ADTRAN NETVANTA 3450 Quick Start Manual page 3

C Y
ONFIGURE OUR
More detailed documentation for configuring your ADTRAN unit is provided on the AOS
Documentation CD included in your shipment. For more detail on hardware setup, refer to the
appropriate NIM quick start guides and the hardware installation guide. For more detail on
configuring your system, refer to the AOS Command Reference Guide, configuration guides, and
technical support notes.
Important: For additional details on product features, specifications,
installation, and safety, refer to the appropriate hardware installation
guide on the AOS Documentation CD shipped with the base unit and
available online at www.adtran.com.
C P
ONSOLE INOUTS
Pin
1
2
3
4
5
6
7
8
9
E P
THERNET INOUTS
Pin
1
2
3
4, 5
6
7, 8
Quick Start Guide, 61200823G1-13A, March 2009
A
PPLICATION
Name Description
DCD Data Carrier Detect (output)
RD Receive Data (output)
TD Transmit Data (input)
DTR Data Terminal Ready (input)
SG Signal Ground
— Tied to Pin 1 (output)
— Unused
— Tied to Pin 1 (output)
— Unused
Name Description
TX1 Transmit Positive
TX2 Transmit Negative
RX1 Receive Positive
— Unused
RX2 Receive Negative
— Unused
3
