273 Branchport Avenue
Long Branch, NJ 07740
(800) 631-2148
www.wheelockinc.com
SERIES AH-WP INDOOR/OUTDOOR AUDIBLE HORN APPLIANCES
Use this product according to this instruction manual. Please keep this instruction manual for future reference.
GENERAL:
Wheelock's AH-WP Audible Horn Appliances are designed to provide a selectable continuous horn or code 3 tone when
connected directly to the Fire Alarm Control Panel (FACP), or provide a synchronized code 3 horn when used in conjunction
with a Sync Module (SM), Dual Sync Module (DSM) or Wheelock's Power Supplies. The AH-WP Appliances are UL Listed
under UL Standard 464 for Audible Signal Appliances. The AH-24WP is ULC Listed under Standard CAN/ULC-S525-99 for
Audible Signaling Appliances. They are listed for indoor and outdoor use and can be mounted to a 4" backbox (See Mounting
Options).
AH-WP Appliances can be field set to provide either High (HI) dBA, Medium (MED) dBA or Low (LO) dBA sound output.
All AH-WP models are designed for use with either filtered DC (VDC) or unfiltered Full-Wave-Rectified (FWR) input voltage.
All inputs are polarized for compatibility with standard reverse polarity supervision of circuit wiring by a FACP.
NOTE: The code 3 horn incorporates the temporal pattern (1/2 second on, 1/2 second off, 1/2 second on, 1/2 second off, 1/2
second on, 1-1/2 off and repeat) specified by ANSI/NFPA for standard emergency evacuation signaling. The code 3 horn shall
be used only for fire evacuation signaling and not for any other purpose.
NOTE: All CAUTIONS and WARNINGS are identified by the symbol
WARNING: THE AH-WP APPLIANCE IS A "FIRE ALARM DEVICE - DO NOT PAINT."
WARNING:
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING THIS PRODUCT.
FAILURE TO COMPLY WITH ANY OF THE FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS
COULD RESULT IN IMPROPER APPLICATION, INSTALLATION AND/OR OPERATION OF THESE
PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT IN PROPERTY DAMAGE AND
SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.
SPECIFICATIONS:
Regulated
Model
Voltage
(VDC/VRMS)
AH-24WP
24
AH-12WP
12
Copyright 2005 Wheelock, Inc. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
Table 1: UL/ULC Listed Models and Ratings
UL Voltage
ULC Voltage
Range
Range
(VDC/VRMS)
(VDC/VRMS)
16-33
20-31
8-17.5
-----
Model AH-12WP is not ULC listed.
Table 1A: ULC Current Ratings 24VDC Models
Model
ULC Voltage
(VDC/VRMS)
AH-24
20.0
24.0
31.0
. All warnings are printed in bold capital letters.
Maximum RMS Current (AMPS)
DC
Lo
Med
Hi
0.021
0.043
0.080
0.058
0.108
0.192
Average Current (AMPS)
Lo
Med
Hi
.014
.020
.035
.017
.025
.050
.021
.030
.065
FWR
Lo
Med
Hi
0.041
0.051
0.090
0.059
0.109
0.209
P83641 J
Sheet 1 of 6
