- Page 1 All manuals and user guides at all-guides.com OWNER’S MANUAL LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LCD MONITOR MODELS E1940S/E1940T E2040S/E2040T E2240S/E2240T E2340S/E2340T www.lg.com...
-
Page 2: Important Precautions
Important Precautions All manuals and user guides at all-guides.com This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 3 Important Precautions All manuals and user guides at all-guides.com On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
- Page 4 Important Precautions All manuals and user guides at all-guides.com On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
- Page 5 Accessories All manuals and user guides at all-guides.com !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. User's Guide/Cards 15-pin D-Sub Signal Cable (To set it up, this signal cable may be attached to this product before shipping out.)
-
Page 6: Connecting The Display
Connecting the Display All manuals and user guides at all-guides.com Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor with its front facing downward on a soft cloth. -
Page 7: Disassembling The Stand
Connecting the Display All manuals and user guides at all-guides.com Disassembling the stand Place the monitor with its front facing downward on a soft cloth. When you desire to disintegrate the Nip Latch inside, Take off the stand base monitor from the stand base, use a coin from stand body. -
Page 8: Positioning Your Display
Connecting the Display All manuals and user guides at all-guides.com Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display -After installation, adjust the angle as shown below. Adjust the position of the panel in various ways for maximum comfort. -
Page 9: Connecting With The Pc
Connecting the Display E1940T/E2040T/E2240T/E2340T All manuals and user guides at all-guides.com Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable. - Page 10 Connecting the Display E1940S/E2040S/E2240S/E2340S All manuals and user guides at all-guides.com Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable...
-
Page 11: Control Panel Functions
Control Panel Functions E1940T/E2040T/E2240T/E2340T All manuals and user guides at all-guides.com Front Panel Controls MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED"... - Page 12 Control Panel Functions All manuals and user guides at all-guides.com AUTO Button AUTO IMAGE ADJUSTMENT When adjusting your display settings, always press the AUTO button before entering the On Screen Display(OSD). (Only Analog Mode) This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode).
- Page 13 Control Panel Functions E1940S/E2040S/E2240S/E2340S All manuals and user guides at all-guides.com Front Panel Controls MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds.
-
Page 14: Auto Button
This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode). The best display mode is E1940S : 1360 x 768 E2040S : 1600 x 900 E2240S/E2340S : 1920 x1080 EXIT Button Exit the OSD(On Screen Display). -
Page 15: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment E1940T/E2040T/E2240T/E2340T All manuals and user guides at all-guides.com Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. - Page 16 On Screen Display (OSD) Control Adjustment E1940S/E2040S/E2240S/E2340S All manuals and user guides at all-guides.com Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system.
-
Page 17: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment All manuals and user guides at all-guides.com The following table indicates all the On Screen Display control, adjustment, and setting menus. : D-SUB(Analog signal) input DSUB : DVI-D(Digital signal) input DVI-D Main menu Sub-menu Supported input Description To adjust the brightness, contrast... - Page 18 You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. E1940S/E2040S/E2240S/E2340S E1940T/E2040T/E2240T/E2340T Press the MENU Button, then the main menu of the OSD appears.
- Page 19 To adjust the brightness of the screen. BRIGHTNESS To adjust the contrast of the screen. CONTRAST SHARPNESS To adjust the clearness of the screen. E1940S/E2040S/E2240S/E2340S Exit : Exit : Decrease : Increase : Select another sub-menu : Restart to select sub-menu COLOR TEMP Select the screen color.
- Page 20 CLOCK stripes visible on the screen background. The horizontal screen size will also change. E1940S/E2040S/E2240S/E2340S To adjust the focus of the display. PHASE This item allows you to remove any horizontal noise and clear or sharpen the image of characters.
- Page 21 WHITE If the output of the video card is BALANCE different the required specifications, E1940S/E2040S/E2240S/E2340S the color level may deteriorate due to video signal distortion. Using this function, the signal level is adjusted to fit into the standard output level of the video card in order to provide the optimal image.
- Page 22 You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. E1940S/E2040S/E2240S/E2340S E1940T/E2040T/E2240T/E2340T Press the MODE Button, then the main menu of the OSD appears.
- Page 23 On Screen Display(OSD) Selection and Adjustment All manuals and user guides at all-guides.com Main menu Sub menu Description NORMAL Select this when you want to use the product in the most general using environment. MOVIE Select this when you are watching a video or movie.
- Page 24 On Screen Display(OSD) Selection and Adjustment All manuals and user guides at all-guides.com Main menu Sub menu Description WIDE Switch to full screen mode according to input image signal. ORIGINAL Change the input image signal ratio to original. * This function works only if input resolution is lower than monitor ratio (16:9).
- Page 25 On Screen Display(OSD) Selection and Adjustment All manuals and user guides at all-guides.com Main menu Sub menu Description NORMAL The PhotoEffect function is disabled. GAUSSIAN This menu changes the screen to be more colorful and smoother. BLUR SEPIA This menu changes the screen to be Sepia tone (brown color).
-
Page 26: Troubleshooting
Troubleshooting All manuals and user guides at all-guides.com Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected properly to the power outlet. display connected? Is the power indicator •... -
Page 27: Display Image Is Incorrect
Troubleshooting All manuals and user guides at all-guides.com Display image is incorrect Display Position is • Press the AUTO button to automatically adjust incorrect. your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. - Page 28 Troubleshooting All manuals and user guides at all-guides.com Display image is incorrect The screen color is • Check if the signal cable is properly connected mono or abnormal. and use a screwdriver to fasten if necessary. • Make sure the video card is properly inserted in the slot.
-
Page 29: Specifications
Specifications E1940T All manuals and user guides at all-guides.com Display 47.0 cm (18.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 47.0 cm 0.300 mm x 0.300 mm (Pixel pitch) Horizontal Freq. 30 kHz to 61 kHz (Automatic) Sync Input Vertical Freq. - Page 30 Specifications E1940S All manuals and user guides at all-guides.com Display 47.0 cm (18.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 47.0 cm 0.300 mm x 0.300 mm (Pixel pitch) Horizontal Freq. 30 kHz to 61 kHz (Automatic) Sync Input Vertical Freq.
- Page 31 Specifications E2040T All manuals and user guides at all-guides.com Display 50.8 cm (20.0 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 50.8 cm 0.2766 mm x 0.2766 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq.
- Page 32 Specifications E2040S All manuals and user guides at all-guides.com Display 50.8 cm (20.0 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 50.8 cm 0.2766 mm x 0.2766 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq.
- Page 33 Specifications E2240T All manuals and user guides at all-guides.com Display 54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 54.6 cm 0.248 mm x 0.248 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq.
- Page 34 Specifications E2240S All manuals and user guides at all-guides.com Display 54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 54.6 cm 0.248 mm x 0.248 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq.
- Page 35 Specifications E2340T All manuals and user guides at all-guides.com Display 58.4 cm (23 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 58.4 cm 0.266 mm x 0.266 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq.
- Page 36 Specifications E2340S All manuals and user guides at all-guides.com Display 58.4 cm (23 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 58.4 cm 0.266 mm x 0.266 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq.
-
Page 37: Preset Modes (Resolution)
Specifications All manuals and user guides at all-guides.com Preset Modes (Resolution) E1940T/E1940S Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 49.725... - Page 38 Specifications All manuals and user guides at all-guides.com E2240T/E2340T/E2240S/E2340S Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 48.363 1024 x 768 60.123 1024 x 768 67.500...
- Page 39 All manuals and user guides at all-guides.com Make sure to read the Important Precautions before using the product. Ke e p t h e O w n e r ’ s M a n u a l (C D ) i n a n accessible place for future reference.
