Page 1
Warranty information contained in this User Guide will describe your limited coverage from ViewSonic® Corporation, which is also found on our web site at http://www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
Page 2
As a world-leading provider of visual solutions, ViewSonic® is dedicated to exceeding the world’s expectations for technological evolution, innovation, and simplicity. At ViewSonic®, we believe that our products have the potential to make a positive impact in the world, and we are confident that the ViewSonic® product you have chosen will serve you well.
Safety Precautions Please read the following Safety Precautions before you start using the device. • Keep this user guide in a safe place for later reference. • Read all warnings and follow all instructions. • Sit at least 18" (45 cm) away from the device. •...
Page 4
• If smoke, an abnormal noise, or a strange odor is present, immediately turn the device off and call your dealer or ViewSonic®. It is dangerous to continue using the device. •...
Page 5
• Fastening the display to a wall or fixed object using cordage or other restraining devices can help support the weight of the display in order to prevent the display from falling over. Hole pattern Interface Pad Pad Hole Screw Specification & Quantity (W x H) (W x H x D) M4 x 10 mm...
Contents Safety Precautions ............3 Introduction ..............8 Package Contents ....................8 Product Overview ....................9 Front and Rear View ....................9 I/O Ports ......................... 9 Initial Setup ............... 10 Installing the Stand ....................10 Wall Mounting ......................11 Using the Security Slot ..................12 Making Connections ..........
Page 7
Regulatory and Service Information ......35 Compliance Information ..................35 FCC Compliance Statement ................... 35 Industry Canada Statement ................... 35 CE Conformity for European Countries ..............35 Declaration of RoHS2 Compliance................. 36 Indian Restriction of Hazardous Substances ............37 Product Disposal at End of Product Life ..............37 Copyright Information ..................38 Customer Service ....................
Introduction Package Contents • Monitor • Power adapter • Power cord • Video cable • Quick start guide NOTE: The power cord and video cables included in your package may vary depending on your country. Please contact your local reseller for more information.
Product Overview Front and Rear View I/O Ports HDMI 1 HDMI 2 1. Audio Out 2. DisplayPort 3. HDMI 4. DC IN NOTE: For more information about the 1(«)/2/3/4/5( ) key and its functions, refer to “Hot Keys” on page 18.
Initial Setup Installing the Stand NOTE: Always place the device on a flat, stable surface. Failure to do so may cause the device to fall and become damaged, or result in personal injury.
4 pieces NOTE: Wall mount kits are sold separately. To obtain a wall mounting kit, contact ViewSonic® or your local dealer. 1. Turn off the device and disconnect all cables. 2. Place the device on a flat, stable surface with the screen facing down.
Using the Security Slot To help prevent the device from being stolen, use a security slot locking device to secure the device to a fixed object. Additionally, fastening the monitor to a wall or fixed object using a security cable can help support the weight of the monitor in order to prevent the monitor from falling over.
Making Connections This section guides you on how to connect the monitor with other equipment. Connecting to Power 1. Connect the power cord to the power adapter. 2. Connect the power adapter to the DC IN jack at the rear of the device. 3.
Using the Monitor Adjusting the Viewing Angle Tilt Angle Adjustment Tilt the monitor forwards or backwards to the desired viewing angle (-7˚ to 22˚). NOTE: When adjusting, support the stand firmly with one hand while tilting the monitor forwards or backwards with the other hand.
Turning the Device On/Off 1. Plug the power cord into a power outlet. 2. Press the Power button to turn on the monitor. 3. To turn the monitor off, press the Power button again. NOTE: The monitor will still consume some power as long as the power cord is connected to the power outlet.
Quick Menu key to activate the Quick Menu. Press the 1( «) View Mode Standard FPS Game RTS Game MOBA Game Movie Text Mono NOTE: Follow the key guide that appears on the bottom of the screen to select the option or make adjustments. Description Menu Select one of the preset color settings.
Hot Keys When the On-Screen Display (OSD) Menu is off, you can quickly access special functions by using the control panel keys. Description «) Press and hold the keys to lock/unlock the OSD Menu. When the menu appears on the screen, continue holding both keys for 10 seconds to lock/unlock the OSD Menu.
Page 19
Description «) Press and hold the keys to lock/unlock the button. Power When the menu appears on the screen, continue holding both keys for 10 seconds to lock/unlock the button. Power Power Lock/Unlock Locking Power Button Press and hold for 10s to lock power If the button is locked, the below message will appear on...
Configuring the Settings General Operations 1. Press the 2/3/4 key to display the On-Screen Display (OSD) Menu. Input Audio Adjust ViewMode Color Adjust Manual Image Setup Menu Select Adjust HDMI 1 HDMI 2 DisplayPort 1920 x 1080 @ 60Hz «) 2.
Page 21
or 2 key to select the desired menu option. Then press the 3 key 3. Press the 1( «) to enter the sub-menu. Manual Image Input Audio Adjust ViewMode Color Adjust Setup Menu Adjust Select Contrast/Brightness sRGB Color Temperature Bluish Color Space Cool Color Range...
On-Screen Display (OSD) Menu Tree Menu Option Main Menu Sub-menu HDMI 1 Input Select HDMI 2 DisplayPort Volume (-/+, 0~100) Audio Adjust Standard ViewMode FPS Game RTS Game MOBA Game Movie Text Mono Contrast (-/+, 0~100) Color Adjust Contrast/Brightness Brightness (-/+, 0~100) Color Temperature sRGB...
Page 23
Menu Option Main Menu Sub-menu (-/+, Manual Sharpness 0/25/50/75/100) Image Adjust Blue Light Filter (-/+, 0~100) Aspect Ratio 16:9 16:10 Overscan (-/+, 0/10/20/30/4 Black Stabilization 0/50/60/70/80/90 /100) (-/+, Advanced DCR 0/25/50/75/100) Standard Response Time Advanced Ultra Fast...
Page 24
Menu Option Main Menu Sub-menu Language Select English Setup Menu Français Deutsch Español Italiano Suomi Svenska Русский Türkçe Česká 日本語 한국어 繁體中文 简体中文 Adaptive Sync 1ms Mode Resolution Notice Information OSD Timeout (-/+, 5/15/30/60) OSD Background Power Indicator Auto Power Off...
Page 25
Menu Option Main Menu Sub-menu Sleep 30 Minutes Setup Menu 45 Minutes 60 Minutes 120 Minutes Standard Optimize ECO Mode Conserve Auto Detect DDC/CI Memory Recall...
Appendix Specifications Specifications Item Category Color a-Si TFT Active Matrix 1920 x 1080 LCD; Type 0.36375 (H)mm x 0.36375 (V)mm pixel pitch Display Size 80 cm, 31.5" RGB vertical stripe Color Filter 25%), Hard Coating (3H) Glass Surface Anti-Glare (Haze TMDS digital (100 Ω) Input Signal Video Sync...
Page 27
39W (Typical) with 50% audio ≤ 0.3W Do not set the graphics card in your computer to exceed these timing modes; doing so may result in permanent damage to the display. Please use the power adapter from ViewSonic® or an authorized source only.
Glossary This section describes the standard glossary of terms used in all LCD display models. All terms are listed in alphabetical order. NOTE: Some terms may not be applicable to your monitor. Advanced DCR Advanced DCR technology automatically detects the image signal and intelligently controls the backlight brightness and color to improve on the ability to make the black blacker in a dark scene, and make the white whiter in a bright environment.
Page 29
Displays the timing mode (video signal input) coming from the graphics card in the computer, the LCD model number, the serial number, and the ViewSonic® website URL. See your graphics cards’s user guide for instructions on changing the resolution and refresh rate (vertical frequency).
Page 30
Sharpness Adjusts the picture quality of the monitor. ViewMode ViewSonic’s unique ViewMode feature offers “Game”, “Movie”, “Web”, “Text”, “MAC”, and “Mono” presets. These presets are specifically designed to deliver an optimized viewing experience for different screen applications.
Page 31
1ms Mode <MPRT> Choose whether to activate Moving Picture Response Time (MPRT); default setting is Off. NOTE: 1. Make sure Input Timing detection is >100Hz to turn on 1ms Mode from default. 2. If 1ms Mode is set to “On”, when turning on Adaptive Sync, MPRT will automatically turn off.
• Connect the monitor to another computer. • If you have an older graphics card, contact ViewSonic® for a non-DDC adapter. • Adjust brightness and contrast settings via the OSD Screen image is too light or dark Menu.
Page 33
Possible Solutions Problem or Issue • Make sure the “Blue Light Filter” is Off. The screen appears yellow The OSD Menu • Check whether the OSD Menu is locked. • Turn off the monitor, unplug the power cord, plug it does not appear on the screen/the back in, and then turn on the monitor.
• ViewSonic® does not recommend the use of any ammonia or alcohol-based cleaners on the display screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the monitor. • ViewSonic® will not be liable for damage resulting from use of any ammonia or alcohol-based cleaners.
Regulatory and Service Information Compliance Information This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on the unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
The following information is only for EU-member states: The mark shown to the right is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose of the equipment as unsorted municipal waste, but use the return and collection systems according to local law.
Schedule 2 of the Rule. Product Disposal at End of Product Life ViewSonic® respects the environment and is committed to working and living green. Thank you for being part of Smarter, Greener Computing. Please visit the ViewSonic®...
ENERGY STAR® is a registered trademark of the U.S. Environmental Protection Agency (EPA). As an ENERGY STAR® partner, ViewSonic® Corporation has determined that this product meets the ENERGY STAR® guidelines for energy efficiency. Disclaimer: ViewSonic® Corporation shall not be liable for technical or editorial errors or omissions contained herein;...
For technical support or product service, see the table below or contact your reseller. NOTE: You will need the product’s serial number. Country/ Region Website Country/ Region Website Asia Pacific & Africa Australia Bangladesh www.viewsonic.com/au/ www.viewsonic.com/bd/ 中国 (China) 香港 (繁體中文) www.viewsonic.com.cn www.viewsonic.com/hk/ Hong Kong (English) India www.viewsonic.com/hk-en/ www.viewsonic.com/in/...
How long the warranty is effective: ViewSonic® displays are warranted for between 1 and 3 years, depending on your country of purchase, for all parts including the light source and for all labor from the date of the first consumer purchase.
Page 41
(e) the serial number of the product. • Take or ship the product, freight prepaid, in the original container to an authorized ViewSonic® service center or ViewSonic®. • For additional information or the name of the nearest ViewSonic® service center, contact ViewSonic®. Limitation of implied warranties:...
Page 42
Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of...
If a product proves to be defective in material or workmanship during the warranty period, ViewSonic® will, at its sole option, repair or replace the product with a like product. Replacement product or parts may include remanufactured or refurbished parts or components &...
Page 44
Exclusion of damages: ViewSonic®’s liability is limited to the cost of repair or replacement of the product. ViewSonic® shall not be liable for: • Damage to other property caused by any defects in the product, damages...
Page 45
Name, address, of manufacturer and importers: México, Av. de la Palma #8 Piso 2 Despacho 203, Corporativo Interpalmas, Col. San Fernando Huixquilucan, Estado de México Tel: (55) 3605-1099 http://www.viewsonic.com/la/soporte/index.htm NÚMERO GRATIS DE ASISTENCIA TÉCNICA PARA TODO MÉXICO: 001.866.823.2004 Hermosillo: Villahermosa: Compumantenimietnos Garantizados, S.A.
