- Page 1 RTL8188CEBT Combo miniCard User’s Manual Rev. 1.0 03 Dec 2009 Realtek Semiconductor Corp. No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu 300, Taiwan Tel.: +886-3-578-0211. Fax: +886-3-577-6047 www.realtek.com.tw...
- Page 2 Combo mini-Card User Manual COPYRIGHT ©2009 Realtek Semiconductor Corp. All rights reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means without the written permission of Realtek Semiconductor Corp.
-
Page 3: Table Of Contents
RTL8188CEBT Combo mini-Card User Manual Table of Contents GENERAL DESCRIPTION..............................1 1.1. RTL8188CE ...................................1 1.2. 4-ROM................................1 FEATURES...................................2 2.1. RTL8188CE ...................................2 2.2. 4 ..................................3 BLOCK DIAGRAM ................................4 PRODUCT SPECIFICATIONS............................5 4.1. PCI E ..........................5 XPRESS SSIGNMENT 4.2...................................6 ECHANICAL 4.3................................6 NVIRONMENTAL 4.3.1. -
Page 4: General Description
1. General Description 1.1. RTL8188CE The Realtek RTL8188CE is a highly integrated single-chip Wireless LAN (WLAN) controller compatible with the IEEE 802.11n specification. It combines a MAC, a 1T1R capable baseband, and RF in a single chip. The RTL8188CE provides a complete solution for a high-performance wireless client. -
Page 5: Features
RTL8188CEBT Combo mini-Card User Manual 2. Features 2.1. RTL8188CE Multiple BSSID feature allows the General RTL8188CE to assume multiple MAC identities when used as a wireless bridge 48-pin QFN Supports Wake-On-WLAN via Magic CMOS MAC, Baseband PHY and RF in a Packet and Wake-up frame single chip for IEEE 802.11b/g/n compatible... -
Page 6: Bluecore4
RTL8188CEBT Combo mini-Card User Manual 2.2. BlueCore4 General Fully Qualified Bluetooth v2.1 + EDR system Enhanced Data Rate (EDR) compliant with v2.1 of Specification for both 2Mbps and 3Mbps modulation modes Full Speed Bluetooth Operation with Full Piconet Support Scatternet Support Low power 1.8V operation... -
Page 7: Block Diagram
RTL8188CEBT Combo mini-Card User Manual 3. Block Diagram WLAN Radio WLAN on/off RTL8188CE NV Memory Interface RX I /Q Configuration TX/RX 2.4GHz PCIe Control and Matching Memory Transceiver Circuit 2.4GHz TX I /Q Baseband SPS/LDO (PHY) Regulators Antenna #2 40MHz 3.3V... -
Page 8: Product Specifications
RTL8188CEBT Combo mini-Card User Manual 4. Product specifications 4.1. Mini PCI Express Pin Assignment Table 1. Mini PCI Express Pin Assignment PIN# Pin Name PIN# Pin Name WAKE# 3.3Vaux COEX1 COEX2 +1.5V (Option) CLKREQ# UIM_PWR UIM_DATA UIM_CLK REFCLK- UIM_RESET REFCLK+... -
Page 9: Mechanical
RTL8188CEBT Combo mini-Card User Manual 4.2. Mechanical Figure 2. RTL8188CE miniCard Mechanical Specification 4.3. Environmental 4.3.1. Operating 0 to 70 °C Operating Temperature: Relative Humidity: 5-90% (non-condensing) 4.3.2. Storage -55 to 125 °C Temperature: Relevant Humidity: 5-95% (non-condensing) 4.4. Functional Specifications Table 2. - Page 10 RTL8188CEBT Combo mini-Card User Manual 802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps 802.11n: MCS 0 to 7 for HT20MHz; MCS 0 to 7 for HT40MHz 1/2/3 Mbps WiFi: CSMA/CA with ACK Media Access Control WiFi + BT: AFH, Time Division 802.11b:...
-
Page 11: Warning
RTL8188CEBT Combo mini-Card User Manual 4.5. Warning 4.5.1 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 12: Industry Canada Statement
RTL8188CEBT Combo mini-Card User Manual required with this module installed (for example, digital device emissions, PC peripheral requirements, etc.). IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop configurations or co-location with another transmitter), then the FCC authorization is no longer considered valid and the FCC ID can not be used on the final product. - Page 13 RTL8188CEBT Combo mini-Card User Manual 2) this device must accept any interference, including interference that may cause undesired operation of the device This device has been designed to operate with an antenna having a maximum gain of 3.95dBi. Antenna having a higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50 ohms.
-
Page 14: Ncc 警語
RTL8188CEBT Combo mini-Card User Manual 4.5.3 NCC 警語 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功 率或變更原設計之特性及功能。 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並 改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電 機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 本模組於取得認證後將依規定於模組本體標示審合格籤，並要求平台上標示「本產品內含射頻模 組：ID編號」 Realtek Semiconductor Corp. Headquarters No. 2, Innovation Road II, Hsinchu Science Park, Hsinchu, 300, Taiwan, R.O.C. Tel: 886-3-5780211 Fax: 886-3-5776047 www.realtek.com.tw Rev.1.0...
