INSTALLATION AND SET-UP MANUAL
WITH ENHANCED AUDIO ENCLOSURE
GENERAL ................................................................................................................................................
PERSONAL COMPUTERS ..............................................................................................................
Hardware ......................................................................................................................................
Operating System Software ...........................................................................................................
BOARD SET-UP.......................................................................................................................................
ENHANCED AUDIO ENCLOSURE ................................................................................................
Audio System Board......................................................................................................................
Mic Audio ALC Enable/Disable DIP Switch (S1)...................................................................
Digital Pots Settings ...............................................................................................................
SPEAKER ASSEMBLY ....................................................................................................................
Speaker Amp Board ......................................................................................................................
Minimum Volume Level DIP Switch (SW1 Position 1) ..........................................................
Maximum Volume Level DIP Switch (SW1 Position 2).......................................................... 10
RS-422 BOARD.................................................................................................................................. 11
INTERCONNECTING THE EQUIPMENT ........................................................................................... 11
CEC/IMC INTERCONNECTIONS.................................................................................................. 11
Control Data Link ......................................................................................................................... 12
Overview................................................................................................................................ 12
RS-422 Interfacing (Co-Located Hook-Ups) ........................................................................... 12
Interconnections).................................................................................................................... 13
Audio Links .................................................................................................................................. 14
PERSONAL COMPUTER ................................................................................................................ 18
PC-To-Enhanced Audio Enclosure Serial Data Interconnect Cable................................................ 18
Standard PC Keyboard .................................................................................................................. 18
Video Display Monitor.................................................................................................................. 18
ENHANCED AUDIO ENCLOSURE ................................................................................................ 18
Dispatch Keyboard ........................................................................................................................ 18
Desk Mic (if used)........................................................................................................................ 18
Headset Jacks (if used) .................................................................................................................. 18
Boom/Gooseneck Mic (if used)...................................................................................................... 19
Footswitches (if used).................................................................................................................... 19
Speakers (if used).......................................................................................................................... 19
Recorder Outputs (if used)............................................................................................................. 20
Paging Input (if used).................................................................................................................... 20
Relay Outputs (if used).................................................................................................................. 21
ericssonz
ericssonz
C3 MAESTRO™ CONSOLE SYSTEM

TABLE OF CONTENTS

LBI-39101
Page
5
6
6
6
6
6
6
6
7
7
7
7
