- Page 1 INSTALLATION MANUAL Fan Coil Of Four-way Cassette Type Thank you very much for purchasing our air conditioner,...
-
Page 2: Table Of Contents
CONTENTS PAGE Install according to this installation instructions strictly. If installation is defective, it will cause water leakage, electrical shock and fire. PRECAUTIONS..................1 INSTALLATION INFORMATION............... 2 When installing the unit in a small room, take measures against to keep refrigerant concentration from exceeding ATTACHED FITTINGS................3 allowable safety limits in the event of refrigerant leakage. -
Page 3: Installation Information
2. INSTALLATION INFORMATION CAUTION Before installing the unit,it is necessary to check To install properly, please read this "installation manual" at whether the ground wire is charged. first. If it is,the unit shall not be installed before correction. The air conditioner must be installed by qualified persons. Ground the air conditioner. -
Page 4: Attached Fittings
3. FITTINGS 3.1 Attached fittings Please check whether the following fittings are of full scope. If there are some spare fittings , please restore them carefully Four-way Cassette Four-way Cassette NAME SHAPE (compact) 1. Installation paper board INSTALLATION FITTINGS 2. Bolt M6 Tubing &... -
Page 5: Inspecting And Handling The Unit
4. INSPECTING AND HANDLING THE UNIT 5.3 Install the main body The existing ceiling (to be horizontal) At delivery, the package should be checked and any damage should be reported immediately to the carrier claims agent. Cut a quadrangular hole of 880x880mm in the ceiling When handling the unit, take into account the following: according to the shape of the installation paper board. - Page 6 FIGURES Fig.5-1 Fig.5-2 Tubing side Drain side Connecting point of drain pipe Water pipe joint Ceiling Panel Outlet Inlet Outlet 880mm (ceiling hole) 780(Hook-location) Ground (Unit: mm) 840(Body) 950(Panel) Table 5-1 Size（mm） Model MKA-600R~MKA-750R MKA-850R~MKA-1500R MKA-850R~MKA-1500R >1000mm Slit Inner insulation Side plate >1000mm Fig.5-4...
-
Page 7: Connect The Drain Pipe
5.4 Install The Panel 6. CONNECT THE DRAIN PIPE CAUTION 6.1 Install the drain pipe of indoor unit Never put the panel face down on floor or against the 1) The drainpipe can use PVC pipe (external diameter about 37～ wall, or on bulgy objects. -
Page 8: Wiring
7. WIRING Gradient: 0.8～1.0 m higher than 1/100 CAUTION The air conditioner should use separate power supply with rated voltage. The external power supply to the air conditioner should have ground wiring, which is linked to the ground wiring of the indoor and outdoor unit. -
Page 9: Test Operation
