Channel Vision 6010 Instructions

* Specifications :
Image Sensor: Sony 1/3" Super HAD CCD
Picture Elements: NTSC: 510x492
Resolution: 420 lines
S/N Ratio: More than 46 dB
Min Illumination: 0.1 LUX
Electronic Shutter: 1/60s - 1/100,000s
Iris Control: Automatic
White Balance: Automatic
Gamma Characteristic: 0.45
Lens: Varifocal, 4-9mm
Sync. System: Internal
Power Requirements: 12VDC
Power Consumption: 120mA
Video Output: 1 Vp-p @ 75 ohms
Humidity: RH 95% max.
Dimensions: 2.75" x 3.30" x 7.50" (70mm x 84mm x 190mm)
Operating Temp: -10°C to 50°C (14°F to 122°F)
CHANNEL VISION
Limited Warranty
Channel Vision Technology will repair or replace any defect in material or workmanship which occurs
during normal use of this product with new or rebuilt parts, free of charge in the USA, for two years from
the date of original purchase. This is a no hassle warranty with no mail in warranty card needed. This
warranty does not cover damages in shipment, failures caused by other products not supplied by Channel
Vision Technology, or failures due to accident, misuse, abuse, or alteration of the equipment. This warranty
is extended only to the original purchaser, and a purchase receipt, invoice, or other proof of original
purchase date will be required before warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling (800) 840-0288 toll free. A Return
Authorization number must be obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other rights (which vary from state to state).
If a problem with this product develops during or after the warranty period, please contact Channel Vision
Technology, your dealer or any factory-authorized service center.
*Specifications subject to change without notice.
500-000 Rev B
6010
Varifocal Bullet Camera
8
