- Page 1 OWNER’S MANUAL MONITOR SIGNAGE Please read this manual carefully before operating the your set and retain it for future reference. MONITOR SIGNAGE MODEL 47VX30MF www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS CONTENTS LICENSES ASSEMBLING AND PREPARING Unpacking Parts and buttons Portrait Layout Installing on a wall REMOTE CONTROL USING THE MONITOR SET Connecting to a PC - Using the input list - RGB connection - HDM/DVI connection - HDMI connection CUSTOMIZING SETTINGS Accessing main menus - PICTURE settings - AUDIO settings - TIME settings - OPTION settings - TILE settings ENTERTAINMENT Using integrated media features - Connecting USB storage devices... -
Page 3: Licenses
LICENSES Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays DivX video. Visit divx.com for more information and software tools to convert your files into DivX videos. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration. DivX Certified® to play DivX® video, including premium content. DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license. Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274 LICENSES... -
Page 4: Assembling And Preparing
ASSEMBLING AND PREPARING ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. POWER MONITOR ENERGY INPUT SAVING . , ! PQRS WXYZ 1/a/A CLEAR - * # MARK BRIGHT NESS MUTE MENU AUTO S.MENU BACK EXIT TILE Remote control and Batteries CD (Owner's Manual) / Card CAUTION Do not use any pirated items to ensure the safety and product life span. -
Page 5: Parts And Buttons
Parts and buttons RS-232C HDMI / DVI RGB IN (CONTROL) RGB OUT Screen Marks INPUT Changes the input source. MENU Accesses the main menus, or saves your input and exits the menus. ▼▲ Adjust the up and down. ◄ ► Adjusts the volume level. AUTO/SET Auto setup when using RGB input. It is also the Set or enter button to make changes in the on-screen menus. Turns the power on or off. / I IR Receiver This is where the unit receives signals from the remote control. Power Indicator This Indicator lights up blue when the display operates normally(on mode). If the display is in sleep (Energy Saving) mode, this indicator color changes to amber. NOTE You can set the Power indicator to on or off by selecting OPTION in the main menu. AUDIO COMPONENT IN AV IN / OUT (RGB/DVI) VIDEO AUDIO... -
Page 6: Portrait Layout
ASSEMBLING AND PREPARING Using the FFC/IR PCB Remove the securing tape first. Do not pull out the FFC, as this may cause damage. Be careful not to damage the product during installation. Using the Kensington security system The Kensington security system connector is located at the back of the Monitor set. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com . Connect the Kensington security system cable between the Monitor set and a table. NOTE The Kensington security system is optional. You can obtain additional accessories from most electronics stores. Portrait Layout - Only on some models. When installing in a Portrait Layout, rotate the monitor clockwise 90 degrees (when facing the screen). Installing on a wall Install the monitor at least 10 cm away from the wall and leave about 10 cm of space at each side of the monitor to ensure sufficient ventilation. De-... - Page 7 If you use improper screw, the product might be damaged and drop from mounted position. In this case, LG Electronics is not responsible for it. VESA compatible. Please use VESA standard as below. 785mm(31 inch) or greater * Fastening screw: Diameter 6.0 mm x Pitch 1.0 mm x Length 10 mm (32 inch is Diameter 4.0 mm x Pitch 0.7 mm x Length 10 mm) Model 47VX30MF VESA (A x B) 800 x 600 Standard screw Number of screws VESA (A x B) ASSEMBLING AND PREPARING CAUTION Disconnect the power cord first, and then move or install the Monitor set. Otherwise electric shock may occur. If you install the Monitor set on a ceiling or slanted wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. D o not over tighten the screws as this may cause damage to the Monitor set and void your warranty.
-
Page 8: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the Monitor set correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse. CAUTION Do not mix old and new batteries, as this may damage the remote control. Make sure to point the remote control to the remote control sensor on the Monitor set. (POWER) Turns the Monitor set on or off. POWER MONITOR ON / OFF Turn off the monitor and then ENERGY INPUT MONITOR turn it back on. SAVING . , ! 1/a/A Button This button selection is not PQRS WXYZ applicable. 1/a/A CLEAR - * # MARK Selects the Aspect Ratio... - Page 9 MENU (See p.13) Accesses the main menus or saves your input and exit menus. Navigation buttons Scrolls through menus or options. Selects menus or options and confirms your input. BACK Allows the user to move return one step in an interactive application.
-
Page 10: Using The Monitor Set
USING THE MONITOR SET USING THE MONITOR SET Connecting to a PC Your Monitor set supports the Plug & Play* feature. * Plug & Play: The function when a PC recognizes a connected device that users connect to a PC and turn on, without device configuration or user intervention. NOTE It is recommended to use the Monitor set with an HDMI connection for the best image quality. If you turn the Monitor set on when cold, the screen may flicker. This is normal. Some red, green, or blue spots may appear on the screen. This is normal. CAUTION Connect the signal input cable and tighten it by turning the screws clockwise. Do not press the screen with your finger for a long time as this may result in temporary distortion on the screen. Avoid displaying a fixed image on the screen for a long period of time to prevent image burn. Use a screensaver if possible. Using the input list Selecting an input source Press INPUT to access the input source list. -
Page 11: Rgb Connection
RGB connection Transmits the analog video signal from your PC to the Monitor set. Connect the PC and the Monitor set with the D-sub 15 pin cable as shown the following illustrations. Select RGB input source. PC/MAC Macintosh Adapter (not included) Back of the product. NOTE Apple computers may require an adapter to connect to this monitor. Call or visit their web site for more information. HDM/DVI connection Transmits the digital video signal from your PC to the Monitor set. Connect the PC and the Monitor set with the HDMI/DVI cable as shown the following illustrations. Select HDMI/DVI input source. (not included) NOTE When using computer input with HDMI, you must set the label of that HDMI input to PC. Use a shielded signal interface cable, such as D-sub 15 pin signal cable and DVI to HDMI cable, with a ferrite core to maintain standard compliance for the product. USING THE MONITOR SET (not included) Back of the product. -
Page 12: Hdmi Connection
USING THE MONITOR SET HDMI connection Transmits the digital video and audio signals from your PC to the Monitor set. Connect the PC and the Monitor set with the HDMI cable as shown in the following illustrations. Select HDMI/DVI input source. (not included) HDMI/DVI Back of the product. NOTE Use a High Speed HDMI™ Cable. Please check the PC environment if you cannot hear the sound in HDMI mode. Some PCs require you to manually change the default audio output to HDMI. If you want to use HDMI-PC mode, you must set the input label to PC mode. -
Page 13: Customizing Settings
CUSTOMIZING SETTINGS Accessing main menus Press MENU to access the main menus. Press the Navigation buttons to scroll to one of the following menus and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. When you are finished, press EXIT. When you return to the previous menu, press BACK. PICTURE (See p.14) Adjusts the image size, quality, or effect. OPTION (See p.21) Customizes the general settings. AUDIO (See p.19) Adjusts the sound quality, effect, or volume level. PICTURE AUDIO TIME OPTION TILE TILE (See p.23) Adjusts the tile options. CUSTOMIZING SETTINGS MARK BRIGHT NESS MUTE AUTO S.MENU MENU BACK EXIT TILE TIME (See p.20) -
Page 14: Picture Settings
CUSTOMIZING SETTINGS PICTURE settings Press MENU to access the main menus. Press the Navigation buttons to scroll to PICTURE and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available picture settings are described in the following: Setting Aspect Ratio Changes the image size to view images at its optimal size (See p.17 to p.18). Energy Saving Sets to automatically adjust the screen brightness corresponding to the surroundings. Level 100% light Level 1 80% light Level 2 60% light Level 3 40% light NOTE If the 'Picture Mode' is set to 'Cinema', the 'Energy saving' mode is disabled. Picture Mode Selects one of the preset image or customizes options in each mode for the best Monitor set screen performance. You are also able to customize advanced options of each mode. The available preset picture modes vary depending on the Monitor set . - Page 15 Setting SCREEN Customizes the PC display options in RGB mode. (In RGB Option Mode Only) Resolution Selects a proper resolution. See “Customizing PC display options”. Auto Config. Sets to adjust the screen position, clock, and phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress. Position/Size/ Adjusts the options when the picture is not clear, especially when characters are Phase shaky, after the auto configuration. Reset Restores the options to the default setting. Basic image options Setting Backlight A djusts the brightness of the screen by controlling the LCD backlight. If you decrease the brightness level, the screen becomes darker and the power consumption will be reduced without any video signal loss. Contrast Increases or decreases the gradient of the video signal. You may use Contrast when the bright part of the picture is saturated. Brightness Adjusts the base level of the signal in the picture. You may use Brightness when the dark part of the picture is saturated. Sharpness Adjusts the level of crispness in the edges between the light and dark areas of the picture. The lower the level, the softer the image. Color Adjusts intensity of all colors. Tint Adjusts the balance between red and green levels.
- Page 16 CUSTOMIZING SETTINGS Advanced image options Setting Colour Set to warm to enhance hotter Colors such as red, or set to cool to make picture bluish. Temperature Option Cool Medium Warm Dynamic Adjusts the contrast to keep it at the best level according to the brightness of the screen. The Contrast picture is improved by making bright parts brighter and dark parts darker. (This function can be used only under AV(CVBS) and Component.) Dynamic Color Adjusts screen Colors so that they look livelier, richer and clearer. This feature enhances hue, saturation and luminance so that red, blue, green and white look more vivid. (This function can be used only under AV(CVBS) and Component.) Noise R educes screen noise without compromising video quality. (This function can be used only under Reduction AV(CVBS) and Component.) Gamma Set your own gamma value. On the monitor, high gamma values display whitish images and low gamma values display high contrast images. Black Level » Low: The picture of the screen gets darker. » High: The picture of the screen gets brighter. Set black level of the screen to proper level. ( Function works in the following mode - AV(CVBS), Component, HDMI-DTV) Film Mode You can watch a cinema-like video by eliminating judder effect.
- Page 17 Aspect Ratio Resize the image to view the image at its optimal size by pressing ARC button. CAUTION If a fixed image displays on the screen for a long period of time, it will be imprinted and become a permanent disfigurement on the screen. This is “image burn” or “burn-in” and not covered by the warranty. If the aspect ratio is set to 4:3 for a long period of time, image burn may occur on the letterboxed area of the screen. - 16:9 : The following selection will allow you to adjust the picture horizontally, in linear proportion, to fill the entire screen(useful for viewing 4:3 formatted DVDs). - Just Scan : Following Selection will lead to you view the picture of best quality without loss of original picture in high resolution image. Note: If there is noise in original Picture, You can see the noise at the edge. Just Scan CUSTOMIZING SETTINGS - Original : The aspect ratio is not adjusted from the original. It is set by the program being watched. Original - 4:3 : The following selection will allow you to view a picture with an original 4:3 aspect ratio, black bars will appear on both the left and right of the screen. - 1:1 : The aspect ratio is not adjusted from the original. (Only HDMI/DVI PC, RGB PC) - 14:9...
- Page 18 CUSTOMIZING SETTINGS - Zoom : The following selection will allow you to view the picture without any alteration, while filling the entire screen. However, the top and bottom of the picture will be cropped. - Cinema Zoom 1 : Choose Cinema Zoom when you want to enlarge the picture in correct proportion. Note: When enlarging or reducing the picture, the image may become distorted. - Full Wide : When Monitor set receives the wide screen signal,it will lead you to adjust the picture horizontally or vertically, in a linear proportion,to fill the entire screen fully. Full Wide MODE AV Component HDMI/DVI 16:9 Just Scan Original 14:9 Zoom Cinema Zoom 1 Full Wide...
-
Page 19: Audio Settings
AUDIO settings Press MENU to access the main menus. Press the Navigation buttons to scroll to AUDIO and press Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available audio options are described in the following: Setting Auto Volume To adjust uneven sound volumes across all channels or signals automatically to the most appropriate level. To use this feature, select On. Clear Voice ll By differentiating the human sound range from others,it helps users listen to human voices better. Balance Adjusts balance between the left and right speakers according to your room environment. Sound Mode Selects one of the preset sound modes or customize each option in each mode. Mode Standard Music Cinema Sport Game CUSTOMIZING SETTINGS AUDIO Auto Volume Auto Volume Clear Voice II Balance Sound Mode Description... -
Page 20: Time Settings
CUSTOMIZING SETTINGS TIME settings Press MENU to access the main menus. Press the Navigation buttons to scroll to TIME and press Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available time settings are described in the following: Setting Clock Sets the time feature. On/Off Time Sets the time to turn on or off the Monitor set. Sleep Timer Sets the length of time until the Monitor set to turns off. When you turn the Monitor set off and turn it on again, the Sleep Timer will be set to off. Auto off If Auto off is active and there is no input signal, the set switches to off mode automatically after 15 minutes. Power on delay When connecting multiple monitors and turning the power on, the monitors are turned on individually to prevent overload. Automatic Standby If you do not use the monitor for more than 4 hours, it will be in standby mode automatically. NOTE Once the on or off time is set, these functions operate daily at the preset time. The scheduled power-off function works properly only when the device time is set correctly. When the scheduled power-on and power-off times are the same, the power-off time has priority over the power-on time if the set is turned on, and vice versa if the set is turned off. The 'Automatic Standby' function may not be available depending on the country. TIME Clock Clock... -
Page 21: Option Settings
OPTION settings Press MENU to access the main menus. Press the Navigation buttons to scroll to OPTION and press Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available option settings are described in the following: Setting Language To choose the language in which the control names are displayed. Input Label Selects a label for an input source to identify a device connected to each input source. NOTE If you want to use HDMI-PC mode, you must set the input label to PC mode. Key Lock Use the buttons to select On or Off. The monitor can be set up so that it can only be used with the remote control. This feature can prevent unauthorized viewing. In order to lock the OSD screen adjustment, set the Key Lock tab to the 'On' position. In order to unlock it, do the following : Push the MENU button on the remote control and set Key Lock to the 'Off' position. Set ID You can assign a unique Set ID NO (name assignment) to each product when several products are connected for display. Specify the number (1 to 99) using the button and exit. Use the assigned Set ID to individually control each product using the Product Control Program. ISM Method A frozen or still picture from a PC/Video game displayed on the screen for prolonged periods could result in a ghost image remaining even when you change the image. Avoid allowing a fixed image to remain on the screen for a long period of time. Setting Normal Orbiter Inversion White Wash DPM Select A user can choose to turn the power saving mode on / off. - Page 22 CUSTOMIZING SETTINGS Setting Interface Select Sets up network connections. Option RS-232C Network Network Setup Option DHCP Manual Information You can find informations about Serial No, F/W version, IP Address and MAC Address. Factory Reset Select this option to return to the default factory settings. Description Enables communication via Serial. LAN - Enables communication via Ethernet. Allocates and sets up IP automatically. Sets up IP address, Gateway, Subnet Mask, Primary DNS and Secondary DNS. The setup process is complete when you select Execute, and "IP Setup Completed" is displayed at the bottom of the screen. While "Wait for IP Setup"...
-
Page 23: Tile Settings
TILE settings Press MENU to access the main menus. Press the Navigation buttons to scroll to TILE and press Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available lock settings are described in the following: Setting Tile Mode To use this function - Must be displayed with various other products. - Must be in a function that can be connected to RGB Cable by distributor and RS-232C. Tile mode and choose Tile alignment and set the ID of the current product to set location. * Only after pressing the SET button the adjustments made to the settings will be saved. - Tile mode : column x row ( c = 1, 2, 3, 4, 5 r = 1, 2, 3, 4, 5) - 5 x 5 available. - Configuration of an integration screen is also available as well as configuration of One by one Display. Tile ID Select the location of the Tile by setting an ID. Natural The image is omitted by the distance between the screens to be naturally shown. H-Size Adjust the horizontal size of the screen taking into account the size of the bezel. V-Size Adjust the vertical size of the screen taking into account the size of the bezel. H-Position Moving the screen position horizontally. V-Position Moving the screen position vertically. Reset Function to initialize and release Tile. All Tile setting are released when selecting Tile recall and the screen returns to Full screen. CUSTOMIZING SETTINGS TILE Tile Mode : 2x2... - Page 24 CUSTOMIZING SETTINGS Tile Mode This monitor can be tiled with additional monitors to create a large tiled display. • 2X1: • Off: When using 2 monitors When the Tile Mode option is disabled ID 1 Tile ID • 4X4: When using 16 monitors ID 1 ID 3 ID 4 ID 2 ID 6 ID 5 ID 7 ID 8 ID 10 ID 11 ID 12 ID 9 ID 15 ID 16 ID 14 ID 13 Tile Mode - Natural mode When active, the part of the image that would normally be displayed in the gap between the monitors is omitted. Before • 2X2: When using 4 monitors ID 2 ID 1 ID 2...
-
Page 25: Entertainment
ENTERTAINMENT Using integrated media features Connecting USB storage devices Connect USB storage devices such as a USB flash memory, external hard drive, or MP3 player to the Monitor set and use multimedia features (“Browsing files” See p.26). Connect a USB flash memory or USB memory card reader to the Monitor set as shown on the following illustration. The USB screen appears. To disconnect a USB storage device, make sure to end the connection properly to prevent damages to the Monitor set or files. CAUTION Do not turn the Monitor set off or remove a USB storage device while the USB storage device is connected to the Monitor set, as this could result in loss of files or damage to the USB storage device. Back up your files saved on a USB storage device frequently, as you may lose or damage the files and this may be not covered by the warranty. ENTERTAINMENT Precautions when using the USB device Only a USB storage device is recognizable. If the USB storage device is connected through a USB hub, the device is not recognizable. -
Page 26: Browsing Files
ENTERTAINMENT recognized as a file name. Please back up the important file because a data of USB device may be damaged. Data management is consumer's responsibility and in consequence the manufactures does not cover the product bearing data damage. If the USB is connected in Standby Mode, specific hard disk will automatically be loaded when the Set is turned on. The recommended capacity is 1TB or less for a USB external hard disk and 32GB or less for USB memory. Any device with more than the recommended capacity may not work properly. If a USB external hard disk with a “Power Saving” function does not work, turn the hard disk off and on again to make it work properly. Names and subtitles of some language files may not display properly.(Korean, Chinese, Japanese) When using Korean or Chinese subtitles or file names, it is recommended to set the language to the corresponding one. Browsing files Access the Photo, Music or Movie lists and browse files. Connect a USB storage device. Press MENU to access the main menus. Press the Navigation buttons to scroll to USB and press OK. Press the Navigation buttons to scroll to PHOTO LIST, MUSIC LIST or MOVIE LIST and press OK. PHOTO LIST MUSIC LIST Photo List Music List... -
Page 27: Supported File Format
Select a folder you want. - To return to the previous level, select Folder. Photo List Page 1/1 No Marked HR101 Drive 1 HR103 HR105 0 folder(s), 0 file(s) Up Folder Navigation Option Page Change Press the Navigation buttons to browse files. The highlighted file will display in the preview window. Photo List Page 2/3 No Marked Drive 1 Up Folder JMJ001 HR101 02/21/2010 HR102 02/21/2010 JHR001... -
Page 28: Viewing Photos
ENTERTAINMENT Viewing Photos View image files saved in a USB storage device. The displays on the screen may differ from the model. Press the Navigation buttons to scroll to USB and press OK. Press the Navigation buttons to scroll to Photo List and press OK. Press the Navigation buttons to select Drive1 to access the connected USB storage device. Press the Navigation buttons to scroll to a folder you want and press OK. Press the Navigation buttons to scroll to a file you want and press OK. A pop-up window will appears. Photo List Page 2/3 No Marked Drive 1 Up Folder JHR001 HR101 02/21/2010 1366x768, 125KB HR102 02/21/2010 View JHR001 02/21/2010 Mark All JHR002 02/21/2010 Delete 1366x768, 125KB... -
Page 29: Listening To Music
Listening to Music Press the Navigation buttons to scroll to USB and press OK. Press the Navigation buttons to scroll to Music List and press OK. Select Drive1 to access the connected USB storage device. Press the Navigation buttons to scroll to a folder you want and press OK. Press the Navigation buttons to scroll to a file you want and press OK. A pop-up window will appears. Music List Page 2/3 No Marked Music Title S003 Up Folder 4395KB 1Kbps S001 Play S002 Play with Photo Mark All S003 Delete 00:00/01:34 S004 Close Up Folder S005 Navigation... -
Page 30: Viewing Movies
ENTERTAINMENT Viewing Movies Play video files on the Monitor set. Your Monitor set displays all of the video files saved in a USB storage device. Movie (*.dat / *.mpg / *.mpeg / *.vob/ *.m4v / *.avi / *.divx) supporting file. Video format: MPEG1, MPEG2, MPEG4(Doesn’t support Microsoft MPEG 4-V2, V3), DivX 3.xx, DivX 4.xx, DivX 5.xx, DivX VOD(DRM), XviD, DivX 6.xx(Playback) Audio format: Mpeg, Mp3, PCM Bit rate: within 32 kbps to 320 kbps (MP3) Subtitle format: *.smi / *.srt / *.sub (Micro DVD, SubViewer 2.0) / *.ass / *.ssa / *.txt (DVD Subtitle System). Some user-created subtitles may not work properly. Some special characters are not supported in subtitles. HTML tags are not supported in subtitles. Subtitles in languages other than the supported languages are not available. Time information in an external subtitle file should be arranged in ascending order to be played. The screen may suffer temporary interruptions (image stoppage, faster playback, etc.) when the audio language is changed. A damaged movie file may not be played correctly, or some player functions may not be usable. Movie files produced with some encoders may not be played correctly. If the video and audio structure of recorded file is not interleaved, either video or audio is outputted. HD videos with a maximum of 1920 x 1080 @ 25/30P or 1280 x 720 @ 50/60P are supported, depending on the frame. - Page 31 Press the Navigation buttons to scroll to USB and press OK. Press the Navigation buttons to scroll to Movie List and press OK. Select Drive1 to access the connected USB storage device. Press the Navigation buttons to scroll to a folder you want and press OK. Press the Navigation buttons to scroll to a file you want and press OK. A pop-up window will appears. Movie List Page 2/3 No Marked Movie Title M002 Up Folder Play Favorite Music M001 Mark All M002 Delete 640x480, 720KB M001 Close Up Folder M001 Navigation Option Page Change Mark MARK Play video by using the following menus.
- Page 32 ENTERTAINMENT Press the Navigation button to show the Picture Size, Audio Language or Subtitle Language. Press the Navigation button to make appropriate adjustments. Subtitle Support Language Language Latin1 English, Spanish, French, German, Italian, Swedish, Finnish, Dutch, Portuguese, Danish, Romanian, Norwegian, Albanian, Gaelic, Welsh, Irish, Catalan, Valencian Latin2 Bosnian, Polish, Croatian, Czech, Slovak, Slovenian, Serbian, Hungarian Latin4 Estonian, Latvian, Lithuanian Cyrillic Bulgarian, Macedonian, Russian, Ukrainian, Kazakh Greek Greek Hebrew Hebrew Chinese Chinese Japanese Japanese Korean Korean NOTE Only the files saved in ASCII CODE is supported for the external subtitles of the movie.
-
Page 33: Divx Registration Code
DivX registration code Check and register the DivX registration code of your Monitor set so that you can rent or purchase the latest movies at www.divx.com/vod . To play a rented or purchased DivX file, the file’s registration code should be same with your Monitor set’s DivX registration code. Press MENU to access the USB menus. Press the Navigation button to scroll to DivX Reg. Code and press OK. View the registration code of your Monitor set. DivX(R) Video On Demand Your registration Code is: xxxxxxxxxx To learn more visit www.divx.com/vod. Close Close NOTE While you are checking the registration code, some buttons may not work. If you use the DivX registration code of another device, you cannot play the rented or purchased DivX file. Make sure to use the DivX registration code assigned to your Monitor set. The video or audio files that are not converted by the standard DivX codec may be corrupted or not be played. -
Page 34: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS Connect various external devices to the ports on the Monitor set’s back panel. Find an external device you want to connect to your Monitor set shown on the following illustration. Check the connection type of the external device. Go to the appropriate illustration and check the connection details. HD Receiver HDMI - See p.35 DVI - See p.35 AV(CVBS) - See p.36 Component - See p.36 Speaker HDMI - See p.12 DVI - See p.11 RGB - See p.11 LAN - See p.37 NOTE If you connect a gaming device to the Monitor set, use the cable supplied with the gaming device. -
Page 35: Connecting To A Hd Receiver, Dvd, Camcorder, Camera, Gaming Device Or Vcr Player
Connecting to a HD receiver, DVD, Camcorder, Camera, Gaming Device or VCR player Connect a HD receiver, DVD, or VCR player to the Monitor set and select an appropriate input mode. HDMI connection Transmits the digital video and audio signals from an external device to the Monitor set. Connect the external device and the Monitor set with the HDMI cable as shown on the following illustration. RGB IN RGB IN RGB OUT RGB OUT HDMI Signal Cable (not included) NOTE Use a High Speed HDMI™ Cable. High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher. MAKING CONNECTIONS HDMI/DVI connection Transmits the digital video signal from an external device to the Monitor set. Connect the external device and the Monitor set with the HDMI/DVI cable as shown in the following illustration. To... -
Page 36: Component Connection
MAKING CONNECTIONS Component connection Transmits the analog video and audio signals from an external device to the Monitor set. Connect the external device and the Monitor set with the component cable as shown on the following illustration. To display images by using progressive scan, make sure to use the component cable. -
Page 37: Connecting To The Lan
Connecting to the LAN LAN connection Connect the LAN cable and install the eZ-Net Manager program on the CD-ROM. For more information about the program, please refer to eZ-Net Guide in the enclosed CD-ROM. Connect PC to Monitor directly. Monitor Set Using a router(Switch) Switch Monitor Set Network Using the Internet. Network Network Monitor Set NOTE Using LAN establishes communication between your PC and the monitor and enables to use the OSD menus on the PC as well as on the monitor. MAKING CONNECTIONS... -
Page 38: Daisy Chain Monitors
MAKING CONNECTIONS Daisy Chain Monitors Use this function to share the RGB video signal with other monitors without having to use a separate signal splitter box. • T o use different products connected to each other Connect one end of the signal input cable (15-pin D-Sub Signal Cable) to the RGB OUT connector of product 1 and connect the other end to the RGB IN connector of other products RGB Mode 15-pin D-Sub Signal Cable (Max 3m) Product 1 AV(CVBS) Mode Audio Cable (Not included) AV IN / OUT AV IN / OUT VIDEO AUDIO VIDEO BNC Cable (Not included) Product 1 NOTE When multi-connecting in/out cascade format, no loss cables are recommended. We recommend that you should use cable distributor. Product 2 Product 3 AV IN / OUT AV IN / OUT VIDEO... -
Page 39: Troubleshooting
Backlight may need repair. y I f the product is in power saving mode, move the mouse or press any key. y Turn both devices off and then back on. y T he signal from the PC (video card) is out of the vertical or horizontal frequency range of the product. Adjust the frequency range by referring to the Specifications in this manual. * Maximum resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI : 1920 x 1080 @ 60 Hz y T he signal cable between PC and product is not connected. Check the signal cable. y P ress the 'INPUT' menu in the remote Control to check the input signal. Resolution y I nstall the product driver, which is provided with the product, or download it from the web site. (http://www.lg.com) y S ee if the plug&play function is supported by referring to the video card user manual. TROUBLESHOOTING... - Page 40 TROUBLESHOOTING 'Key Lock On' message appears. Problem The 'Key Lock On' message appears when pressing the Menu button. The screen image looks abnormal. Problem Is the screen position wrong? Do thin lines appear on the background screen? Horizontal noise appears or the characters look blurred. The screen is displayed abnormally. After-image appears on the product. Problem After-image appears when the product is turned off. Resolution y The Lock function prevents the OSD settings from being changed inadvertently. To release the lock, go to Menu and Option and disable the Key Lock option. Resolution y D-Sub analog signal - Press the "AUTO" button in the remote control to automatically select the optimal screen status that fits into the current mode. If adjustment is not satisfactory, use the Position OSD menu.
- Page 41 The audio function does not work. Problem No sound? y See if the audio cable is connected properly. y Adjust the volume. y S ee if the sound is set properly. Sound is too dull. y Adjust the Clear Voice ll, Treble and Bass appropriately. Sound is too low. y A djust the volume. Screen color is abnormal. Problem Screen has poor color resolution y S et the number of colors to more than 24 bits (true color) Select (16 colors). S creen color is unstable or y Check the connection status of the signal cable. Or, re-insert the PC mono-colored. Do black spots appear on the y S everal pixels (red, green, white or black color) may appear on the screen?
-
Page 42: Specifications
SPECIFICATIONS SPECIFICATIONS LCD Panel Screen Type Pixel Pitch Video Signal Max. Resolution Recommended Resolution RGB : 1920 X 1080 @ 60 Hz Horizontal Frequency Vertical Frequency Synchronization Type Input Connector Power Rated Voltage Power Consumption Environmental Operating Temperature conditions Operating Humidity Storage Temperature Storage Humidity Dimensions... - Page 43 RGB (PC) supported mode Horizontal Vertical Resolution Frequency(kHz) Frequency(Hz) 31.469 640 x 350 31.468 720 x 400 31.469 640 x 480 37.5 640 x 480 37.879 800 x 600 46.875 800 x 600 49.725 832 x 624 48.363 1024 x 768 60.123 1024 x 768 44.772 1280 x 720 47.7 1280 x 768 47.72 1360 x 768 47.7 1366 x 768 63.981 1280 x 1024 79.98 1280 x 1024 65.290 1680 x 1050 67.5 1920 x 1080...
-
Page 44: Ir Codes
IR CODES IR CODES This feature is not available for all models. Code (Hexa) Energy Saving ( ꕊ ) (POWER) INPUT Monitor On Monitor Off ARC (MARK) MENU Up ( ꕌ ) Down ( ꕍ ) Left (<) Right (>) OK( ꔉ ) BACK( ꕉ ) EXIT ( + ) ( - ) MUTE Brightness ꕌ (Page UP) Brightness ꕍ (Page Down) 10 to 19 Number Key 0 to 9 Red Key... -
Page 45: Controlling The Multiple Product
CONTROLLING THE MULTIPLE PRODUCT Use this method to connect several products to a single PC. You can control several products at a time by connecting them to a single PC. In the Option menu, Set ID must be between 1 and 99 without being duplicated. Connecting the cable Connect the RS-232C cable as shown in the picture. The RS-232C protocol is used for communication between the PC and product. You can turn the product on/off, select an input source or adjust the OSD menu from your PC. RS-232C Cable (not included) RS-232C Configurations 7-Wire Configurations (Standard RS-232C cable) D-Sub 9 D-Sub 9 (Female) (Female) Communication Parameter Baud Rate : 9600 buad Rate (UART) Data Length : 8 bit Parity Bit : None Stop Bit : 1bit Flow Control : None Communication Code : ASCII code Use a crossed (reverse) cable EXTERNAL CONTROL DEVICE SETUP Monitor Set 1 Monitor Set 2 Monitor Set 3 3-Wire Configurations (Not Standard) Monitor Set 4 D-Sub 9... -
Page 46: Command Reference List
EXTERNAL CONTROL DEVICE SETUP Command reference list 01. Power 02. Aspect Ratio 03. Screen Mute 04. Volume Mute 05. Volume Control 06. Contrast 07. Brightness 08. Color 09. Tint 10. Sharpness 11. OSD Select 12. Remote Lock/ key Lock 13. Balance 14. Color Temperature 15. Abnomal state 16. ISM mode 17. Auto configuration 18. Key 19. Tile Mode 20. Tile H Position 21. Tile V Position 22. Tile H Size 23. Tile V Size 24. Tile ID Set 25. Natural Mode (In Tile mode) 26. Picture mode (PSM) 27. Sound mode 28. Fan Fault check 29. Elapsed time return 30. Temperature value 31. Lamp fault check 32. Auto Volume 33. Speaker 34. Time 35. On Timer (On/Off Timer) Time 36. Off Timer (On/Off Timer) Time... - Page 47 39. Auto Sleep 40. Power On Delay 41. Language 42. DPM Select 43. Reset 44. Power Saving 45. Power Indicator 46. Serial no. 47. S / W Version 48. Input Select Note : During USB operations such as Dvix or EMF, all commands except Power(ka) and Key(mc) are not executed and treated as NG.
-
Page 48: Transmission/ Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission/ Receiving protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command 1]: First command. (k, j, m, d, f, x) * [Command 2]: Second command.(a to u) * [Set ID]: Set up the Set ID number of product. range : 01H to 63H. - Page 49 01. Power (Command: k a) To control Power On/Off of the set. Transmission [k][a][ ][Set ID][ ][Data][Cr] Data 00 : Power Off Data 01 : Power On Acknowledgement [a][ ][Set ID][ ][OK][Data][x] To show the status of Power On/Off. Transmission [k][a][ ][Set ID][ ][FF][Cr] Acknowledgement [a][ ][Set ID][ ][OK][Data][x] Data 00 : Power Off Data 01 : Power On 02. Aspect Ratio (Command: k c) To adjust the screen format. You can also adjust the screen format using the ARC (Aspect Ratio Control) button on remote control or in the Screen menu. Transmission [k][c][ ][Set ID][ ][Data][Cr] Data 01 : Normal Screen (4 : 3) 02 : Wide Scran (16 : 9) 04 : Zoom (AV(CVBS),Component,HDMI-DTV) 06 : Original (AV(CVBS)) 07 : 14 : 9 (AV(CVBS),Component,HDMI-DTV) 09 : Just Scan (HD DTV) * W hen the RGB, HDMI - PC mode (1:1) 10 to 1F : C inema Zoom 1 to 16 (AV(CVBS),Component,HDMI-DTV) B : Full Wide (AV(CVBS))
- Page 50 EXTERNAL CONTROL DEVICE SETUP 05. Volume Control (Command: k f) To adjust Volume. Transmission [k][f][ ][Set ID][ ][Data][Cr] Data Min : 00H to Max : 64H (Hexadecimal code) Acknowledgement [f][ ][Set ID][ ][OK][Data][x] Data Min : 00H to Max : 64H * Real data mapping 0 : STEP 0 : A : STEP 10 : F : STEP 15 10 : STEP 16 : 64 : STEP 100 06. Contrast (Command: k g) To adjust screen contrast. You can also adjust the contrast in the Picture menu. Transmission [k][g][ ][Set ID][ ][Data][Cr] Data Min : 00H to Max : 64H Acknowledgement [g][ ][Set ID][ ][OK][Data][x] Data Min : 00H to Max : 64H * Refer to 'Real data mapping ’. See p.50 07.
- Page 51 11. OSD Select (Command: k l) To control OSD on/off to the set. Transmission [k][l][ ][Set ID][ ][Data][Cr] Data 00: OSD Off Data 01: OSD On Acknowledgement [l][ ][Set ID][ ][OK][Data][x] Data 00: OSD Off Data 01: OSD On 12. Remote Lock /Key Lock (Command: k m) To control Remote Lock on/off to the set. This function, when controlling RS-232C, locks the remote control and the local keys. Transmission [k][m][ ][Set ID][ ][Data][Cr] Data 00: Off Data 01: On Acknowledgement [m][ ][Set ID][ ][OK][Data][x] Data 00: Off Data 01: On 13. Balance (Command: k t) To adjust the sound balance. Transmission [k][t][ ][Set ID][ ][Data][Cr] Data Min : 00H to Max : 64H...
- Page 52 EXTERNAL CONTROL DEVICE SETUP 17. Auto Configure (Command: j u) To adjust picture position and minimize image shaking. Automatically. NB : Only applies to RGB(PC) mode. Transmission [j][u][ ][Set ID][ ][Data][Cr] Data 01 : To set Acknowledgement [u][ ][Set ID][ ][OK][Data][x] 18. Key (Command: m c) To send IR remote key code. Transmission [m][c][ ][Set ID][ ][Data][Cr] Data Key code : Refer to ‘IR CODES’. See p.44 Acknowledgement [c][ ][Set ID][ ][OK][Data][x] 19. Tile Mode (Command: d d) Change a Tile Mode. Transmission [d][d][ ][Set ID][ ][Data][Cr] Data Description 00 or 11 Tile mode is off.
- Page 53 23. Tile V Size (Command: d h) To set the Vertical size. Transmission [d][h][ ][Set ID][ ][Data][x] Data Min : 00H to Max : 64H * Refer to 'Real data mapping ’. See p.50 Acknowledgement [h][ ][Set ID][ ][OK/NG][Data][x] 24. Tile ID Set (Command: d i) To assign the Tile ID for Tiling function. Transmission [d][i][ ][Set ID][ ][Data][x] Data Min : 00H to Max : 19H (Hexadecimal code) Acknowledgement [i][ ][Set ID][ ][OK/NG][Data][x] 25. Natural Mode (Command: d j) To assign the Tile Natural mode for Tiling function. Transmission [d][j][ ][Set ID][ ][Data][x] Data 00 : Natural Off 01 : Natural On ff : Read Status Acknowledgement [j][ ][Set ID][ ][OK/NG][Data][x] EXTERNAL CONTROL DEVICE SETUP...
- Page 54 EXTERNAL CONTROL DEVICE SETUP 29. Elapsed time return (Command: d l) To read the elapsed time. Transmission [d][l][ ][Set ID][ ][Data][x] * The data is always FF(in Hex). Acknowledgement [l][ ][Set ID][ ][OK/NG][Data][x] * The data is always FF(in Hex). (Hexadecimal code) 30. Temperature value (Command: d n) To read the inside temperature value. Transmission [d][n][ ][Set ID][ ][Data][x] * The data is always FF(in Hex). Acknowledgement [n][ ][Set ID][ ][OK/NG][Data][x] * The data is 1 byte long in Hexadecimal. 31. Lamp fault Check (Command: d p) To check lamp fault. Transmission [d][p][ ][Set ID][ ][Data][x] * The data is always FF(in Hex).
- Page 55 35. On Timer (On/Off Timer) Time (Command: f d) Set On Timer. Transmission [f][d][ ][Set ID][ ][Data1][ ][Data2][ ][Data3][Cr] [Data1] 1. f1h to f4h(read one index) f1: read 1st index of On Time List f2: read 2nd index of On Time List f3: read 3rd index of On Time List f4: read 4th index of On Time List 2. e1h~e4h(delete one index), e0h(delete all indexes) e0: delete all indexes of On Time List e1: delete 1st index of On Time List e2: delete 2nd index of On Time List e3: delete 3rd index of On Time List e4: delete 4th index of On Time List 3. 01h to 80h (write) (Day of Week) bit0 (01h) : Monday bit1 (02h) : Tuesday bit2 (04h) : Wednesday bit3 (08h) : Thursday bit4 (10h) : Friday bit5 (20h) : Saturday bit6 (40h) : Sunday bit7 (80h) : Everyday (1fh) : Monday to Friday (3fh) : Monday to Saturday (60h) : Saturday to Sunday [Data 2] 00h to 17h (Hours) [Data 3] 00h to 3bh (Minutes) *When you read/delete the current on time list, all of [Data2][Data3] are have to be FFH.
- Page 56 EXTERNAL CONTROL DEVICE SETUP 37. Scheduling Input select (Command: f u) (Main Picture Input) To select input source for Set depending on day. Transmission [f][u][ ][Set ID][ ][Data1][ ][Data2][Cr] [Data 1] 1. f1h to f4h(write/read one index) f1: read 1st index of Scheduling Input f2: read 2nd index of Scheduling Input f3: read 3rd index of Scheduling Input f4: read 4th index of Scheduling Input [Data 2] Input Data(Hex) Input AV(CVBS) Component RGB - PC HDMI/DVI - HD - DVD HDMI/DVI - PC *When you read/delete the current Scheduling Input, [Data2] needs to be FFH. (ex1: fu 01 f1 ff - when you read 1st index of Scheduling Input. ex2: fu 01 f3 02 - when you write one Scheduling Input Data in to 3rd index, "AV(CVBS)") Acknowledgement [u][ ][Set ID][ ][OK][Data1][Data2][x] 38.
- Page 57 41. Language (Command: f i) Set the OSD language. Transmission [f][i][ ][Set ID][ ][Data][Cr] Data 00 : English 01 : French 02 : German 03 : Spanish 04 : Italian 05 : Portuguese 06 : Chinese 07 : Japanese 08 : Korean 09 : Russian Acknowledgement [i][ ][Set ID][ ][OK/NG][Data][x] 42. DPM Select (Command: f j) Set the DPM (Display Power Management) function. Transmission [f][j][ ][Set ID][ ][Data][Cr] Data 00 : Off 01 : On Acknowledgement [j][ ][Set ID][ ][OK/NG][Data][x] 43. Reset (Command: f k) Set the DPM (Display Power Management) function. Transmission [f][k][ ][Set ID][ ][Data][Cr] Data 00 : Picture Reset 01 : Screen Reset...
- Page 58 EXTERNAL CONTROL DEVICE SETUP 47. S/W Version (Command: f z) Check the software version. Transmission [f][z][ ][Set ID][ ][Data][Cr] Data FFH : Read Acknowledgement [z][ ][Set ID][ ][OK/NG][Data][x] 48. Input Select (Command: x b) To select input source for the Set. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data 20H : AV(CVBS) 40H : Component 60H : RGB(PC) 90H : HDMI/DVI(DTV) A0H : HDMI/DVI(PC) Acknowledgement [b][ ][Set ID][ ][OK/NG][Data][x] Data 20H : AV(CVBS) 40H : Component 60H : RGB(PC) 90H : HDMI/DVI(DTV) A0H : HDMI/DVI(PC)
- Page 59 Make sure to read the Safety Precautions before using the product. Keep the Owner's Manual(CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET. Record it below should you ever need service.
