable 3 Year Warranty.
Check the enclosed warranty registration card
for more information.
7811 E. Pierce St. Scottsdale, AZ 85257
PH: 480-941-0705 FAX: 480-946-2412
www.genzbenz.com
A Kaman Music Company, Bloomfield, CT

QUICK REFERENCE

Always
IMPORTANT FEATURES:
• FET/12AX7 Tube Preamps— can be Switched or Mixed
together via Footswitch (Footswitch included)
• 3 Circuit Shape Network (Footswitchable—F/S optional)
LF Extend, Mid Scoop, HF Attack—All adjustable Min-Max.
• 5 Band Active EQ with 2 shelving controls and 3 peaking
• High Powered Robust Output
• XLR Direct Out w/ Level Control, Pre/Post/Ground Lift Sw.
• High Velocity Heat Management w/ 2 Speed Fan
• Speakon® and Standard 1/4" Speaker Outputs
• Unique "Soft Limit" Circuitry—Simulates Output Saturation for
Warmer Limiting Action
MANUAL
275 Watts @ 8 ohms
425 Watts @ 4 ohms
625 Watts @ 2 ohms
