Page 1
WD8754RJ(A/F/G/H/S/V/W/Z) WD8752RJ(A/F/G/H/S/V/W/Z) WD8754CJ(A/F/G/H/S/V/W/Z) WD8752CJ(A/F/G/H/S/V/W/Z) WD8754DJ(A/F/G/H/S/V/W/Z) WD8752DJ(A/F/G/H/S/V/W/Z) Washing Machine user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive a more complete service, please register your product at www.samsung.com/register WD8754RJF-02713L_EN.indd 1 WD8754RJF-02713L_EN.indd 1 2011-02-11 2011-02-11 6:00:26 6:00:26...
Page 2
Your new washing machine will change the way you feel about doing laundry. From its super-size capacity to its energy effi ciency, the Samsung washing machine has all the features to turn a mundane chore into a pleasure.
Page 3
This manual contains important information on the installation, use, and care of your new Samsung washing machine. Refer to it for descriptions of the control panel, instructions on how to use the washing machine, and tips for making the most of its state-of-the-art features and functions.
Congratulations on your new Samsung washer. This manual contains important information on the installation, use and care of your appliance. Please take time to read this manual to take full advantage of your washer’s many benefi ts and features.
Page 5
Do not let children (or pets) play on or in your washing machine. The washing machine door does not open easily from the inside, and children may be seriously injured if trapped inside. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or WARNING instruction concerning use of the appliance by a person responsible for their safety.
Page 6
safety information SEVERE WARNING SIGNS FOR INSTALLATION WARNING The installation of this appliance must be performed by a qualifi ed technician or service company. - Failure to do so may result in electric shock, fi re, an explosion, problems with the product, or injury.
Page 7
Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance. - This may result in electric shock or fi re. Do not pull the power cord, when unplugging the power plug.
Page 8
safety information Do not wash items contaminated with gasoline, kerosene, benzene, paint thinner, alcohol or other fl ammable or explosive substances. - This may result in electric shock, fi re or an explosion. Do not open the washer door by force while it is operating (high-temperature washing/ drying/spinning).
Page 9
CAUTION SIGNS FOR USING CAUTION When the washer is contaminated by a foreign substance such as detergent, dirt, food waste, etc., unplug the power plug and clean the washer using a damp and soft cloth. - Failure to do so may result in discoloration, deformation, damage or rust. The front glass may be broken by a strong impact.
Page 10
safety information Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. - This may result in electric shock, fi re, problems with the product, or injury. Do not spray volatile material such as insecticide onto the surface of the appliance.
Page 11
Do not use natural hand-washing soap for the washer. - If it hardens and accumulates inside the washer, it may result in problems with the product, discoloration, rust or bad odors. Do not wash large laundry items such as bedding in the washing net. - Place socks and brassieres into the washing net and wash them with the other laundry.
contents SETTING UP YOUR WASHING Checking the parts MACHINE Meeting installation requirements Electrical supply and grounding Water Supply Drain Flooring Surrounding temperature Alcove or closet installation Installing your washing machine WASHING A LOAD OF LAUNDRY Washing for the fi rst time Basic instructions Using the control panel Child lock...
Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact Samsung Customer Service or your Samsung dealer. Release lever...
setting up your washing machine MEETING INSTALLATION REQUIREMENTS Electrical supply and grounding To prevent unnecessary risk of fi re, electrical shock, or personal injury, all wiring and grounding must be done in accordance with the National Electrical Code ANSI/FNPA, No. 70 Latest Revision and local codes and ordinances.
Drain Samsung recommends a standpipe height of 65 cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory.
Page 16
setting up your washing machine STEP 2 Removing the shipping bolts Before installing the washing machine, you must remove all shipping bolts from the back of the unit. 1. Loosen all the bolts with the supplied wrench. 2. Hold the bolt with the spanner and pull it through the wide section of the hole.
STEP 3 Adjusting the levelling feet When installing your washing machine, ensure that the power plug, the water supply and the drain are easily accessible. 1. Slide the washing machine into position. 2. Level your washing machine by turning the leveling feet in and out as necessary by hand.
Page 18
setting up your washing machine Connecting the water supply hose (selected models) 1. Remove the adaptor from the water supply hose. Adaptor Water supply hose 2. First, using a ‘+’ type screwdriver, loosen the four screws on the adaptor. Next, take the adaptor and turn part (2) following the arrow until there is a 5 mm gap.
Page 19
✗ 6. Turn on the water supply and ensure that no water leaks from the water valve, tap or adaptor. If there is a water leaks, repeat the previous steps. Do not use your washing machine if there is a water ✗...
setting up your washing machine Connecting the drain hose The end of the drain hose can be positioned in three ways: 1. Over the edge of a wash basin: The drain hose must be placed at a height of between 60 and 90 cm.
With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash fi rst. WASHING FOR THE FIRST TIME Before washing laundry for the fi rst time, you must run a complete empty cycle (i.e. no laundry).
washing a load of laundry USING THE CONTROL PANEL DIGITAL GRAPHIC Displays the remaining wash cycle time, all cycle information, and error DISPLAY messages. Select the tumble pattern and spin speed for the cycle. For detailed information, refer to “Washing clothes using the cycle selector”.
Page 23
Quick 29’ - Washes laundry in 29 minutes. For lightly soiled garments. Spin - Performs an additional spin cycle to remove more water. Rinse + Spin - Use for a load that needs rinsing only or to add rinse- added fabric softener to a load. Drain Only - Turn the Cycle Selector to the Spin position, press the Spin button, and then press the Start/Pause button to drain the water.
Page 24
washing a load of laundry Press this button when the laundry is heavily soiled and needs to be INTENSIVE WASH washed intensively. The cycle time is increased for each cycle. / DRY SELECTION Turn the Cycle Selector to the Drying position and press this button to BUTTON use the 4 kg high-capacity drying function.
Child lock The Child Lock function allows you to lock the buttons so that the wash cycle you’ve chosen can’t be changed. Activating/Deactivating If you want to activate or deactivate the Child Lock function, press the Temp. and Rinse buttons at the same time for 3 seconds.
washing a load of laundry Air Wash The Air Wash system deodorizes and sterilizes fabrics without getting them wet, opening up cleaning options for many non washable items. The sterilization function also kills the common household dust mite, offering relief for allergy sufferers. •...
DRYING Refer to the label of drying capacity and be sure to put in the clothes to the lower level than the marked line for the dried clothe of 4.0kg. 1. Open the door, put in the clothes and close the door again. 2.
Page 28
washing a load of laundry Wash + Dry This is the cycle time for drying only, please refer to page 37 for the cycle wash time. Drying Time Drying Type Information Load (Max Load) 1. Place suitable amount of detergent and fabric softener in the detergent tray and close it again.
Washing clothes using the cycle selector Your new washing machine makes washing clothes easy, using Samsung’s “Fuzzy Control” automatic control system. When you select a wash program, the machine will set the correct temperature, washing time, and washing speed. 1. Turn on your sink’s water tap.
washing a load of laundry LAUNDRY GUIDELINES Follow these simple guidelines for the cleanest laundry and the most effi cient wash. Always check the Care label on clothing before washing. Sort and wash your laundry according to the following criteria: •...
DETERGENT AND ADDITIVES INFORMATION Which detergent to use The type of detergent you should use is based on the type of fabric (cotton, synthetic, delicate items, wool), colour, wash temperature, and degree of soiling. Always use “low suds” laundry detergent, which is designed for front load washing machines. Follow the detergent manufacturer’s recommendations based on the weight of the laundry, the degree of soiling, and the hardness of the water in your area.
cleaning and maintaining your washing machine Keeping your washing machine clean improves its performance, wards off unnecessary repairs, and lengthens its life. DRAINING THE WASHING MACHINE IN AN EMERGENCY 1. Unplug the washing machine from the power supply. 2. Open the fi lter cover using a coin or a key. Filter cover 3.
CLEANING THE DETERGENT DRAWER AND DRAWER RECESS 1. Press the release lever on the inside of the Release lever detergent drawer and pull the drawer out. Liquid detergent divider 2. Remove the liquid detergent divider from the detergent drawer 3. Wash all parts under running water. 4.
cleaning and maintaining your washing machine CLEANING THE WATER HOSE MESH FILTER You should clean the water hose mesh fi lter at least once a year, or when the error message of “4E” is displayed: 1. Turn off the water supply to the washing machine. 2.
• The door will not open until 3 minutes after the machine stops or the not open. power turns off. If the problem persists, contact your local Samsung Customer Service. troubleshooting and information codes _35 WD8754RJF-02713L_EN.indd Sec8:35 WD8754RJF-02713L_EN.indd Sec8:35 2011-02-11...
Page 36
The fan will automatically function, so just wait until “Hot” indication disappeared. For any codes not listed above, or if the suggested solution doesn’t fi x the problem, call your Samsung Service Centre or local Samsung dealer. 36_ troubleshooting and information codes WD8754RJF-02713L_EN.indd Sec8:36...
appendix FABRIC CARE CHART The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing, and dry cleaning when necessary. The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow the care label directions to maximize garment life and reduce laundering problems.
SPECIFICATIONS TYPE FRONT LOADING WASHING MACHINE WD8754CJ/WD8754DJ/WD8754EJ/WD8754RJ WD8752CJ/WD8752DJ/WD8752EJ/WD8752RJ DIMENSIONS W598mm X D600mm X H844mm WATER PRESSURE 50 kPa ~ 800 kPa WATER VOLUME ℓ WD8754CJ/ WD8752CJ/ WD8754DJ/ WD8752DJ/ WD8754EJ/ WD8752EJ/ NET WEIGHT WD8754RJ WD8752RJ 70 kg 69 kg WASH AND SPIN CAPACITY 7.5 kg [DRY LAUNDRY] DRY CAPACITY 4.0 kg...
Page 40
QUESTIONS OR COMMENTS? Country CALL OR VISIT US ONLINE AT Saudi Arabia 9200-21230 www.samsung.com Code No. DC68-02713L_EN WD8754RJF-02713L_EN.indd Sec9:40 WD8754RJF-02713L_EN.indd Sec9:40 2011-02-11 2011-02-11 6:01:35 6:01:35...
