- Page 1 Cassette Type Series 1 Way cassette : AM✴✴✴FN1DEH✴ 2 Way cassette : AM✴✴✴FN2DEH✴ 4 Way cassette : AM✴✴✴FN4DEH✴ Air Conditioner user manual imagine the possibilities Thank you for purchasing this Samsung product.
- Page 2 Features of your new air conditioner Cool Summer Offer On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest. This summer, beat the heat with your own air conditioner.
-
Page 3: Table Of Contents
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For more information on safe disposal and recycling, visit our website www.samsung.com/in or contact our Helpline numbers - 1800 40 SAMSUNG (1800 40 7267864) -
Page 4: Safety Precautions
If you have any questions, call your nearest contact center or find help and information online at www.samsung.com. Important safety symbols and precautions: Hazards or unsafe practices that may result in severe WARNING personal injury or death. - Page 5 FOR INSTALLATION WARNING The installation of this appliance must be performed by a qualified technician or service company. X Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury. Install an isolation switch next to the air conditioner (but not on the panels of the air conditioner) and circuit breaker dedicated to the air conditioner.
- Page 6 Safety precautions FOR INSTALLATION CAUTION Install your appliance on a level and hard floor that can support its weight. X Failing to do so may result in abnormal vibrations, noise, or problems with the product. When installing the indoor unit, make sure to install the draining hose properly, so that water is drained correctly.
- Page 7 FOR USING WARNING If the appliance is flooded, please contact your nearest service center. X Failing to do so may result in electric shock or fire. If the appliance generates a strange noise, a burning smell or smoke, cut-off the power supply immediately and contact the nearest service center.
- Page 8 Safety precautions FOR USING WARNING Do not turn the air conditioner off with the circuit breaker while it is operating. X Turning the air conditioner off and then on again with the circuit breaker may cause a spark and result in electric shock or fire. After unpacking the air conditioner, keep all packaging materials well out of the reach of children, as packaging materials can be dangerous to children.
- Page 9 FOR USING WARNING Do not attempt to repair, disassemble, or modify the appliance yourself. X Do not use any fuse (such as cooper, steel wire, etc.)other than the standard fuse. X Failing to do so may result in electric shock, fire, problems with the product, or injury.
- Page 10 Safety precautions FOR USING CAUTION Do not apply a strong impact to the remote controller and do not disassemble the remote controller. Do not touch the pipes connected with the product. X This may result in burns or injury. Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or for any other unusual purposes.
- Page 11 FOR CLEANING WARNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner or alcohol to clean the appliance. X This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, cut-off the power supply and wait until the fan stops.
-
Page 12: Viewing Your Air Conditioner
Viewing your air conditioner Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay cool or warm with optimal efficiency. Please read the user manual to get started and to make the best use of the air conditioner. Slim 1 way cassette Main parts PC1NUSMAN... - Page 13 2 way cassette Main parts and Display PC2NUSMEN Air flow blade Air intake Air filter (under the grille) Display Filter reset indicator Fan indicator Timer indicator Power indicator Power button Your air conditioner and display may look slightly different from the illustration shown above depending on your model.
- Page 14 Viewing your air conditioner 4 way cassette Main parts and Display Air flow blade Air intake Air filter (under the grille) Display On/Off operation indicator Removing frost indicator Timer indicator Filter reset indicator Remote control sensor Your air conditioner and display may look slightly different from the illustration shown above depending on your model.
-
Page 15: Using Your Air Conditioner
Using your air conditioner Tips on using air conditioner Here are some tips that you would follow when using your air conditioner. TOPIC RECOMMENDATION • If current outside temperatures are much higher than the selected indoor temperature, it may take time to bring the inner temperature to the desired coolness. - Page 16 Using your air conditioner TOPIC RECOMMENDATION • If both indoor and outdoor temperatures are high High indoor/ and the air conditioner is running in Heat mode, the outdoor outdoor unit’s fan and compressor may stop at times. temperatures This is normal; wait until the air conditioner turns on again.
-
Page 17: Cleaning And Maintaining The Air Conditioner
Cleaning and maintaining the air conditioner For the best performance of your air conditioner, clean it periodically. When cleaning, make sure to unplug the unit for user’s safety. Cleaning the exterior Wipe the surface of the unit with a slightly wet or dry cloth when needed. Wipe off dirt of odd-shaped area by using a soft brush. - Page 18 Cleaning and maintaining the air conditioner 2. Unhook the safety clips by holding the front grille. 3. Detach the front grille. Hold the front grille at a 45° angle, lift it up slightly and then pull the grille forward. Hold the grille to prevent dropping outside from the opening of the CAUTION front grille.
- Page 19 2 way cassette PC2NUSMEN 1. Open the front grille. Push the [▼] tabs located in 3 places to unlock the groove on the front grille. The grille automatically drops. Two safety clips are mounted to the inside front grille to prevent dropping downward.
- Page 20 1. Open the front grille. Open the blades on the left and right side of the Samsung logo. Press both of the levers and pull the grille downward. Two safety clips are mounted to the front grille to prevent it from dropping.
- Page 21 4. Clean the grille and Air filter with a vacuum cleaner or soft brush. If dust is too heavy, then rinse it with running water and dry it in a ventilated area. For best conditions, repeat every two weeks. If the Air filter dries in a confined (or humid) area, odors may generate. If it occurs, re-clean and dry it in a well- ventilated area.
- Page 22 Cleaning and maintaining the air conditioner Cleaning the filter When cleaning the filter, make sure to unplug the power from the unit. Washable foam based Air filter captures large particles from the air. The filter is cleaned with a vacuum or by hand washing. Slim 1 way cassette 1.
- Page 23 2. Pull out the Air filter. Grab the Air filter and lift it upwards while pushing slightly, and then pull the Air filter forward. When cleaning the filter you do not need to detach the grille at all times. If you want to detach the front grille, see step 2 and 3 on page 18 for instructions.
- Page 24 Cleaning and maintaining the air conditioner 2 way cassette 1. Open the front grille. Push the [▼] tabs located in 3 places to unlock the hook on the front grille. The grille automatically drops. Two safety clips are mounted to the inside front grille to prevent dropping downward.
- Page 25 4 way cassette 1. Push both of the tabs outwards to unlock the hook on the front grille. The grille automatically drops. Two safety clips are mounted to the inside front grille to prevent dropping downward. 2. Pull out the Air filter. Grab the Air filter and lift it upwards while pushing slightly, and then pull the Air filter forward.
- Page 26 Cleaning and maintaining the air conditioner Maintaining your air conditioner If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition. 1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and disconnect the power plug.
- Page 27 Internal protections via the unit control system This internal protection operates if an internal fault occurs in the air conditioner. Type Description Against cold air The internal fan will be off to block cold air when the heat pump is heating. Defrost cycle Anti-Freezing of Indoor Heat The compressor will be off if the heat exchanger temp of indoor unit decrease to...
-
Page 28: Appendix
Appendix Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. PROBLEM SOLUTION The air conditioner • Because of the protective mechanism, the does not operate appliance does not start operating immediately immediately after it to keep the unit from overloading. - Page 29 PROBLEM SOLUTION • Check if the air conditioner has just been turned on. If so, wait 3 minutes. Cool air does not come out to protect the compressor of the outdoor unit. • Check if the air conditioner is installed in a place with a direct exposure to sunlight.
- Page 30 Appendix PROBLEM SOLUTION • A bubbling sound may be heard when the refrigerant is circulating through the compressor. Let the air conditioner operate in a The air conditioner selected mode. makes a bubbling sound. • When you press the Power button on the remote control, noise may be heard from the drain pump inside the air conditioner.
- Page 31 PROBLEM SOLUTION • Check if TEST indicator is displayed on the The wired remote wired remote control. If so, turn off the unit and control does not switch off the circuit breaker. Call your nearest operate. contact center. • Press the Power button on the remote control The indicators of the digital display to turn the unit off and switch the circuit...
- Page 32 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT INDIA 1800 40 SAMSUNG (1800 40 7267864) - Toll Free www.samsung.com/in/support This product is RoHS compliant DB68-05489A-01...
