Sealey LED086 Instructions

thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
refer to electrical
instructions shock
Hazard
1. saFety
electrical
1.1.
warning! it is the user's responsibility to read, understand and comply with the following:
‰
warning! tHis Product must Be instAlled BY A QuAlified electriciAn.
‰
You must check all electrical equipment and appliances to ensure they are safe before using. You must inspect power supply leads
9
and all electrical connections for wear and damage.
You must ensure the risk of electric shock is minimised by the installation of appropriate safety devices. An rccB (residual current
9
circuit Breaker) should be incorporated in the main distribution board.
You must also read and understand the following instructions concerning electrical safety.
9
ensure the light is connected to an appropriate electrical on/off switch.
9
ensure the insulation on all cables and the product itself is safe before connecting to the mains power supply.
9
ensure that cables are always protected against short circuit and overload.
9
regularly inspect power supply, leads and all electrical connections for wear and damage, especially power connections, to
9
ensure that none are loose.
ensure the voltage marked on the product is the same as the electrical power supply to be used.
9
do not pull power cable once installed.
8
do not use worn or damaged leads, or connections. immediately replace or have repaired by a qualified electrician.
8
ensure the unit is correctly earthed and wired according to the following. (installation should be undertaken by a qualified electrician)
9
a) connect the green/Yellow earth wire to the earth terminal 'e'.
b) connect the Brown live wire to live terminal 'l'.
c) connect the Blue neutral wire to the neutral terminal 'n'.
After wiring, check there are no bare wires, that all wires have been correctly connected and that the wire restraint is tight.
1.2. general safety
warning! turn off the mains power supply before servicing or performing any maintenance.
‰
Maintain the light in good condition (Repairs must only be undertaken by a qualified electrician).
9
replace or repair damaged parts. use genuine parts only, non authorised parts may be dangerous and will invalidate the warranty.
9
ensure the light is installed correctly in accordance with these instructions.
9
only install the light on a vertical surface.
9
do not fix the light on any horizontal surface i.e. ceiling, or overhang.
8
Ideally the Installation should be away from flammable or combustible materials such as wood, cloth, paper etc.
9
▲ danger! do not direct the light into a persons eyes. this unit has a very intensive light output, which if incorrectly used
could cause eye damage.
do not install the light where it is likely to be knocked or hit.
8
do not install in bathrooms, shower rooms, sauna or such locations.
8
do not install near an exhaust outlet. i.e. Boiler flue, dryer outlet, etc.
8
do not use the light without the front glass shield fitted.
8
2. introduction
mounted in a die-cast powder coated aluminium extra slim housing with wall bracket. SMD LED technology allows ultra bright illumination
whilst keeping costs lower than traditional halogen tubes. even spread of light across a 110° angle. features a motion detector. suitable for
outdoor mounting.
3. sPeciFication
model no:..............................led086..........led087..........led088..........led089
Power:.........................................10w...............20w................50w................70w
lumen output:.........................800ml............1600ml...........3800ml........... 5600ml
supply:.............................230V-50Hz......230V-50Hz.....230V-50Hz......230V-50Hz
colour temperature:................6000K.............6000K............6000K.............6000K
iP rating:.................................. iP54...............iP54...............iP54................iP54
Pir sensor:..................................Yes................Yes.................Yes..................Yes
© Jack sealey limited
instructions for
Floodlight with wall bracket & Pir
sensor 10w / 20w / 50w / 70w smd led
model no: led086 / led087 / led088 / led089
Original Language Version led086/led087/led088/led089 | issue 1 26/05/16
