FIRE ALARM SYSTEMS
Description
The Series NS Horn Strobe Appliances will satisfy virtually
all requirements for indoor, wall mount applications.
The Series NH Horn and the horn portion of the Series NS
includes a selectable continuous horn tone or temporal
pattern (Code 3) with selectable dBA settings of 90 or 95
dBA.
Strobe options include Wheelock's patented Multi-Candela
strobe with field selectable candela settings of: 15, 30, 75
or 110cd.
These versatile Horn Strobe Appliances may be
synchronized when used in conjunction with the Wheelock
SM or DSM Sync Module(s). Additionally, the audible
may be silenced while maintaining strobe activation.
All models of the Series NS are designed for maximum
performance, reliability and cost effectiveness while
meeting or exceeding the latest requirements of
CAN/ULC-S526-02 for Visual Signaling Appliances and
CAN/ULC-S525-99 for Audible Signaling Appliances.
Wheelock's patented 2-Wire Series NS Horn Strobes and
Series NH Horns offer more features with less current draw.
Your Choice
•
NS models are available in 2-Wire, 24 VDC
•
NS models are available with Wheelock's patented
Multi-Candela Strobe that offers field selectable
candela settings of: 15, 30, 75 or 110 cd
Copyright 2005 Wheelock Inc. All rights reserved.
Helping People Take Action
SERIES NS
SINGLE & MULTI-CANDELA
HORN STROBE APPLIANCES
SERIES NH HORNS
Series NH
Multi-Candela Indicator
(bottom of Strobe Lens)
Features
•
Approvals include: CAN/ULC-S526-02 for Visual
Signaling Appliances and CAN/ULC-S525-99 for
Audible Signaling Appliances
•
ADA/NFPA/ANSI compliant
•
Meets OSHA 29 Part 1910.165
•
Field Selectable Candela Settings: 15, 30, 75 or
110 cd. (Multi-Candela models)
•
Selectable Continuous Horn or Temporal (Code 3)
•
2 Selectable dBA settings of 90 and 95 dBA in
both tones
•
Patented Universal Mounting Plate
•
Filtered DC or unfiltered VRMS input voltage
•
Wall Mount
•
Synchronize with Wheelock SM or DSM Sync
Module(s)
•
Fast installation with IN/OUT screw terminals
using #12 to #18 AWG wires
•
Backward compatible with other Wheelock
Appliances
I N C .
SM
Series NS
2
Advertisement
Related Manuals for Wheelock Series NH
Summary of Contents for Wheelock Series NH
- Page 1 Series NS all requirements for indoor, wall mount applications. The Series NH Horn and the horn portion of the Series NS includes a selectable continuous horn tone or temporal pattern (Code 3) with selectable dBA settings of 90 or 95 dBA.
-
Page 2: General Notes
Series NS Strobe products are listed for indoor use with a temperature range of 0°C to 49°C (32°F to 120°F) and maximum humidity of 93% (± 2%). • Series NH horns are listed for audible signal appliances (Indoor use only). • All Canadian Installations should be in accordance with the Canadian Standard for the Installation of Fire Alarm Systems - CAN/ULC-S524-01 and Canadian Electrical Code, Part 1. - Page 3 WARNING: CONTACT WHEELOCK FOR THE CURRENT INSTALLATION INSTRUCTIONS (P83983) SERIES NS-24MCW, (P84030) SERIES NS 24 VDC SINGLE CANDELA MODELS, (P83984) SERIES NH (P83600) AND “GENERAL INFORMATION” SHEET (P82380) ON THESE PRODUCTS. THESE DOCUMENTS UNDERGO PERIODIC CHANGES. IT IS IMPORTANT THAT YOU HAVE CURRENT INFORMATION ON THESE PRODUCTS.
- Page 4 ARCHITECTS AND ENGINEERS SPECIFICATIONS The audible/visual notification appliances shall be Wheelock Series NS Horn Strobe appliances and Series NH Horn appliances or ULC Listed under Standard approved equals. The Series NS appliances shall meet and be CAN/ULC-S526-02 for Visual Signaling Appliances and CAN/ULC-S525-99 for Audible Signaling Appliances.
