- Page 1 Oper ator’s manual (EPA) 326HD60 X-series 326HD75 X-series Please r ead the operator’s manual carefully and make sure you understand the instructions before using the machine. E E E E n n n n g g g g l l l l i i i i s s s s h h h h...
-
Page 2: Key To Symbols
KEY T O SYMBOLS Symbols The engine is s witched off by moving the stop switch to the stop position. W ARNING! Incorrect or careless CAUTION! The stop switch use of a hedge trimmer can turn it automatically returns to the start into a dangerous tool that can cause position. -
Page 3: Table Of Contents
CONTENTS Contents Note the f ollowing before starting: KEY TO SYMBOLS Symbols Please read the oper ator’s manual carefully. CONTENTS Contents W ARNING! Long-term exposure to noise can result in permanent hearing Note the f ollowing before starting: impairment. So always use approved INTR ODUCTION hearing protection. -
Page 4: Intr Oduction
Dear customer! Cong ratulations on your choice to buy a Husqvarna product! Husqvarna is based on a tradition that dates back to 1689, when the Swedish King Karl XI ordered the construction of a factory on the banks of the Huskvarna River, for production of muskets. -
Page 5: What Is What
WHA T IS WHA T? What is what? Operator’s manual 13 Lock for handle Grease filler cap, bevel gear 14 Fuel tank Gear housing 15 Fuel cap Blades 16 Air purge Blade guard 17 Choke control Front handle 18 Air filter cover Cylinder cover 19 Hand guard Starter handle... -
Page 6: General Safety Preca Utions
GENERAL SAFETY PRECA UTIONS Impor tant Personal protective equipment IMPORTANT! IMPOR TANT! The machine is only designed for cutting branches and Incorrect or careless use of a hedge trimmer can turn it twigs. into a dangerous tool that can cause serious or even fatal injury. -
Page 7: Machine ' S Safety Equipment
GENERAL SAFETY PRECA UTIONS CLO THING the throttle control is automatically locked at the idle setting. Wear clothes made of a strong fabric and avoid loose clothing that can catch on twigs and branches. Always wear heavy, long pants. Do not wear jewellery, shorts sandals or go barefoot. - Page 8 GENERAL SAFETY PRECA UTIONS Stop switch Regularly check the vibration damping units for cracks or deformation. Check that the vibration damping element is Use the stop switch to switch off the engine. undamaged and securely attached. WARNING! Overexposure to vibration can lead to circulatory damage or nerve damage in people who have impaired circulation.
- Page 9 GENERAL SAFETY PRECAUTIONS Regularly check that the muffler is securely attached to When the blades are correctly adjusted the play between the machine. the blades should be 0,2–0,4 mm, measured at the screws. The edges of the blades are too hard to be filed. Dull blades should be sharpened using a grinder.
-
Page 10: Fuel Handling
Two-stroke oil supervision and when performing all service measures. • For best results and performance use HUSQVARNA two-stroke engine oil, which is specially formulated for WARNING! Take care when handling fuel. our air-cooled two stroke-engines. Bear in mind the risk of fire, explosion •... -
Page 11: Fueling
FUEL HANDLING Mixing Fueling • Always mix the gasoline and oil in a clean container intended for fuel. • Always start by filling half the amount of the gasoline to be used. Then add the entire amount of oil. Mix WARNING! Taking the following (shake) the fuel mixture. -
Page 12: Starting And Stopping
STARTING AND STOPPING Check before starting Starting and stopping • Inspect the working area. Remove any objects that could be thrown out. WARNING! The complete clutch cover • Check the cutting attachment. Never use blades that and gear housing must be fitted before are dull, cracked or damaged. - Page 13 STARTING AND STOPPING Warm engine Stopping Primer bulb: Press the air purge repeatedly until fuel The engine is switched off by moving the stop switch to begins to fill the bulb. The bulb need not be completely the stop position. filled.
-
Page 14: Working Techniques
WORKING TECHNIQUES General working instructions • Never work from a ladder, stool or any other raised position that is not fully secured. IMPORTANT! This section takes up the basic safety precautions for working with a hedge trimmer. If you encounter a situation where you are uncertain how to proceed you should ask an expert. - Page 15 WORKING TECHNIQUES • When the engine is switched off, keep your hands and Basic working techniques feet away from the cutting attachment until it has • Work with a swinging action from the bottom upwards stopped completely. when trimming sides. •...
-
Page 16: Maintenance
• The T-screw regulates the throttle setting at idle speed. If the T-screw is turned clockwise this gives a Your Husqvarna product has been designed and higher idle speed; turning it anti-clockwise gives a manufactured to specifications that reduce harmful lower idle speed. - Page 17 MAINTENANCE Low speed jet L High speed jet H Try to find the highest idling speed, turning the low speed The high speed jet H affects the engine power, speed, needle L clockwise respectively counter-clockwise. When temperature and fuel consumption. If the high speed jet H the highest speed has been found, turn the low speed is set too lean (screwed in too far) the engine speed will needle L 1/4 turn counter-clockwise.
-
Page 18: Muffler
MAINTENANCE Correctly adjusted carburetor performance of the catalytic converter is impaired. Contact your dealer to inspect the muffler. A blocked When the carburetor is correctly adjusted the machine screen will cause the machine to overheat and result in accelerates without hesitation and burbles a little at damage to the cylinder and piston. -
Page 19: Spark Plug
Use of the wrong spark plug can damage the piston/ cylinder. Check that the spark plug is fitted with a suppressor. Always use HUSQVARNA filter oil, art. no. 531 00 92-48. Air filter The filter oil contains a solvent to make it spread evenly through the filter. -
Page 20: Gear Housing
Use a grease gun to fill with grease. This should be done after every 60 working hours. Use Husqvarna’s special grease, no. 503 98 96-01. CAUTION! The gear housing must not be filled completely with grease. The grease expands as the machine heats up during operation. -
Page 21: Maintenance Schedule
MAINTENANCE Maintenance schedule The following is a list of the maintenance that must be performed on the machine. Most of the items are described in the Maintenance section. The user must only carry out the maintenance and service work described in this manual. More extensive work must be carried out by an authorised service workshop. -
Page 22: Technical Data
TECHNICAL DATA Technical data Technical data 326HD60 326HD75 Engine Cylinder displacement, cu.in/cm 1,55/25,4 1,55/25,4 Cylinder bore, inch/mm 1,34/34 1,34/34 Stroke, inch/mm 1,10/28 1,10/28 Idle speed, rpm 2700 2700 Recommended max. fast idle speed, rpm 10500-12500 10500-12500 Max. engine output, acc. to ISO 8893 0,9/9000 0,9/9000 Catalytic converter muffler... -
Page 23: Federal And California Emissions Control Warranty Statement
If the part fails prior to the first scheduled replacement, Husqvarna Forest & Garden. the part will be repaired or replaced by Husqvarna Forest & Garden at no cost. Any such part repaired or replaced OWNER′S WARRANTY... - Page 24 EPA may not be used. The use of any non-exempted add-on or modified parts will be grounds for disallowing a warranty claim. Husqvarna Forest & Garden will not be liable to warrant failures of warranted parts caused by the use of a non-exempted add-on or modified part.
- Page 28 1151434-95 ´®z+SKQ¶5L¨ ´®z+SKQ¶5L¨ 2008-12-16...
