Quick Setup Guide NS-DV111080F / NS-DV111080F-CN Congratulations on your purchase of a high-quality Insignia product. Your NS-DV111080F / NS-DV111080F-CN is designed for reliable and trouble-free performance. Use this guide for initial setup of your camcorder. If you have questions, see your User Guide for more information.
Getting to know your camcorder Front view Speakers Shutter button Tele / Wide zoom button Lens Flash Microphone light panel Back view Busy / Power Mode indicator dial Start / Stop Playback button button USB / mini HDMI port Navigation control BUSY POWER OPEN...
Right view Hand strap Flash button Left view Menu button LED light button with LCD panel open Display button DISP MENU OPEN SD/SDHC card slot Power button Bottom view Tripod socket...
Setting up your camcorder To install the battery: 1 Open the battery cover using the Open slider. 2 Insert the battery. Make sure that the + and – symbols on the battery line up with the + and – symbols on your camcorder. You can charge the battery with the included battery charger.
Inserting or removing an SD/SDHC card Your camcorder has 128 MB of internal memory, approximately 70 MB of which is available for video/photo capture. 70 MB will allow you to capture less than one minute of high defi nition video or several photos, so it is strongly recommended that you insert an SD/SDHC card for video/photo capture.
Page 6
System setting Video mode Beep Video format HD (1080p 30fps) Auto power off 5 min. Stabilizer TV format NTSC Time stamp Help text Color balance Auto Simple mode Dual video mode Video quality Super Fine Photo mode Capture resolution Stabilizer Time stamp Face detection Self-timer...
To take a picture: 1 Turn on your camcorder. 2 Turn the Mode dial to 3 Aim the lens, then half-press the Shutter button until the focus area turns green. 4 Fully press the Shutter button to take the picture. To record a video: 1 Turn on your camcorder.
