PRESSURE WASHER
INSTRUCTION
MANUAL
MANUEL
D'UTILISATION
MANUAL DE
INSTRUCCIONES
If your pressure washer is not working properly or if there are parts missing or broken,
please DO NOT RETURN IT TO THE PLACE OF PURCHASE. Contact our Customer
Service Department at 1-877-362-4271 or www.simpsoncleaning.com
Si votre rondelle de pression ne travaille pas convenablement ou s'il y a des
parties manquant ou cassé, s'il vous plaît le PAS LE RETOURNE AU LIEU
D'ACHAT. Contacter notre département de service clients à
www.simpsoncleaning.com
Si su lavadora a presión no trabaja correctamente ó encuentra partes rotas
ófaltantes, por favor NO LA REGRECE AL LUGAR DONDE LA COMPRO.
Contáctese con nuestro Departamento de Servicio al Cliente llamando al
1-877-362-4271 ou www.simpsoncleaning.com
IMPORTANT: Please make certain that the person who is to use this equipment carefully
reads and understands these instructions before operating.
IMPORTANT  : Assurez-vous que toute personne qui utilisera cet équipement lise
attentivement ces instructions avant de l'utiliser.
IMPORTANTE: Aségurese por favor de que la persona que vaya a utilizar este equipo lea
con cuidado y comprenda estas instrucciones antes de operar.
VEA EL ESPAÑOL EN LA CONTRAPORTADA. INSTRUCTIVO DE OPERACIÓN,
CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA. ADVERTENCIA:
LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
SAVE THIS MANUAL FOR FUTURE REFERENCE
CONSERVE ESTAS INSTRUCCIONES PARA FUTURAS CONSULTAS
Part No. 7111550 Rev. 0
LISEZ ET CONSERVEZ CES INSTRUCTIONS
NOV2018
1-877-362-4271 o

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Megashot MS61039 50-State and is the answer not in the manual?

Questions and answers

Related Manuals for Simpson Megashot MS61039 50-State

Summary of Contents for Simpson Megashot MS61039 50-State

  • Page 1 PRESSURE WASHER INSTRUCTION MANUAL MANUEL D’UTILISATION MANUAL DE INSTRUCCIONES If your pressure washer is not working properly or if there are parts missing or broken, please DO NOT RETURN IT TO THE PLACE OF PURCHASE. Contact our Customer Service Department at 1-877-362-4271 or www.simpsoncleaning.com Si votre rondelle de pression ne travaille pas convenablement ou s'il y a des parties manquant ou cassé, s'il vous plaît le PAS LE RETOURNE AU LIEU D'ACHAT.

  • Page 2: Safety Guidelines - Definitions

    SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these symbols. DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 3 WARNING: This product may not be equipped with a spark-arresting muffler. If the product is not equipped and will be used around flam ma ble ma teri als or on land covered with materials such as agricultural crops, forest, brush, grass or other similar items, then an ap proved spark arrester must be installed and is legally required in the state of California.
  • Page 4 DANGER: RISK TO BREATHING (ASPHYXIATION) WHAT CAN HAPPEN HOW TO PREVENT IT • Breathing ex haust fumes will cause • Operate pressure washer in a well- se ri ous injury or death! En gine ventilated area. Avoid en closed areas exhaust contains carbon mon ox ide, such as ga rages, base ments, etc.
  • Page 5 DANGER: RISK OF INJURY FROM SPRAY WHAT CAN HAPPEN HOW TO PREVENT IT • High-velocity fluid spray can cause • Always wear ANSI-approved Z87.1 objects to break, projecting particles safety glasses. Wear protective clothing at high speed. to protect against accidental spraying. •...
  • Page 6 DANGER: RISK OF INJURY OR PROP ER TY DAMAGE WHEN TRANSPORTING OR STORING WHAT CAN HAPPEN HOW TO PREVENT IT • Fuel or oil can leak or spill and could • If pressure washer is equipped with a fuel result in fire or breathing hazard. shut-off valve, turn the valve to the OFF Se rious in ju ry or death can re sult.
  • Page 7 WARNING: RISK OF BURSTING WHAT CAN HAPPEN HOW TO PREVENT IT • Over inflation of tires could result in • Use a tire pressure gauge to check the serious injury and property damage. tires pressure before each use and while inflating tires;...
  • Page 8 QUICK SETUP GUIDE WARNING: To reduce the risk of injury, read the pressure washer instruction manual and the engine instruction manual before operating pressure washer. Install the Add/Check Oil Add Gasoline Handle The engine is In a well shipped without ventilated outdoor Place handle oil.
  • Page 9 Connect Spray Connect QC Turn Water Wand to Spray Nozzles to Spray Faucet Wand Completely On Thread the spray Pull quick connect cou- Do not run the unit wand into the end pler back and insert without water supply of the spray gun. nozzle.
  • Page 10 GET TO KNOW THE PRESSURE WASHER NOTE: Photographs and line drawings used in this manual are for reference only and do not represent a specific model. Compare the illustrations with your unit to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. BASIC ELEMENTS OF A PRESSURE WASHER (FIG.
  • Page 11 H. Frame Pump Outlet Pump Inlet K. Quick Connect Nozzles Dial-N-Wash Adjustable Pressure Regulator (if equipped, not shown): ® Use the Dial-N-Wash to increase and decrease the pressure. Refer to the Dial- N-Wash Adjustment paragraph. BASIC ELEMENTS OF AN ENGINE Refer to the Engine Owner’s Manual for location and operation of engine controls. Choke Control: Opens and closes carburetor choke valve.

  • Page 12: Operation

    NOTE: The pump on this unit is maintenance free and requires no oil. If there is a problem with the pump, contact our Customer Service Group on www.simpsoncleaning.com as soon as possible. NOTICE: The engine is shipped without oil. Before starting engine, add the oil provided.
  • Page 13 NOTICE: DO NOT attempt to increase pump pressure. A higher pressure setting than the factory set pressure may damage pump. DIAL-N-WASH ADJUSTMENT (FIG. 6, 7) (IF EQUIPPED) Choose the correct high pressure nozzle (0˚, 15˚ or 40˚) for the job to be performed.
  • Page 14 NOZZLE COLOR SPRAY PATTERN USES SURFACES* 0˚ powerful pinpoint unpainted metal for spot cleaning or concrete; of hard, unpainted DO NOT use on wood (if equipped) surfaces or for high reach areas 15˚ intense cleaning grills, driveways, Yellow of unpainted concrete or brick hard surfaces walkways, unpainted...
  • Page 15 Install the black low pressure nozzle into the quick connect fitting of the spray wand. (if equipped) Rotate the Dial-N-Wash (L) to the MAX pressure setting as shown in Figure 6. See How To Use Spray Wand paragraph in this section. NOTE: To apply chemicals the black low pressure nozzle must be installed and the Dial-N-Wash must be in the MAX pressure setting as shown in Figure 6.
  • Page 16 • Operate pressure washer in a well-ventilated area. Avoid en closed areas such as ga rages, base ments, etc. • Never op er ate unit in or near a lo ca tion occupied by humans or animals. WARNING: Risk of Fire, Asphyxiation and Burn. Never fill fuel tank when engine is running or hot.

  • Page 17: Shutting Down

    WARNING: To reduce the possibility of contamination always protect against backflow when connected to a potable water system. Choose the correct nozzle for the job to be performed. See How To Use spray Wand instructions in this section. NOTE: If applying a chemical or cleaning solution, see How To Apply Chemicals/Cleaning Solvents instructions in this section.

  • Page 18: Maintenance

    MAINTENANCE WARNING: Risk of burn hazard. When performing maintenance, you may be exposed to hot surfaces, water pressure or moving parts that can cause serious injury or death. WARNING: Risk of fire hazard. Always disconnect, spark plug wire, let the engine cool and release all water pressure before performing any maintenance or repair.

  • Page 19: Pressure Washer

    ® is environmentally friendly. NOTE: Using pump guard helps provide proper lubrication to the internal seals of the pump regardless of temperature or environment. NOTICE: Risk of property damage. Use only SIMPSON / POWERWASHER ® ® Pump Guard or equivalent. Other products could be corrosive and/or contain alco- hol which may cause pump damage.

  • Page 20: Service Information

    The one year limited warranty applies to the pump only. FIVE YEAR LIMITED WARRANTY ON FRAME SIMPSON warrants to the original purchaser that the frame of the SIMPSON ® ® pressure washer covered under this warranty is free from manufacturer’s defects in material and workmanship for five years from the date of purchase.
  • Page 21 Owners Manual(s) supplied with the product, improper maintenance, the use of accessories or attachments not SIMPSON recommended by ® , or unauthorized repair or alterations.

  • Page 22: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE OPERATIONAL POSSIBLE CAUSE SOLUTION ISSUE Engine will No fuel. Add fresh fuel. not start (see Pressure builds up after Squeeze gun trigger to relieve Engine Owner’s two pulls on the recoil pres sure Manuall for starter or after initial use further engine Choke lever in the "No Move choke to the "Choke"...
  • Page 23 OPERATIONAL POSSIBLE CAUSE SOLUTION ISSUE See How to Use Spray Wand Will not draw Spray wand not in chemicals low pressure paragraph in the Operation Section Chemical filter clogged Clean filter Chemical screen not Make sure end of detergent in cleaning solution siphon hose is fully submerged into cleaning solution Chemical too thick...
  • Page 25 www.simpsoncleaning.com Internet Address: Warranty Registration via Internet www.simpsoncleaning.com Adresse Internet : Enregistrement de la garantie par Internet www.simpsoncleaning.com Sitio Address: Registro Garantía mediante Internet Copyright. All Rights Reserved Copyright. Todos los derechos reservados Copyright. Tous droits réservés FNA Group, Inc. 7152 99th Street Pleasant Prairie, WI 53158 Made in U.S.A.
