  • Page 1 ® TWO-SIDED GRILLS MODEL CG10, GR10 CG14 & GR14 Installation and Operation Instructions 2M-Z2906 Rev. O 10/03/2014 14 x 14 Grooved Grill...
  • Page 2: Maintenance And Repairs

    RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. Star reserves the right to change specifications and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
  • Page 3 SPECIFICATIONS Height Approx. Weight Model Grid “A” Width “B” Depth Voltage Wattage Amps NEMA Surface “C” Closed “D” Open Shipping Installed 5-15P 16-1/8” 21-1/8” 14-1/4” 28-3/4” 1800 52 lbs. 36 lbs. GR10 Alum. 5-20P* 40.9 cm 53.7 cm 36.2 cm 73 cm 208/240 1350/1800...
  • Page 4 Specifications Model Platen Timer Country CG10I-120V CG10I-120VC without Timer Canadian CG10I-240V CastIron CG10IT-120V CG10IT-120VC with Timer Canadian CG10IT-240V Grooved Top and Bottom Platens CG14-120V CG14-120VC without Timer Canadian CG14-240V Aluminum CG14-2T-120V with 2 Timers CG14-2T-120VC Canadian CG14GTB-120V Smooth Bottom and Grooved Top Platens with Timer CG14I-240V Grooved Top and Bottom Platens...
  • Page 5: General Installation Data

    GENERAL INSTALLATION DATA This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. Before using your new equipment, read and understand all the instructions &...
  • Page 6: Initial Start-Up

    ELECTRICAL SPECIFICATIONS Model No. Volts Rated Wattage Amps NEMA Plug GR 10 1800 5-15P GR 10 1800 6-15P GR 10I 1800 5-15P GR 10I 1800 6-15P CG 10I 1800 5-15P CG 10I 1800 6-15P Note: For Canada, 120 volt units listed above have NEMA 5-20P plug. Model No.
  • Page 7: Knob Setting

    KNOB SETTING Knob Position Approx. Temp 175°F / 79°C 200°F / 93°C 250°F / 121°C 300°F / 148°C 350°F / 176°C 400°F / 204°C 450°F / 232°C 500°F / 260°C 550°F / 287°C ON/OFF ROCKER SWITCH (TIMER MODELS ONLY) The switch turns the unit on and off. The switch has three positions: With the switch in this position, both top and bottom platens will heat.
  • Page 8 CLEANING (NON CHROME SURFACES) Begin cleaning procedure by using the operating procedures within your organization, or follow the steps below: 1. If particles adhere to the cooking surface during the day, scrape them off with a spatula. NOTE: It is best not to let food cook onto the grill, as food build-up on the grill will increase sticking and smoking.
  • Page 9: Operation Troubleshooting

    1 years against manufacturing defects to the original owner from the date of installation. This limited warranty is void if it is determined by Star Manufacturing International Incorporated or one of its authorized representatives that the chrome surface has been misused or abused or subjected to the following situations: 1.
  • Page 10 LIMITED EQUIPMENT WARRANTY All workmanship and material in Star products have a one (1) year limited warranty on parts & labor in the United States and Canada. Such warranty is limited to the original purchaser only and shall be effective from the date the equipment is placed in service. Star's obligation under this warranty is limited to the repair of defects without charge, by the factory authorized service agency or one of its sub-agencies.
  • Page 14 GENERAL LOCATION BUT MAY BE RELOCATED OR SCALED FOR CLARITY. CG/GR, 10/14, 120V/230/240V, MODEL: WITH TIMER STAR MANUFACTURING INTERNATIONAL INC. THIS DRAWING CONTAINS INFORMATION CONFIDENTIAL TO STAR MFG. INT'L. INC. NO REPRODUCTION OR DISCLOSURE OF ITS CONTENTS IS PERMITTED. SK2001 Rev A 8/10/2004...
  • Page 15 RELOCATED OR SCALED FOR CLARITY. WIRE DIAGRAM, CG/GR, 10/14, 120V/230/240V, WITH 2 TIMERS, T-STAT, AND SPST SWITCH SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE STAR MANUFACTURING INTERNATIONAL, INC. MODEL: SEE ABOVE SK2387 REV. A 2-26-09...
  • Page 16 ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE This drawing contains information confidential = B Style Hinge Units Only to Star Manufacturing International, Inc. No reproduction or disclosure of its contents is permitted. STAR INTERNATIONAL HOLDINGS, INC. COMPANY...
  • Page 17: Parts List

    TORQUE BOX ASSY. D9-Z3071 BRACKET-HANDLE IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE 1 INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star Manufacturing International, Inc.
  • Page 18 BASE ASSY/GREASE CABINET 120C MODELS D9-GR0553 230V MODELS IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star Manufacturing International, Inc.
  • Page 19 CAST-TOP ALM GR14, GR14T IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE 1 INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star International Holding, Inc. Company...
  • Page 20 CG14T, CG14IT, CG14IGT, GR14T, GR14IT IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star International Holding, Inc. Company...
  • Page 21 COUNTER BALANCE STOP BRACKET ACCESSORIES IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star International Holding, Inc. Company...
  • Page 22 GR14I, GR14IT, CG14I, CG14IT, CG14IGT, CG14ITGT IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star International Holding, Inc. Company...
  • Page 23 Z1-70-07-0343 SWITCH GUARD CG14E, GR14E IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. Star International Holding, Inc. Company...
  • Page 24 STAR INTERNATIONAL HOLDINGS INC. COMPANY Star - Holman - Lang - Wells - Bloomfield - Toastmaster 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (314) 678-6303 www.star-mfg.com...
