- Page 1 OWNER’S MANUAL DLP PROJECTOR Please read this manual carefully before operating your set and retain it for future reference. HX350T www.lg.com...
- Page 2 DLP PROJECTOR DLP PROJECTOR Warning - Class B (b) For a Class B Digital device or peripheral, the instructions furnished the user shall include the fol- lowing or similar statement, placed in a prominent location in the text of the manual: NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
-
Page 3: Table Of Contents
Contents Contents Safety Instructions OPTION Menu Options Selecting Menu Language ............28 Projector Description Selecting Audio Language ............28 Main Body ..................7 Setting Caption ................29 Control Panel ..................7 Using Blank Function ..............30 Connections ..................8 Selecting Blank image ..............30 Remote Control ................9 Screen Capture Function .............31 Installing Batteries ................ -
Page 4: Safety Instructions
Safety Instructions Safety Instructions Please take note of the safety instructions to prevent any potential accident or misuse of the projector. ꔈ Safety Instructions are given in two forms as detailed below. WARNING : The violation of this instruction may cause serious injuries or even death. NOTES : The violation of this instruction may cause injuries or damage to the projector. - Page 5 Safety Instructions Power WARNING Never touch the power plug with Do not plug-in too many items Prevent dust from collecting on a wet hand. into one power outlet. the power plug pins or outlet. This may cause an electric shock It may result in overheating of the out- This may cause a fire hazard! hazard!
- Page 6 Safety Instructions Using WARNING If the projector is in a room that experiences a gas leak, do not touch Always open the lens door or the projector. remove the lens cap when the projector lamp is on. It can cause a fire or a burn by a spark. Using NOTES Do not place heavy objects on...
-
Page 7: Projector Description
Projector Description Projector Description Main Body * The projector is manufactured using high-precision technology. You may, however, see on the Projector screen tiny black points and/or bright points (red, blue, or green). This can be a normal result of the manufacturing process and does not always indicate a malfunction. -
Page 8: Connections
Projector Description Connections Audio Out port AUDIO IN IR (Remote control sensor) * Do not block the IR port for normal operation VIDEO IN of remote control. DC Power IN Kensington Security System Connector HDMI (Refer to page 13) RGB IN ANTENNA IN * Note that clearance is limited between the USB and HDMI inputs. -
Page 9: Remote Control
Projector Description Remote Control INPUT POWER Turns the projector on or off. Access USB. INPUT FLASHBK Changes the input source. AUTO Alphanumeric buttons RATIO Enters letters and numbers. MUTE - (Dash) MENU Inserts a dash between numbers such as INFO MENU Q.MENU Accesses the menu. -
Page 10: Accessories
BLANK Optional Extras * Below are some optional accessories you may need to operate the projector. These are not made or sold by LG. * Contact your dealer to purchase these items. * Optional parts can be changed without notice to improve the quality of the product, and new optional parts can be added. -
Page 11: Installation
Installation Installation Installation Precautions Provide proper ventilation for this projector. • The projector is equipped with ventilation holes(intake) on • Do not place the projector on a carpet, rug or other similar the bottom and ventilation holes(exhaust) on the front. Do surface. -
Page 12: Basic Operation Of The Projector
Installation Basic Operation of the Projector 1 . Place the projector on a sturdy and horizontal surface. 2 . Place the projector with the desired distance from the screen. The distance between the projector and the screen determines the actual size of the image. 3 . -
Page 13: How To Install The Projector Using A Tripod
Installation How to install the projector using a tripod * You can install this projector using a camera tripod. * When stabilizing the tripod, we recommend using the locking bolt of standard size 4.5 mm or less.The maximum size allowed for the locking bolt is 6.5 mm.(If it is longer than the maximum allowed size, it may damage the projector.) Part connected to the projector Part connected to the tripod Bottom side of Projector... -
Page 14: Turning On The Projector
Installation Turning on the Projector 1 . Make sure the power cord is connected correctly. 2 . After wait for a moment, press the POWER button on the top cover or the POWER button on the remote control. (The light on the control panel will be turned on.) Press the INPUT button on the remote control to select the input signal you want. -
Page 15: Connections
Connections Connections Connecting to a Speaker or Headphone Connect the Audio Out port of the projector to headphones or powered speakers. Antenna (Analog or Digital) Connecting to an Antenna or Cable * To prevent damage do not connect to the power outlet until all connections Outdoor Antenna Wall Antenna are made between the devices. -
Page 16: Connecting To A Video Source
Connections Connecting to a Video Source * You can connect a VCR, a camcorder or any other compatible video image source to the projector. < How to connect > Video Cable Audio Cable 1 . Connect the VIDEO IN of the projector to the output jack of the video source with a video cable. -
Page 17: Operating The Projector
Operating the Projector Operating the Projector * The On-Screen Display (OSD) in this manual may be slightly different from your projector. CHANNEL Menu Options Channel Setup - Auto Scan * Automatically finds all channels available through antenna or cable inputs, and stores them in memory on the channel list. Run this function if you change your residence or move the projector. -
Page 18: Channel Editing
Operating the Projector Channel Editing 1 . Press the MENU button. Then, move to CHANNEL with the ∧, ∨, ＜, ＞ buttons and press the ◉OK button. 2 . Press the ∧, ∨ buttons to move Channel Edit and press the ◉OK button. -
Page 19: Brief Information
Operating the Projector Brief Information Press the INFO ⓘ button on the remote control and then show the brief info on the screen. • Press the BACK button to exit the menu screen. Brief Info Title Test.. 6:35 PM Sat, Jul 2, 2011 6:30 PM 7:45 PM ꘋ... -
Page 20: Advanced Control Function
Operating the Projector Advanced Control Function < When Picture Mode is Vivid/Standard/ Cinema/Sport/Game > 1 . Press the MENU button. Then, move to PICTURE with the ∧, ∨, ꔗ ꔃ Color Temperature Medium PICTURE ꔂMove ꔉOK ＜, ＞ buttons and press the ◉OK button. Dynamic Contrast High Picture Mode... -
Page 21: Picture Reset Function
Operating the Projector Standard: Displays standard color area. Color Gamut Wide: Mode to use and set the rich color area of the display. ꔈMaximize the utilization of color to increase color quality. - This function enables Cinema/Expert 1/2. Edge Enhancer ꔈShow clearer and distinctive yet natural corners of the video. -
Page 22: Screen Menu Options
Operating the Projector SCREEN Menu Options To Change PJT Mode * This function turns the projected image upside down or flips horizontal. PJT Mode 1 . Press the Q.MENU button on the remote control. 2 . Press the ＜, ＞ buttons to move PJT Mode. Front 3 . -
Page 23: Auto Configure Function
Operating the Projector Auto Configure Function * This function assures you of getting the best video quality by automatically adjusting the horizontal size and synchronization of the image. * Auto Tracking function works in RGB PC input only. Press the AUTO button of the remote control. •... -
Page 24: Audio Menu Options
Operating the Projector AUDIO Menu Options Adjusting Volume Press the VOL +, - button to adjust the volume. If you want to switch the sound off, press the MUTE button. • You can cancel the mute function by pressing the MUTE, VOL +, - button. •... -
Page 25: Adjusting Speaker Balance
Operating the Projector Adjusting Speaker Balance * Adjust the left/right sound of speaker to suit your taste and room situations. 1 . Press the MENU button. Then, move to AUDIO with the AUDIO ꔂMove ꔉOK ∧, ∨, ＜, ＞ buttons and press the ◉OK button. Volume Balance Treble... -
Page 26: Time Menu Options
Operating the Projector TIME Menu Options Clock Setting * The time is set automatically from a digital channel signal. The digital channel signal includes information for the current time provided by the broadcasting station. Set the clock manually if the current time is set incorrectly by the auto clock function. 1 . -
Page 27: Sleep Time Function
Operating the Projector Sleep time Function Sleep Timer * The sleep timer turns the projector off at the preset time. 1 . Press the Q.MENU button on the remote control. 2 . Press the ＜, ＞ buttons to move Sleep Timer. 3 . -
Page 28: Option Menu Options
Operating the Projector OPTION Menu Options Selecting Menu Language 1 . Press the MENU button. Then, move to OPTION with the ∧, ∨, ＜, ＞ buttons and press the ◉OK button. OPTION ꔂMove ꔉOK Menu Language :English Audio Language :English 2 . -
Page 29: Setting Caption
Operating the Projector Setting Caption 1 . Press the MENU button. Then, move to OPTION with the ∧, ∨, ＜, OPTION ꔂMove ꔉOK ＞ buttons and press the ◉OK button. Menu Language :English ꔗ ꔃ Audio Language :English Caption :Service1 2 . -
Page 30: Using Blank Function
Operating the Projector Using Blank Function * This function may be effective if you need to get the attention of the audience during presentations, meetings or briefings. 1 . Press the BLANK button on the remote control. • The screen turns off to a background color. •... -
Page 31: Screen Capture Function
Operating the Projector Screen Capture Function 1 . Press the MENU button. Then, move to OPTION with the ∧, ∨, ＜, OPTION ꔂMove ꔉOK ＞ buttons and press the ◉OK button. Menu Language :English Audio Language :English Caption :Service1 2 . Press the ∧, ∨ buttons to move Screen Capture and press the Blank Image :Blue ◉OK button. -
Page 32: To Make The Power Of The Projector Turn On Automatically When Power Is Applied
Operating the Projector To make the power of the projector turn on automatically when power is applied 1 . Press the MENU button. Then, move to OPTION with the ∧, ∨, ＜, OPTION ꔂMove ꔉOK ＞ buttons and press the ◉OK button. Menu Language :English Audio Language... -
Page 33: Initial Setting Function
1 . Press the MENU button. Then, move to INFORMATION with INFORMATION ꔂMove ꔉOK the ∧, ∨, ＜, ＞ buttons and press the ◉OK button. Model Name : HX350T Input : TV Resolution 2 . You can see the current information of the projector. -
Page 34: Parental Control/Ratings
PARENTAL CONTROL/RATINGS PARENTAL CONTROL/RATINGS * Parental Control can be used to block specific channels, ratings and other viewing sources. The Parental Control Function (V-Chip) is used to block program viewing based on the ratings sent by the broad- casting station. The default setting is to allow all programs to be viewed. Viewing can be blocked by choosing the type of the program and the categories. -
Page 35: Set Password
PARENTAL CONTROL/RATINGS Set Password * Change the password by inputting a new password twice. 1 . Press the MENU button. Then, move to LOCK with the ∧, ∨, ＜, ＞ LOCK ꔂMove ꔉOK buttons and press the ◉OK button. Lock System :Off Set Password Block Channel... -
Page 36: Channel Blocking
PARENTAL CONTROL/RATINGS Channel Blocking * Blocks any channels that you do not want to watch or that you do not want your children to watch. 1 . Press the MENU button. Then, move to LOCK with the ∧, ∨, ＜, ＞ LOCK ꔂMove ꔉOK buttons and press the ◉OK button. -
Page 37: Tv Rating Children - For Usa
PARENTAL CONTROL/RATINGS TV Rating Children - For USA * Prevents children from watching certain children's TV programs, according to the ratings limit set. The children rating does not apply to other TV programs. Unless you block certain TV programs intended for mature audiences in the TV Rating - sub menu, your children can view those programs. -
Page 38: Tv Rating English - For Canada
PARENTAL CONTROL/RATINGS TV Rating English - For CANADA * Selecting Canadian English rating system. 1 . Press the MENU button. Then, move to LOCK with the ∧, ∨, ＜, LOCK ꔂMove ꔉOK ＞ buttons and press the ◉OK button. Lock System Set Password Block Channel 2 . -
Page 39: Downloadable Rating
PARENTAL CONTROL/RATINGS Downloadable Rating * This function is available only for digital channels. This function operates only when projector has received Region5 Rating data. 1 . Press the MENU button. Then, move to LOCK with the ∧, ∨, ＜, LOCK ＞... -
Page 40: Usb
* Image shown may differ from your projector. To use the USB device Connecting the USB device 1 . Connect the USB device to the USB jack on the back of the projector. 2 . The USB media menu will open automatically. PHOTO LIST MOVIE LIST FILE VIEWER... -
Page 41: Usb Notes
USB notes ► Only a USB storage device is recognizable. ► USB hubs are not supported. ► A USB storage device which uses its own driver may not be recognized. ► The recognition speed of a USB storage device will depend on each device. ►... -
Page 42: Photo List
PHOTO LIST * The projector can display JPEG files. The On Screen Display may be different from your set. Images are an example to assist with the projector operation. PHOTO(*.JPEG) supporting file Baseline : 64 x 64 - 15360 x 8640 Progressive : 64 x 64 - 1920 x 1440 •... -
Page 43: Full Screen Menu
Full Screen Menu 1 . Press the USB button. Then, move to PHOTO LIST with the ＜, ＞ buttons and press the ◉OK button. 2 . Press the ∧, ∨, ＜, ＞ buttons to move desired photo and press the ◉OK button. 3 . -
Page 44: Music List
MUSIC LIST * You can use the Music List menu to play MP3 files from a USB storage device. The On Screen Display on your model may be slightly different. MUSIC (*.MP3) supporting file Bit rate range 32 Kbps - 320 Kbps •... -
Page 45: Movie List
MOVIE LIST * The movie list is activated once USB is detected. It is used when playing movie files on projector. Supported Movie Formats Extension name Video Codec Audio Codec Max Resolution mpg, mpeg, vob MPEG1, MPEG2 Dolby Digital,MPEG,MP3,LPCM MPEG1 Dolby Digital,MPEG,MP3,LPCM ts,trp,tp MPEG2, H.264/AVC... -
Page 46: Precautions When Playing Video Files
Precautions When Playing Video Files ► A DivX movie file and its subtitle file must be located in the same folder. ► At this time, a movie file name and its subtitle file name must be identical for it to be displayed. ►... -
Page 47: Screen Components
Screen Components 1 . Moves to upper level folder MUSIC LIST Page 1/1 No Marked 2 . Preview: Display the title/folder name of the movie in the Movie Title Duration selected folder Up Folder 3 . Current page/Total pages 4 . Total number of marked movies 5 . -
Page 48: Playing The Movie
Playing the Movie * You can adjust various method during the movie play. 1 . Press the USB button. Then, move to MOVIE LIST with the ＜, ＞ buttons and press the ◉OK button. 2 . Press the ∧, ∨, ＜, ＞ move to a desired movie file and press the ◉OK button. -
Page 49: To See The Divx Registration Code
To See The DivX Registration Code * Confirm the DivX registration code number of the projector. Using the registration number, movies can be rented or purchased at www.divx.com/vod. 1 . Press the MENU button. Then, move to USB with the ∧, ∨, ＜, ＞ ꔂMove ꔉOK buttons and press the ◉OK button. -
Page 50: File Viewer
FILE VIEWER Supported File : XLS, DOC, PPT, TXT, XLSX, PPTX, DOCX, PDF • Microsoft Office Version 97 / 2000 / 2002 / 2003 / 2007 • Adobe PDF Version 1.0 / 1.1 / 1.2 / 1.3 / 1.4 - File Viewer realigns the document, so it may look different than when viewed on a PC. - For the documents that include images, the resolution may look lower during the realigning process. -
Page 51: Information
Information Information Supported Monitor Display * The following table lists the display formats supported by the projector. Format Vertical Freq.(Hz) Horizontal Freq.(kHz) * If the projector does not support the input signal, “Invalid Format” message appears on the screen. * The projector supports DDC1/2B type as Plug & Play. -
Page 52: Specifications
(Screen size) Projection Offset 110 % Remote control distance Video compatibility NTSC AC-DC Adapter LG, SD-B191A, 19.5 V , 5.64 A Audio Output 1 W + 1 W Television System NTSC-M, ATSC, 64 & 256 QAM Program Coverage VHF 2 - 13, UHF 14 - 69, CATV 1 - 135, DTV 2 - 69, CADTV 1 - 135 External Antenna Impedance 75 Ω... -
Page 53: Open Source Software Notice
MPL LIBRARIES: nanox LG Electronics offers to provide source code to you on CD-ROM for a charge covering the cost of performing such distribution, such as the cost of media, shipping and handling upon e-mail request to LG Electronics at: opensource@lge.com This offer is valid for a period of three (3) years from the date of the distribution of this product by LG Electronics. - Page 54 The model and serial number of the projector is LG Customer Information Center located on the back or one side of the projector. Record it below should you ever need service. 1-800-243-0000 USA, Consumer User 1-888-865-3026 USA, Commercial User MODEL...
