- Page 1 MANUAL FiberLink 7250 Series Hi-Res RGB with Stereo Audio Over Two Fibers Installation and Operations Manual WWW.ARTEL.COM...
-
Page 2: Table Of Contents
Maintenance and Repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Page 2 FiberLink 7250 Series User’s Manual... -
Page 3: Welcome
FiberLink 7250 Series Welcome The FiberLink 7250 Series is a transmitter/receiver pair that transmits a single channel of RGBHV video (up to WUXGA) and two audio channels over two single mode or multimode fibers . It is available as a free-standing box unit or as a card version for use in the rackmount- able 6000A card cage . -
Page 4: Technical Specifications
SNR (A-Weighted) 95 dB Channel Phase Differential +/-0 .1 Crosstalk Min . Min . 95 dB (1 kHz) Signal Connectors 3 .5mm Stereo jack Audio to Video Diff . Delay (skew) <300 uS Page 4 FiberLink 7250 Series User’s Manual... - Page 5 *Distance specifications are only approximate and are not guaranteed. Operating loss budget must not be exceeded. General Specifications Operating Temp. Range -20 to +50 degrees C Operating Power 9-24 Volts AC or DC@7 .4watts (max .) FiberLink 7250 Series User’s Manual Page 5...
-
Page 6: Installation Instructions
FiberLink 7250 Series Installation Instructions The FiberLink 7250 Series transmission system is ready for immediate use . There are indica- tor LEDs on the units for monitoring purposes . The following instructions describe the typical installation procedure and the function of the LED indicators . -
Page 7: System Connections
Transmitter Receiver Green Green Blue Blue Ground Ground Ground Ground Ground Ground Ground Ground Ground Ground Hor . Sync . Out Hor . Sync Out Vert . Sync Out Vert . Sync Out FiberLink 7250 Series User’s Manual Page 7... -
Page 8: Alarm Switch Settings
Steady Green Indicates both H and V sync detected on the input Audio Indicates no audio detected by the transmitter unit Alarm On (Red) Loss of video (rack card only) Page 8 FiberLink 7250 Series User’s Manual... -
Page 9: Indicator Leds
Data No data detected to or from the receiver unit Blinking Indicates active data detected to or from the receiver unit Alarm On (Red) Loss of video or optical signal (rack card only) FiberLink 7250 Series User’s Manual Page 9... - Page 10 If these are off, it usually means that the fiber is broken or has too much attenuation. Next, be certain that the input and output signal connections are correct. Page 10 FiberLink 7250 Series User’s Manual...
-
Page 11: Maintenance And Repairs
FiberLink 7250 Series Maintenance and Repairs The FiberLink 7250 Series transmission system has been manufactured using the latest semiconductor devices and techniques that electronic technology has to offer. It has been designed for long, reliable and trouble-free service and are not normally field repairable. - Page 12 • Solutions for most video, audio, and data formats • Multimode and single mode versions • Designed and manufactured in the USA • Training and installation support available • 24x7x365 technical support available Artel Video Systems Corp. 5B Lyberty Way, Westford, MA 01886 USA T: 978-263-5775 F: 978-263-9755 All specifications subject to sales@artel.com...
