Channel Vision 6010-B Specification Sheet

Model 6010-B 1/3" COLOR
Vari-FOCAL Bullet Camera
Mounting hole
1/4" - 20
1-1/4"
4"
Specifications May Change Without Notice.
Channel Vision Technology will repair or replace any defect in material or workmanship which
occur during normal use of this product with new or rebuilt parts, free of charge in the USA, for
two years from the date of original purchase. This is a no hassle warranty with no mail in warranty
card needed. This warranty does not cover damages in shipment, failures caused by other products
not supplied by Channel Vision Technology, or failures due to accident, misuse, abuse, or
alteration of the equipment. This warranty is extended only to the original purchaser, and a
purchase receipt, invoice, or other proof of original purchase date will be required before
warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling (800) 840-0288 tool free. A
Return Authorization number must be obtained in advance and can be marked on the outside of
the shipping carton.
This warranty gives you specific legal rights and you may have other rights (which vary from state
to state). If a problem with this product develops during or after the warranty period, please
contact Channel Vision Technology, your dealer or any factory-authorized service center.
Costa Mesa, CA 92626
Zoom ring
BNC
(Video)
DC Jack
(Power)
CHANNEL VISION

Limited Warranty

234 Fischer Ave.
Specifications
Image Sensor 1/3" Color CCD
NTSC: 512 (H) x 492 (V)
Effective Pixels
Horizontal Resolution 380 TV Lines
Synchronizing System
Internal
Scanning System 2:1 Interlaced
1V p-p 75
Video Output
More than 48dB (AGC off)
S/N Ratio
0.2 Lux @ F2.0
Minimum Illumination
Automatic
BLC
Shutter Speed NTSC: 1/60 ~1/100,000
0.45
Gamma Correction
2100 K~8200 K Auto °
White Balance
Gain Control (AGC)
Automatic
Smear Effect 0.005%
MTBF
80,000 hours
Power Source
9~12 VDC Regulated
Operating Current
90mA
Lens
4-9mm (69°) Vari-FOCAL Lens
Operating T emperature
14°F ~ 122 F (10 C ~ 50 C)
Humidity
Less than 90% RH
Output T erminal 4' Cable with BNC - Female for Video, DC Jack - Male for Power
1-1/4" (D) x 4" (L)
Dimensions
Weight 5.1 oz
380 TV Lines, Weatherproof
Standard 4-9mm, Vari-FOCAL Lens
Strong, metal structure, easy to install.
Composite
°
° ° °
500-000
