- Page 1 WD8704EJ(A/F/G/H/S/V/W/Z) WD8702EJ(A/F/G/H/S/V/W/Z) WD8704RJ(A/F/G/H/S/V/W/Z) WD8702RJ(A/F/G/H/S/V/W/Z) WD8704CJ(A/F/G/H/S/V/W/Z) WD8702CJ(A/F/G/H/S/V/W/Z) WD8704DJ(A/F/G/H/S/V/W/Z) WD8702DJ(A/F/G/H/S/V/W/Z) Washing Machine user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive a more complete service, please register your product at www.samsung.com/register WD8704EJ-02719A_EN.indd 1 2009-10-20 ø¿¿¸ 11:08:02...
- Page 2 Your new washing machine will change the way you feel about doing laundry. From its super-size capacity to its energy efficiency, the Samsung washing machine has all the features to turn a mundane chore into a pleasure. • Washing to drying with one button Enjoy convenient non stop washing and drying.
- Page 3 This manual contains important information on the installation, use, and care of your new Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how to use the washing machine, and tips for making the most of its state-of-the-art features and functions.
- Page 4 It’s your responsibility to use common sense, caution, and care when installing, maintaining, and operating your washing machine. Samsung is not liable for damages resulting from improper use. IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS...
- Page 5 If this appliance is supplied from a cord extension set or electrical portable outlet device, the cord extension set or electrical portable outlet device must be positioned so that it is not subject to splashing or ingress of moisture. safety information _5 WD8704EJ-02719A_EN.indd 5 2009-10-20 ø¿¿¸ 11:08:03...
- Page 6 For washing machines with ventilation openings in the base, ensure that the opening is not obstructed by carpet or any other obstacles. Use the new hose-sets and old hose-sets should not be reused. 6_ safety information WD8704EJ-02719A_EN.indd 6 2009-10-20 ø¿¿¸ 11:08:04...
- Page 7 - this will reduce, but not eliminate, the hazard. Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated. CAUTION safety information _7 WD8704EJ-02719A_EN.indd 7 2009-10-20 ø¿¿¸ 11:08:04...
-
Page 8: Table Of Contents
Repairing a frozen washing machine Storing your washing machine TROUBLESHOOTING AND Check these points if your washing machine... INFORMATION CODES Information codes CYCLE CHART Cycle chart APPENDIX Fabric care chart Protecting the environment Declaration of conformity 8_ contents WD8704EJ-02719A_EN.indd 8 2009-10-20 ø¿¿¸ 11:08:04... -
Page 9: Setting Up Your Washing Machine
Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact Samsung Customer Service or your Samsung dealer. Release lever... -
Page 10: Meeting Installation Requirements
• Periodically checking for leaks at water inlet hose fittings. Before using your washing machine for the first time, check all connections at the water valve and taps for leaks. WARNING 10_ setting up your new washing machine WD8704EJ-02719A_EN.indd 10 2009-10-20 ø¿¿¸ 11:08:05... -
Page 11: Drain
Drain Samsung recommends a standpipe height of 18 in (46 cm). The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory. - Page 12 4. Store the shipping bolts away safely in case you have to move the washing machine in the future. Packaging materials can be dangerous to children; keep all packaging material (plastic bags, polystyrene, etc.) well out of the reach of children. WARNING 12_ setting up your new washing machine WD8704EJ-02719A_EN.indd 12 2009-10-20 ø¿¿¸ 11:08:05...
- Page 13 2. Connect the other end of the hot water supply hose to your sink’s hot water tap and tighten it by hand. 3. Use a Y-piece if you only want to use cold water. setting up your new washing machine _13 WD8704EJ-02719A_EN.indd 13 2009-10-20 ø¿¿¸ 11:08:06...
- Page 14 5. Connect the other end of the water supply hose to the inlet water valve at the rear of the washing machine. Screw the hose clockwise all the way in. 14_ setting up your new washing machine WD8704EJ-02719A_EN.indd 14 2009-10-20 ø¿¿¸ 11:08:07...
- Page 15 Use the most conventional type of tap for the water supply. In case the tap is square or too big, remove the spacing ring before inserting the tap into the adaptor. setting up your new washing machine _15 WD8704EJ-02719A_EN.indd 15 2009-10-20 ø¿¿¸ 11:08:07...
-
Page 16: Environment
10.) ENVIRONMENT Please dispose of the packaging materials for this product in an “environmentally friendly” manner. For further detail, please contact your local area authority. 16_ setting up your new washing machine WD8704EJ-02719A_EN.indd 16 2009-10-20 ø¿¿¸ 11:08:08... -
Page 17: Washing A Load Of Laundry
With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash first. WASHING FOR THE FIRST TIME Before washing laundry for the first time, you must run a complete empty cycle (i.e. no laundry). -
Page 18: Using The Control Panel
Water Saving - This is a specially designed course that enables you to wash laundry effectively with the minimum amount of water. Water Saving, 40˚C, Intensive Wash/Dry, 3 rinses, 1400rpm spin is recommended for a normally soiled cotton load. 18_ washing a load of laundry WD8704EJ-02719A_EN.indd 18 2009-10-20 ø¿¿¸ 11:08:10... - Page 19 • The drying conditions may differ depending on the type and the amount of laundry. washing a load of laundry _19 WD8704EJ-02719A_EN.indd 19 2009-10-20 ø¿¿¸ 11:08:11...
- Page 20 Press it once to turn your washing machine on, press it again to turn your POWER BUTTON washing machine off. If the washing machine is left on for more than 10 minutes without any buttons being touched, the power automatically turns off. 20_ washing a load of laundry WD8704EJ-02719A_EN.indd 20 2009-10-20 ø¿¿¸ 11:08:11...
-
Page 21: Child Lock
2. Turn the Cycle Selector to the Spin positio. 3. Press the Spin button 1 times until rpm sign is off. 4. Then “1” shows up on time display in center. 5. Press the Start/Pause button. washing a load of laundry _21 WD8704EJ-02719A_EN.indd 21 2009-10-20 ø¿¿¸ 11:08:12... -
Page 22: Air Refresh
• Hard bedding such as a wooden pillows (neck-rest) - Pillows or blankets filled with plastic or starch rather than cotton - Electric blankets • Furry blankets • Bulky blankets • Latex pillow 22_ washing a load of laundry WD8704EJ-02719A_EN.indd 22 2009-10-20 ø¿¿¸ 11:08:13... -
Page 23: Drying
2. Press Drying button until Time Dry option illuminates 3. Continue to press Drying button until the drying 4.0kg 287min. Time Drying ( time you require is illuminated 4. Press the Start/Pause button washing a load of laundry _23 WD8704EJ-02719A_EN.indd 23 2009-10-20 ø¿¿¸ 11:08:14... - Page 24 firstly Start/Pause or Power button and take them out. • In case you wish to dry after hand washing, select both Spin and Dry at the same time. 24_ washing a load of laundry WD8704EJ-02719A_EN.indd 24 2009-10-20 ø¿¿¸ 11:08:14...
-
Page 25: Washing Clothes Using The Cycle Selector
Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed. 1. Turn on your sink’s water tap. -
Page 26: Laundry Guidelines
If the laundry is unbalanced, the spin efficiency may be degraded. • When washing Bedding or Duvets, the wash time may be lengthened or the spin efficiency may be degraded. 26_ washing a load of laundry WD8704EJ-02719A_EN.indd 26 2009-10-20 ø¿¿¸ 11:08:14... -
Page 27: Detergent And Additives Information
• Detergents using a ball and net Concentrated or thick fabric softener and conditioner must be diluted with a little water before being poured into the dispenser (prevents the overflow from becoming blocked.) washing a load of laundry _27 WD8704EJ-02719A_EN.indd 27 2009-10-20 ø¿¿¸ 11:08:15... -
Page 28: Cleaning And Maintaining Your Washing Machine
1. Wipe the washing machine surfaces, including the control panel, with a soft cloth using a nonabrasive household detergent. 2. Use a soft cloth to dry the surfaces. 3. Do not pour water onto the washing machine. 28_ cleaning and maintaining your washing machine WD8704EJ-02719A_EN.indd 28 2009-10-20 ø¿¿¸ 11:08:15... -
Page 29: Cleaning The Detergent Drawer And Drawer Recess
4. Wash any dirt or other material from the debris filter. Make sure the drain pump propeller behind the debris filter is not blocked. 5. Replace the debris filter cap. 6. Replace the filter cover. cleaning and maintaining your washing machine _29 WD8704EJ-02719A_EN.indd 29 2009-10-20 ø¿¿¸ 11:08:16... -
Page 30: Cleaning The Water Hose Mesh Filter
If your washing machine has been stored in below-freezing temperatures, allow time for any leftover water in your washing machine to thaw out before using it. 30_ cleaning and maintaining your washing machine WD8704EJ-02719A_EN.indd 30 2009-10-20 ø¿¿¸ 11:08:17... -
Page 31: Troubleshooting And Information Codes
Door is locked shut or will The door will not open until 3 minutes after the machine stops or the not open. power turns off. If the problem persists, contact your local Samsung Customer Service. troubleshooting and information codes _31 WD8704EJ-02719A_EN.indd 31 2009-10-20 ø¿¿¸ 11:08:17... - Page 32 The fan will automatically function, so just wait until “Hot” indication disappeared. For any codes not listed above, or if the suggested solution doesn’t fix the problem, call your Samsung Service Centre or local Samsung dealer. 32_ troubleshooting and information codes WD8704EJ-02719A_EN.indd 32...
- Page 33 3. Course time in individual homes may differ from the values given in the table due to variations in the pressure and temperature of the water supply, the load and the type of laundry. 4. When the Intensive Wash function is selected, the cycle time is increased for each cycle. cycle chart _33 WD8704EJ-02719A_EN.indd 33 2009-10-20 ø¿¿¸ 11:08:17...
-
Page 34: Appendix
Save water and electricity by only washing full loads (the exact amount depends upon the program used). DECLARATION OF CONFORMITY This appliance complies with European safety standards, EC directive 93/68 and EN Standard 60335. 34_ appendix WD8704EJ-02719A_EN.indd 34 2009-10-20 ø¿¿¸ 11:08:18... - Page 35 2.5 kg WD8704CJ/ WD8702CJ/ WD8704DJ/ WD8702DJ/ MODEL WD8704EJ/ WD8702EJ/ SPIN REVOLUTIONS WD8704RJ WD8702RJ 1400 1200 The appearance and specifications of the product are subject to change without prior notice for purposes of product enhancement. appendix _35 WD8704EJ-02719A_EN.indd 35 2009-10-20 ø¿¿¸ 11:08:18...
