Acer UT220HQL Quick Start Manual

Acer LCD Monitor Quick Start Guide (QSG)

Important safety instructions

Please read the following instructions carefully.
1 To clean the LCD monitor screen:
• Turn off the LCD monitor and unplug the power cord.
• Spray a non-solvent cleaning solution onto a rag and clean the screen gently.
2 Do not place the LCD monitor near a window. Exposing the monitor to rain, moisture or sunlight can severely
damage it.
3 Do not apply pressure to the LCD screen. Excessive pressure may cause permanent damage to the display.
4 Do not remove the cover or attempt to service this unit yourself. An authorized technician should perform
servicing of any nature.
5 Store the LCD monitor in a room with a temperature of -20° to 60° C (-4° to140° F). Storing the LCD monitor
outside this range may result in permanent damage.
6 Immediately unplug your monitor and call an authorized technician if any of the following circumstances occur:
• Monitor-to-PC signal cable is frayed or damaged.
• Liquid spills onto the LCD monitor or the monitor is exposed to rain.
• The LCD monitor or case is damaged.

Package contents

Audio
LCD
Power cord cable
monitor
(optional)

Connecting your monitor to a computer

1. Turn off your computer and unplug your computer's power
cord.
Connect the signal cable to the VGA and/or HDMI(optional)
2.
and/or MHL(optional) input socket of the monitor, and the
VGA and/or HDMI(optional) and/or MHL(optional) output
socket of the graphics card on the computer. Then tighten
the thumbscrews on the signal cable connector.
3. Optional: Connect the audio input socket (AUDIO IN) of the
LCD monitor and the line-out port on the computer with
the audio cable.
Connect the USB Cabel(Only USB-Input Model)(Optional).
4.
Connect one end of the adapter to the monitor and the other
5.
end to a properly grounded, AC outlet.
6.
Plug the power cords of your computer and your monitor
into a nearby electrical outlet.
Manufacturer: TPV Electronics (Fujian) co.,LTD,Model: ADPC1945
4 3
7 6 5

External controls

1&2 Power button
3&4 </> Minus / Plus
5 Menu OSD functions Press to view the OSD. Press again to enter a selection in the OSD.
MHL cable HDMI cable
VGA cable
(optional)
(optional)
(optional)
MHL
1&2
Turns the monitor on/off. Blue indicates power on. Amber indicates
standby/ power saving mode.
If the OSD is active, press the Minus or Plus buttons to toggle between
the OSD options. If the OSD is inactive, press the Minus or Plus buttons to
adjust the volume. (Optional)
USB cable
Quick start
AC Adapter
(optional)
guide
USB
USB
VGA
