MCSDI-1
applications
live video Production
broadcasting
Corporate and Industrial Production
education and training
events and entertainment
Government
Postproduction
Corporate Headquarters
Focus enhancements
1370 Dell avenue
Campbell, Ca 95008
P 800 338 3348 (toll free)
P 408 866 8300
F 408 866 4859
e sales@focusinfo.com
e asiapac@focusinfo.com
european Headquarters
CoMo Computer & Motion GmbH
a Focus enhancements Company
lise-Meitner-Str.15
24223 raisdorf
Germany
P +49 4307 8358 0
F +49 4307 8358 99
e emea@focusinfo.com
©2007. Focus enhancements, Inc. Specifications are sub-
ject to change. all brand and product names are trademarks
of their respective companies. 8/07 Manl-1095-02
mcsdi-1
Small, flexible, and affordable, the MCSDI-1 Portable HD/SD-SDI Media Converter can be
mounted on your camcorder or between your tripod and camcorder and converts HD an-
alog, SD analog, or digital HDMI input signals to HD-SDI or SD-SDI output—with ease.
MCSDI-1 Portable HD/SD-SDI Media Converter
a powerful converter in a portable package, the MCSDI-1 enables you to convert the output
from any camera—including prosumer-level cameras—to professional-grade HD-SDI or
SD-SDI for outstanding, broadcast-quality video.
Key Features
Flexible and affordable
Camera and tripod Mount
Multiple Input options
Input Signal auto Sensing
Closed Captioning
extends the Usage of Prosumer
Cameras
two-Channel audio Input
technical Specifications
MoDel
video Formats
video Inputs
video-Input Ports
video outputs
audio Input
audio-Input Ports
audio-Input Settings
audio output
audio levels
analog/Digital Conversion
Power requirements
Dimensions (h x w x d)
Weight
Compliance
Warranty
optional accessories
MCSDI-1 Portable HD/SD-SDI MeDIa Converter
Benefits
With its ability to convert SD, HD, or HDMI inputs to SD-SDI or
HD-SDI, the MCSDI-1 delivers multiple conversion options in one
cost-effective unit.
With its small footprint, the MCSDI-1 can be easily mounted on your
camcorder or between your tripod and camcorder, making it the
perfect portable solution.
the MCSDI-1 accommodates HD analog, SD analog, and HDMI inputs.
With built-in auto sensing, no signal setting is required for video
inputs, making the unit very simple to use.
the MCSDI-1 supports closed captions in the line 21 format.
Prosumer-level HD cameras (with analog or HDMI output) can now
be used in live studio shoots when combined with the MCSDI-1.
the MCSDI-1 can accommodate two channels of audio input and
embed them both in the SDI signal, requiring only one SDI cable for
both video and audio transmission.
MCSDI-1
1080i (50/59.94 Hz) and 720p (50/59.94 Hz) with auto sensing
HD component: YPbPr (SMPte 274); SD component/composite/YC
(S-video); HDMI
5 x rCa; 1 x 19-pin HDMI
SD-SDI (SMPte 259); HD-SDI (SMPte 292/296)
2-channel (SMPte 299; SMPte 272M-a)
2 x rCa
Selector switch
embedded SDI (SMPte 299; SMPte 272M-a)
+4 db; 0 db; -8 db
video: 10 bits; audio: 24 bits (48 kHz), 16 bits (48 kHz)
7.2–30v DC (power adapter included)
5.25" x 3.75" x 1.125" (133.35 mm x 95.25 mm x 28.575 mm)
1 lb. (0.45 kg)
Ce, C-tick, and FCC
2 years
HDMI cable
www.focusinfo.com
800.338.3348
