INSTALLATION
INSTRUCTIONS
© Copyright 2004
QTEC SERIES
PACKAGED HEAT PUMP
QH244D
QH363D
QH483D
Bard Manufacturing Company
Bryan, Ohio 43506
Since 1914 . . . Moving ahead, just as planned.
Models:
QH303D
QH423D
QH603D
MIS-1554
Manual:
Supersedes: 2100-435C
File:
Date:
2100-435D
Vol II Tab 14
02-10-06
Manual 2100-435D
Page
1 of 38
