ACCESSORIES

CHECKING ACCESSORIES

One remote control Two AA batteries
CONNECTING THE DISPLAY TO EXTERNAL EQUIPMENT
Carefully check the terminals for position and type before making any connections.
Loose connectors can result in picture or color problems. Make sure that all connectors are securely inserted into their terminals.
Ferrite cores
These ferrite cores are used to attenuate undesired signals.
Two ferrite cores
When connecting a cable to the power input terminal, RS-232C terminal, attach one of these ferrite cores to the cable near the terminal.
Power Cable
Ferrite Core
E-2
Two user's manuals
RS-232C Cable
Ferrite Core
One power cable Two ferrite cores
(W Type)
(E Type)
(A Type)
