SYSTEM SPECIFICATIONS
Lower cut-off frequency, –3 dB:
Upper cut-off frequency, –3 dB:
Free field frequency response of system:
Maximum short term sine wave acoustic output on axis
in half space, averaged from 100 Hz to 3 kHz:
Maximum long term RMS acoustic output in same
conditions with IEC weighted noise (limited by driver
unit protection circuit):
Maximum peak acoustic output per pair on top of
console, @ 1 m from the engineer with music material:
Self generated noise level in free field @ 1m on axis:
Harmonic distortion at 85 dB SPL @ 1m on axis:
Freq:
Drivers: Bass
Treble
Weight:
Dimensions: Height
(including Iso-Pod™ table stand)
Height
(without Iso-Pod™ table stand)
Width
Depth

EC Declaration of Conformity

This is to certify that the Genelec Monitoring System
8020A conforms to the following standards:
Safety:
EN 60065: 2002 / IEC 60065:2001 7th Edition
EMC:
EN 55020 : 2002 + A1 : 2003
EN 55013: (2001)
EN 61000-3-2 (2000)
EN 61000-3-3 (1995)
The product herewith complies with the requirements of
The Low Voltage Directive73/23/EEC, EMC Directive
89/336/EEC and 93/68/EEC
Signed:
Ilpo Martikainen Ilpo Martikainen
Position: Managing Director
Date: 4-May-2005
< 65 Hz
> 21 kHz
66 Hz – 20 kHz (± 2.5 dB)
@ 1 m > 96 dB SPL
@ 0.5 m > 102 dB SPL
@ 1 m > 95 dB SPL
> 105 dB
< 10 dB (A-weighted)
50...100 Hz < 3 %
> 100 Hz < 0.5 %
105 mm (4") cone
19 mm ( / ") metal dome
3
4
Both drivers are
magnetically shielded
3.7 kg (8.1 lb)
242 mm (9 / ")
1
2
230 mm (9 / ")
1
16
151 mm (6")
142 mm (5 / ")
5
8
CROSSOVER SECTION
Connectors:
Input: XLR female, balanced 10 kOhm,
pin 1 gnd, pin 2 +, pin 3 -
Output: XLR male, balanced 100 Ohm
Pin 1 gnd, pin 2 +, pin 3 -
Input level for 100 dB SPL output at 1 m:
-6 dBu at volume control max
Volume control range:
-80 dB relative to max output
Output signal level is 0 dB relative to input signal level
but adjustable by volume control
Crossover frequency, Bass/Treble:
Treble tilt control operating range:
0 to –2 dB @ 15 kHz
Bass roll-off control operating in a –6 dB step @ 85 Hz
(to be used in conjunction with a 7050B subwoofer)
Bass tilt control operating range in –2 dB steps:
0 to –6 dB @ 100 Hz
The 'CAL' position is with all tone controls set to 'off ' and
the input sensitivity control to maximum (fully
clockwise).
AMPLIFIER SECTION
Bass amplifier output power with an 8 Ohm load:
Treble amplifier output power with an 8 Ohm load: 20 W
Long term output power is limited by driver unit
protection circuitry.
Amplifier system distortion at nominal output:
THD
SMPTE-IM
CCIF-IM
DIM 100
Signal to Noise ratio, referred to full output:
Bass
Treble
Mains voltage:
100, 120, 220 or 230 V
according to region
Voltage operating range:
Power consumption:
3.0 kHz
20 W
< 0.08 %
< 0.08 %
< 0.08 %
< 0.08 %
> 95 dB
> 95 dB
±10 %
Idle 5 VA
Full output 50 VA
