SE7261A DSP Subwoofer Operating Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE7261A and is the answer not in the manual?

Questions and answers

Related Manuals for Genelec SE7261A

Summary of Contents for Genelec SE7261A

  • Page 1 SE7261A DSP Subwoofer Operating Manual...

  • Page 3: Ec Declaration Of Conformity

    Use with the GLM.SE™ network is described in the GLM.SE™ System Operating Manual. EC Declaration Of Conformity This is to certify that Genelec SE7261A DSP Subwoofer conforms to the following standards: Safety: EN 60065: 2002 / IEC 60065:2001 7th Edition...

  • Page 4: Installation

    GLM.SE™ Genelec Loudspeaker Manager kit. Installation The SE7261A is supplied with a mains cable, one 5 m GLM control network cable and this operating manual. Once unpacked, place the subwoofer in a suitable location (for more details see the "Positioning"...
  • Page 5 The mains cable may only be connected to an earthed mains power supply. The “BYPASS” 1/4” Jack provides connection to the optional Genelec 1092-400 switch to operate the Bypass function. See “SE7261A Subwoofer Features” for description of this function.
  • Page 6 This leaves sufficient 7,5 centimeters (") of free space on the reflex port side. The height and depth of the recess should not be any bigger than those needed to fit the subwoofer flush with the wall surface. SE7261A Subwoofer Features Various controls and switches are accessible on the connector panel.
  • Page 7 When producing an audio format that does not require the use of +10 dB gain on the LFE channel, such as DVD-Audio (MLP) and SACD (DSD). Bypass The “BYPASS” section allows the use of an optional Genelec 1092-400 remote bypass switch. This allows for remote control Selection Switch setting...

  • Page 8: Test Tone

    -12 dB -14 dB Test Tone: The SE7261A subwoofer contains a tone generator for phase alignment. The “TEST TONE” switch activates the tone generator at the crossover frequency. The test tone signal is sent to OUTPUT 1 on AES/EBU subframe A. To perform an adjustment one main loudspeaker has to be connected to this channel and set to reproduce this signal with the subwoofer.

  • Page 9: Maintenance

    Any maintenance or repair of the loudspeaker should be undertaken by qualified service personnel only. Safety considerations Although the SE7261A has been designed in accordance with international safety standards, to ensure safe operation and to maintain the subwoofer under safe operating conditions, the following warnings and cautions must be observed: 1.
  • Page 10 85 dB, which may cause permanent hearing damage. Guarantee Genelec SE7261A subwoofer is supplied with a two year guarantee against manufacturing faults or defects that might alter the performance of the subwoofer. Refer to supplier for full sales and guarantee terms.

  • Page 11: System Specifications

    SySTEM SPECIFICATIONS SE7261A Free field frequency response 19 Hz - 100 Hz (± .0 dB) Maximum short term sine ≥ 108 dB SPL wave SPL output averaged from 0 to 85 Hz, measured in half space at 1 meter ≥ 11 dB SPL...
  • Page 12 Designed to Adapt Genelec Document D0082R002. Copyright Genelec Oy 12.2007. All data subject to change 750-SE7261A...
