www.lg.com
*MFL71458522*
(2002-REV00)
OLED65GX*
AA
Head
Head
1
washer
2
3
washer
Head
washer
Head
washer
1
2
1
2
3

Advertisement

Table of Contents
loading

Related Manuals for LG OLED65GX Series

Summary of Contents for LG OLED65GX Series

  • Page 1 *MFL71458522* (2002-REV00) OLED65GX* Head Head washer washer Head washer Head washer...
  • Page 2 90° (mm) (kg) 90° OLED65GXPPA 1446 19.9 29.0 Power requirement AC 100-240 V ~ 50 / 60 Hz...
  • Page 3 OWNER’S MANUAL Safety and Reference Please read this manual carefully before operating your set and retain it for future reference. *MFL71689222* www.lg.com Copyright © 2020 LG Electronics Inc. All Rights Reserved. (2002-REV00)
  • Page 4 Warning! Safety • Ventilation - Install your TV where there is proper ventilation. Do not install in Instructions a confined space such as a bookcase. - Do not install the product on a carpet or cushion. - Do not block or cover the product with cloth or other materials while unit is plugged in.
  • Page 5 • Use only an authorized attachments / accessories approved by LG Electronics. Otherwise, this may result in fire, electric shock, malfunction, or product damage. • Never disassemble the AC adapter or power cord. This may result in fire or electric shock.

  • Page 6: Separate Purchase

    Preparing Separate Purchase Separate purchase items can be changed or modified for quality • If the TV is turned on for the first time after it was shipped from the improvement without any notification. Contact your dealer to buy these factory, initialization of the TV may take a few minutes.

  • Page 7: Wall Mounting Bracket

    Wall Mounting Bracket • Hold the side and bottom of the TV frame firmly. Make sure not to hold the transparent part, speaker, or speaker grill area. (Depending on model) Make sure to use screws and wall mount bracket that meet the VESA standard.
  • Page 8 Mounting on the Table • If a television is not positioned in a sufficiently stable location, it can be potentially hazardous due to falling. Many injuries, particularly to children, can be avoided 1 Lift and tilt the TV into its upright position on a table. by taking simple precautions such as: •...

  • Page 9: Mounting To The Wall

    We recommend the use (Except for OLW480B) of LG’s wall mount bracket. LG’s wall mount bracket is easy to move with cables connected. When you do not use LG’s wall mount bracket, please • Professional installers should read this manual carefully to ensure use a wall mount bracket where the device is adequately secured to the proper installation.

  • Page 10: Before Installation

    LG is not responsible for problems caused by improper installation unstable installation and potential safety issues. of the product, e.g., heavily tilted walls and ceilings.
  • Page 11 Securing TV to the Wall 1 Drill holes in anchor locations with a drill bit of Ø 8 mm to a depth of 80 mm to 100 mm. (Except for OLW480B) 2 Clean the drilled holes. • Please use the TV close to the wall after installation. How to fix anchors and screws 3 Insert the enclosed anchors for fixing the wall mount into the (Except for OLW480B)

  • Page 12: After Installation

    Connections After Installation •  When connecting additional cables from the sides, we Connect various external devices to the TV and switch input modes to recommend holding the centre of the TV horizontally or select an external device. For more information of external device’s vertically and pulling the product to make sure there is connection, refer to the manual provided with each device.
  • Page 13 External Devices •  [Picture] [Additional Settings] [HDMI ULTRA HD Deep Color] Available external devices are: Blu-ray player, HD receivers, DVD players, - On : Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0), VCRs, audio systems, USB storage devices, PC, gaming devices, and 4K @ 100/120 Hz (4:4:4, 4:2:2, 4:2:0) other external devices.

  • Page 14: Using Button

    Using Button You can simply operate the TV functions, using the button. Basic functions Power On (Press) Power Off (Press and Hold) Menu Control (Press Menu Selection (Press and Hold 1 All running apps will close, and any recording in progress will stop. (Depending on country) 2 You can access and adjust the menu by pressing the button when TV is on.
  • Page 15 Using Magic Remote ** To use the button, press and hold for more than 1 second. Control (POWER) Turns the TV on or off. (STB POWER) You can turn your set-top box on or off by adding the set-top box to the universal remote control for your TV. (Depending on model) Number buttons Enters numbers.

  • Page 16: Troubleshooting

    Troubleshooting Registering Magic Remote Control How to register the Magic Remote Control Cannot control the TV with the remote control. • Check the remote control sensor on the product and try again. To use the Magic Remote, first pair it with your TV. •...
  • Page 17 Generated Sound • “Cracking” noise: A cracking noise that occurs when watching or turning off the TV is generated by plastic thermal contraction due to temperature and humidity. This noise is common for products where thermal deformation is required. • Electrical circuit humming/panel buzzing: A low level noise is generated from a high-speed switching circuit, which supplies a large amount of current to operate a product.

  • Page 18: Specifications

    Specifications Broadcasting Specifications Digital TV Analogue TV Television system ISDB-T NTSC-M Program coverage VHF, UHF, CATV Maximum number of storable programs ISDB-T & Analogue TV : 3,000 External antenna impedance 75 Ω Wireless module(LGSBWAC94)Specifications Wireless LAN (IEEE 802.11a/b/g/n/ac) Frequency range Output power(Max.) 2,400 to 2,483.5 MHz 17.5 dBm...

  • Page 19: Open Source Software Notice Information

    In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
  • Page 20 → → [Picture] → [Picture Mode Settings] → static image on the screen for a long time. LG OLED TVs incorporate [Picture Mode] → [APS] dedicated functions that protect the screen from possible image →...
  • Page 21 Regulatory WARNING! Never place a television set in an unstable location. A television set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided by taking simple precautions such as: • Using cabinets or stands recommended by the manufacturer of the television set.
  • Page 22 The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
