Simpson Megashot MS61039 50-State Instruction Manual page 14

NOZZLE COLOR SPRAY PATTERN USES
Red
(if equipped)
Yellow
(if equipped)
Green
(if equipped)
White
(if equipped)
Black
(if equipped)
*NOTICE: The high pressure spray from your pressure washer is capable of
causing damage to surfaces such as wood, glass, automobile paint, auto striping
and trim, and delicate objects such as flowers and shrubs. Before spraying,
check the item to be cleaned to assure yourself that it is strong enough to resist
damage from the force of the spray.
HOW TO APPLY CHEMICALS/CLEANING SOLVENTS (FIG. 9)
Applying chemicals or cleaning solvents is a low pressure operation. NOTE: Use
only soaps and chemicals designed for pressure washer use. Do not use bleach.
9
To Apply Chemicals (Siphon Hose, if equipped):
1. Ensure detergent siphon hose (F, Figure 9) is attached to barbed fitting location
near high pressure hose connection of pump as shown.
2. Place other end of detergent siphon hose with filter on it into container holding
chemical/cleaning solution. NOTE: For every 7 gallons of water pumped 1
gallon of chemical/cleaning solution will be used.
0˚
15˚
25˚
40˚
low pressure
F
powerful pinpoint
for spot cleaning
of hard, unpainted
surfaces or for
high reach areas
intense cleaning
of unpainted
hard surfaces
intense cleaning of
larger areas
cleaning of
painted or delicate
surfaces
applies cleaning
solutions
OR
14- ENG
SURFACES*
unpainted metal
or concrete;
DO NOT use on wood
grills, driveways,
concrete or brick
walkways, unpainted
brick or stucco
metal, concrete or wood
auto/RV, marine,
wood, painted brick
and stucco, vinyl,
painted siding
Low pressure
spray is safe on all
surfaces. Always verify
compatibility of cleaning
solution prior to use.
F
