PRESSURE WASHER
USE AND CARE MANUAL
READ THIS MANUAL CAREFULLY BEFORE OPERATION
Failure to follow the instructions and safety precautions in this manual can result
in property damage, serious injury and/or death.
If your pressure washer is not working or if there are parts missing or broken, please DO NOT
RETURN IT TO THE PLACE OF PURCHASE. Contact our Customer Service Department by calling
1-877-362-4271 or emailing cservice@fna-group.com
SAVE THIS MANUAL FOR FUTURE REFERENCE
NOTE: Photographs and line drawings used in this manual are for reference only and may not
represent your specific model.
Part Number 7120074 / ENGLISH
For 61264
LOOK BEFORE YOU PUMP!
REV A - 2/2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simpson Pro Series

Summary of Contents for Simpson Pro Series

  • Page 1 PRESSURE WASHER USE AND CARE MANUAL For 61264 LOOK BEFORE YOU PUMP! READ THIS MANUAL CAREFULLY BEFORE OPERATION Failure to follow the instructions and safety precautions in this manual can result in property damage, serious injury and/or death. If your pressure washer is not working or if there are parts missing or broken, please DO NOT RETURN IT TO THE PLACE OF PURCHASE.
  • Page 2 NOTES THIS PAGE WAS INTENTIONALLY LEFT BLANK Page II...
  • Page 3 SAVE THIS MANUAL FOR FUTURE USE Keep this manual for future reference. This manual should be considered a permanent part of the product and stay with it. This manual should be available to anyone operating the product(s) it covers. This manual should remain with the product(s) it covers if sold to a new owner.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SAFETY INSTRUCTIONS Read this Manual Before Operating Additional Instructions Hazard Alert Symbols DISCLAIMERS PERSONAL PROTECTIVE EQUIPMENT UNPACKING ASSEMBLY Install Knob-style Handle Adding the pump breather cap Assemble the Spray Gun Organize Accessories Connect the battery COMPONENT LOCATION CONNECTING HOSES PURGING AIR FROM THE PUMP 11 NOZZLES...
  • Page 5 MAINTENANCE Maintenance Cleaning the Pressure Washer Connections Nozzle Cleaning Water Inlet Filter Pump Maintenance Engine Maintenance STORAGE AND TRANSPORTATION Storing for Two Months or Less Storing for More Than Two Months Transportation USING SIMPSON ® PUMP GUARD WARRANTY Page 3...

  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS READ THIS MANUAL BEFORE OPERATING This manual contains important safety information and instructions. Do not operate this product until you have read, and completely understand all safety, operation, and maintenance instructions listed in this manual. Failure to follow the information contained in this manual will result in property damage, injury, and/or death.

  • Page 7: Disclaimers

    NOTICE This appliance is not intended to be used by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 8: Unpacking

    UNPACKING Follow the steps outlined in this section to unpack and assemble your pressure washer. If you have any questions regarding the unpacking or assembly of your pressure washer, please have your model number and serial number ready, then contact customer support at 1-877-362-4271 or email cservice@fna-group.com.

  • Page 9: Assemble The Spray Gun

    Assemble the spray gun 1. Secure the lance to the gun by carefully turning the coupler on the spray gun until the coupler stops rotating. Do not over tighten. Most of the threads on the lance will not be visible if the lance and gun are properly assembled.

  • Page 10: Component Location

    COMPONENT LOCATION 1. Engine ON/OFF switch 2. Fuel tank 3. Fuel filler cap 4. Engine starter motor 5. Electric start push button 6. Detergent injection connector 7. Spray gun holder 8. Nozzle holder 9. Spray gun 10. Spray gun trigger 11.
  • Page 11 16. Engine throttle (if equipped) 17. Engine choke 18. Engine fuel valve 19. Garden hose coupler & water inlet filter 20. Battery box 21. Spark plug 22. Engine starting recoil 23. Spray wand quick connector 24. High-pressure hose 25. Thermal relief valve 26.

  • Page 12: Connecting Hoses

    CONNECTING HOSES Before connecting a water supply hose, be sure the water supply is capable of providing an uninterrupted source of clean, cold water at a minimum rate of 5 gallons per minute (GPM) and 20 pounds per square inch (PSI) of pressure. Once a proper water supply is secured, follow the instructions below to connect both the water supply and high-pressure hoses to the pressure washer.

  • Page 13: Purging Air From The Pump

    PURGING AIR FROM THE PUMP NOTICE PUMP PURGING Running a pressure washer pump without water will severely damage the pump seals and other internal components. To avoid this hazard, make sure your water supply is uninterrupted and at least 5 GPM at 20 PSI, and always purge the air your pressure washer pump before starting the engine.

  • Page 14: Nozzles

    NOZZLES Nozzle Selection The nozzles supplied with the pressure washer have specific spray patterns designed to clean different surfaces. Using the incorrect nozzle can damage surfaces. Refer to the table below to select the correct nozzle before using the pressure washer. NOTE: The selection of nozzles included may vary with pressure washer models.

  • Page 15: Using Chemicals

    USING CHEMICALS NOTICE VOLATILE LIQUIDS Pressure washing with volatile, flammable, or corrosive liquids could cause pressure washer damage, fire, or explosion resulting in severe injury and/or death. To avoid these hazards, use only approved soaps and chemicals, do not attempt to pressure wash with volatile, flammable, or corrosive liquids, and NEVER use bleach.

  • Page 16: Operating Checklist

    OPERATING CHECKLIST Location Place the pressure washer on a level surface outside in a well-ventilated area before operating. Keep all flammable materials at least five feet away from all sides of the product. ● Never use pressure washer inside a house, garage, or any other kind of enclosure even if doors and windows are open.

  • Page 17: High Altitude Operation

    High Altitude Operation This engine will have proper engine performance and emission control when it is operated at or below an altitude of 5000 feet (1524 meters). This engine requires a high-altitude carburetor kit to ensure proper engine performance and emission control when operated at altitudes above 5000 feet (1524 meters).

  • Page 18: Checking The Engine Oil

    WARNING: WARNING: INJECTION INJURY The high pressures created by a pressure washer can cause fluid injection injuries, severe lacerations, amputations, and / or death. To avoid these hazards, always aim the spray gun and lance in a safe direction when using the pressure washer and never attempt to touch a leak in a high-pressure hose or fitting.
  • Page 19 NOTICE FILL ENGINE OIL BEFORE USE The engine is shipped from the factory without oil. Running the engine without oil will result in severe engine damage and void the warranty. To avoid causing engine damage and voiding the warranty, fill the engine with the recommended oil type before starting. NOTICE USE CORRECT ENGINE OIL Oil is a major factor in the performance and service life of any engine.

  • Page 20: Checking Fuel

    Checking Fuel WARNING: WARNING: REFUELING Gasoline is highly flammable and gasoline vapors are extremely explosive. Fire and explosions can cause severe burns and/or death. Keep gasoline away from flames, sparks, and other ignition sources. Refuel outdoors in a well-ventilated area with the engine stopped and cool.
  • Page 21 NOTICE GASOLINE STORAGE It is important to prevent gum deposits from forming in essential fuel system parts, such as the carburetor, fuel filter, fuel hose or tank during storage. Alcohol-blended fuels (also called gasohol, ethanol, or methanol) attract moisture, which leads to separation and formation of acids during storage.

  • Page 22: Starting The Engine

    STARTING THE ENGINE WARNING: WARNING: OPERATING CHECKLIST Attempting to start the engine incorrectly or using the pressure washer incorrectly can result in engine and/or pressure washer damage, and may cause serious injury or death. To avoid these hazards, be sure to read, understand, and follow the steps outlined in the OPERATING CHECKLIST section of the owner’s manual before starting the engine, and follow all the guidelines for proper use of the pressure washer.
  • Page 23 NOTE: The starting position of the choke will vary depending on the engine temperature. If starting a cold engine, move the choke lever towards the CHOKE position. If starting a warm engine, move the choke lever towards the RUN position. 6A.
  • Page 24 7. Once the engine starts, slowly move the choke lever to RUN as the engine runs. If the engine falters, move the choke toward CHOKE until the engine has warmed up. CHOKE SHUTTING OFF THE ENGINE NOTICE PUMP DAMAGE Turning off the water supply to your pump with the engine running will damage the pump. Damage caused by running the pump without water is not covered under warranty.
  • Page 25 OPERATION TIPS Terms ● PSI – Stands for pounds per square inch and measures the water pressure or stripping power produced by the pressure washer. The higher the PSI number, the greater the pressure and stripping power produced. ● GPM – Stands for gallons per minute and measures the flow rate of the water. The higher the GPM, the greater the flow or rinsing power produced.
  • Page 26 TROUBLE SHOOTING ISSUE POSSIBLE CAUSE SOLUTION The fuel tank is empty. Add fresh fuel. Aim the spray gun in a Water pressure in the pump safe direction then pull the is preventing the engine from trigger to release water rotating. pressure in the pump.
  • Page 27 ISSUE POSSIBLE CAUSE SOLUTION Spray wand not in low pressure. Insert black “soap” nozzle. Detergent filter clogged. Clean the filter. Make sure the filter end of Detergent filter is not the detergent siphon hose submerged in the detergent. is fully submerged in the detergent.
  • Page 28 MAINTENANCE For safety reasons, the manufacturer recommends all pressure washer service and repairs be performed by an authorized service center. All warranty replacements or repairs must be performed by an authorized distribution or service center. To find an authorized service center near you, make a warranty claim, or get authorized warranty repair, call 1-877-362- 4271 or email cservice@fna-group.com.
  • Page 29 Nozzle Cleaning If a nozzle becomes clogged, the pump may pulsate and spray patterns could change. If the nozzle is not cleaned, excessive pressure may develop possibly damaging the pump, or other accessories. Inspect nozzles before using them and follow the instructions in this section for the proper nozzle cleaning procedure.
  • Page 30 Pump Maintenance Note: The pump was filled with oil at the factory. The preferred oil is SIMPSON © Premium Pump Crankcase Oil. If this oil is not available, an SAE 15W-40 oil may be used. Change the oil after the first 50 hours of operation and every 100 hours thereafter or every 3 months.
  • Page 31 Disconnect the high-pressure hose from the pump and spray gun. 7. Allow the engine to cool completely. ® 8. Protect the pump by using SIMPSON Pump Guard per the USING PUMP GUARD section of this manual.
  • Page 32 Install the spark plug. Drain the high-pressure hose. Using SIMPSON Pump Guard or an equivalent is recommended when storing the unit for more than 30 days and/or when freezing temperatures are expected. Store the pressure washer in a clean, dry area out of direct sunlight.
  • Page 33 NOTICE PUMP DAMAGE Leaving water inside the pump during freezing weather will cause severe damage to the pump. To avoid costly damage, always treat the pump with SIMPSON ® Pump Guard to remove the trapped water and to fill the pump with a lubricating, antifreeze solution.
  • Page 34 RESPONSIBILITY OF ORIGINAL PURCHASER (INITIAL USER): To process a warranty claim on your SIMPSON® pressure washer, report the concern to 1-877-362-4271 or cservice@FNA-GROUP.COM for authorization and direction to the nearest authorized service center in your area.
  • Page 35 NOTES THIS PAGE WAS INTENTIONALLY LEFT BLANK Page 33...
  • Page 36 THIS PAGE WAS INTENTIONALLY LEFT BLANK Page 34...
  • Page 37 THIS PAGE WAS INTENTIONALLY LEFT BLANK Page 35...
  • Page 38 READ THIS MANUAL CAREFULLY BEFORE OPERATION Failure to follow the instructions and safety precautions in this manual can result in property damage, serious injury and/or death. SAVE THIS MANUAL FOR FUTURE REFERENCE Part Number 7120074 / ENGLISH REV A - 2/2023...
