Literature Assembly
911-0825
Contains the following:
2100-034(F)
2100-479
2100-383(C)
2100-738(A)
User's Guide
Leak Test, Evacuation, Charging
QWV Installation Instructions
QW*S3 Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Q-TEC Series and is the answer not in the manual?

Questions and answers

Related Manuals for Bard Q-TEC Series

Summary of Contents for Bard Q-TEC Series

  • Page 1 Literature Assembly 911-0825 Contains the following: 2100-034(F) User’s Guide 2100-479 Leak Test, Evacuation, Charging 2100-383(C) QWV Installation Instructions 2100-738(A) QW*S3 Installation Instructions...
  • Page 2 USER’S GUIDE For all Packaged Systems (Air Conditioners and Heat Pumps) WA & WL - Series Air Conditioners IH - Series Air Source Heat Pumps WH & SH - Series Air Source Heat Pumps PA - Series Air Conditioners PH - Series Air Source Heat Pumps QA - Series Air Conditioners QH - Series Air Source Heat Pumps MANUAL 2100-034 REV.
  • Page 3 TABLE OF CONTENTS General Information Air Filters Page 3 Outdoor Coil Page 3-4 Routine Equipment Outdoor Maintenance Page 4 Basic Operating Principles Air Conditioners Page 4-5 Heat Pump (Air-to-Air) Page 5-6 Heat Pump (Water-to-Air) Page 6 Ventilation Page 7 Dehumidification Circuits Page 7 Automatic Control Systems Thermostats...
  • Page 4 This manual is generic in nature and covers a wide range of heating and cooling products manufactured by Bard Manufacturing Company. It is intended to be a general guide for care and operation of typical systems and covers the most important features you should be aware of and are responsible for as the user of the equipment.
  • Page 5 Depending on the specific equipment involved, the surface that can accumulate debris can be on the opposite side that is exposed to view when standing in front of the machine. Closely review the machine when operating to see which direction or path that the airflow moves through the machine, and if the air inlet side of the coil is hidden, try to observe the back (hidden) side by looking into the side grilles, using flashlight if necessary.
  • Page 6 stream in the process. It may take several hours to pull down a hot, moist building or structure on initial startup, or anytime the system has been turned off for a long period of time. It is generally best to set the thermostat at a comfortable temperature and let it control the system as needed, rather than turning it on and off.
  • Page 7 The length of the defrost cycle will vary depending upon actual outdoor temperature, humidity levels and amount of accumulated frost. It could range from 1-2 minutes up to but not exceeding 10 minutes. When the defrost cycle terminates, the reversing valve will shift back to heating mode and the outdoor fan will restart.
  • Page 8 User’s Guide. Many installers also install thermostats other than those offered by Bard, and must determine proper compatibility prior to installation.
  • Page 9 50 and 60% Relative Humidity (RH) and typically affords acceptable human comfort conditions for most individuals, and under no circumstances should be set lower than 40% as overcooling of the conditioned space and/or freeze-ups of the indoor coil may occur. INSUFFICIENT COOLING OR HEATING In extremely hot or cold weather your system will continue to deliver its normal supply of conditioned air.
  • Page 10 HELPFUL HINTS AND GOOD OPERATING PRACTICES The following information will help you enjoy the full comfort and benefits of your Bard cooling and heating system, maximize the performance and efficiency, and help extend the life of your system: 1. Always keep the equipment in peak operating condition with routine scheduled maintenance, especially for the air filters and to assure clean outdoor coil.
  • Page 11 SERVICING PROCEDURE R-410A LEAK TEST EVACUATION CHARGING Bard Manufacturing Company, Inc. Manual No.: 2100-479 Supersedes: NEW Bryan, Ohio 43506 File: Volume I, Tab 1 Since 1914...Moving ahead, just as planned. Date: 03-08-07 Manual 2100-479 Page 1 of 11...

  • Page 12: Table Of Contents

    CONTENTS General Troubleshooting the Mechanical System Recovery Equipment Rated for R-410A ....3 Air Conditioning & Heat Pump - Cooling .....9 Leak Detectors ............3 Gauge Manifold ............3 Low Suction — Low Head Pressure ......9 High Suction — Low Head Pressure ......9 Attaching Gauge Manifold ........3 Low Suction —...

  • Page 13: General

    GENERAL GAUGE MANIFOLD WARNING WARNING The oils used with R-410A refrigerant are hydroscopic and absorb water from the Gauge manifold must be suitable for use atmosphere readily. Do not leave systems with R-410A refrigerant and POE oils. open to the atmosphere for more than 5 minutes.

  • Page 14: Attaching Manifold Hose To Schrader Valve

    3. Close drum valve and disconnect from center port. ATTACHING MANIFOLD HOSE TO Release nitrogen or CO2 into the atmosphere through SCHRADER VALVE suction line of gauge manifold. 4. Correct any leaks and recheck. When leaks, if any, WARNING have been repaired, system is ready to be evacuated and charged.

  • Page 15: Charging

    R-410A System Charging CHARGING THE SYSTEM BY WEIGHT Even though R-410A has a very small fractionation potential, 1. Connect manifold as instructed. it cannot be ignored completely when charging. To avoid fractionation, charging of an air conditioner or heat pump 2.

  • Page 16: Figure 1: Typical Ac System Cooling Cycle

    FIGURE 1 TYPICAL AIR CONDITIONING SYSTEM COOLING CYCLE MIS-369 Manual 2100-479 Page 6 of 11...

  • Page 17: Figure 2: Typical Hp System Cooling Cycle

    FIGURE 2 TYPICAL HEAT PUMP SYSTEM COOLING CYCLE MIS-368 Manual 2100-479 Page 7 of 11...

  • Page 18: Figure 3 Heating Cycle

    WARNING To speed refrigerant flow, it may be necessary to place refrigerant drum in a pan of warm water (not greater than 130ºF). Remember to either consider the total weight of the pan of water or remove the drum for weighing frequently to keep track of the charging process.

  • Page 19: Troubleshooting The Mechanical System

    roubleshooTing The echanical ysTeM AIR CONDITIONING AND HEAT PUMP — COOLING LOW SUCTION — LOW HEAD LOW SUCTION — HIGH HEAD PRESSURE PRESSURE 1. Restricted ��� over indoor coil. 1. Partial restriction and then overcharged. 2. Defective indoor fan motor. HIGH SUCTION — HIGH HEAD 3.
  • Page 20 Manual 2100-479 Manual 2100-479 Page 10 of 11 Page 10 of 11...
  • Page 21 Manual 2100-479 Manual 2100-479 Page 11 of 11 Page 11 of 11...
  • Page 23 INSTALLATION INSTRUCTIONS QW SERIES WALL SLEEVE Models: QWVS42 QWVS42-19 QWVS42-H MIS-1608 Bard Manufacturing Company, Inc. Manual: 2100-383C Bryan, Ohio 43506 Supersedes: 2100-383B Date: 10-8-15 www.bardhvac.com Page 1 of 9...
  • Page 24 CONTENTS Figures Getting Other Information and Publications ...3 Figure 1 Wood Framed Installation ......4 Installation ..............4 Figure 2 Application of Sealant to Flanges ....5 Shipping Damage ..........4 Figure 3 Masonry Construction Installation ..... 6 General ..............4 Figure 4 Typical Installation ........7 Installation Wood Framed Walls.......

  • Page 25: Getting Other Information And Publications

    Heating and Air Conditioning Systems ASHRAE American Society of Heating, Refrigerating, and Air Conditioning Engineers, Inc. 1791 Tullie Circle, N.E. QW Installation Instruction Manual ..Bard/2100-381 Atlanta, GA 30329-2305 Telephone: (404) 636-8400 Fax: (404) 321-5478 BARD Bard Manufacturing Company, Inc.

  • Page 26: Figure 1

    INSTALLATION SHIPPING DAMAGE national and/or local codes in any way. Authorities having jurisdiction should be consulted before the Upon receipt of equipment, the carton should be installation is made. checked for external signs of shipping damage. If damage is found, the receiving party must contact INSTALLATION –...

  • Page 27: Application Of Sealant To Flanges

    FIGURE 2 Application of Sealant to Flanges SEAL ALL (4) FLANGES 17 23/32" SEAL ALL NOTCHES IN ALL (4) CORNERS MIS-1609 A Manual 2100-383C Page 5 of 9...

  • Page 28: Masonry Construction Installation

    The sleeve is then re-inserted into the prepared opening the sleeve and attach with three screws per side. Roll from the outside of the building. All of the mounting unit up to sleeve making sure the cabinet rear is tight flanges must contact the exterior wall.

  • Page 29: Typical Installation

    should be drilled through the holes in the sleeve with sleeve must be anchored to the wall. All four mounting the sleeve level and square in the opening. A slope is flanges must be fastened with two fasteners each to built into the bottom of the sleeve from the inside to the outside wall.
  • Page 30 FIGURE 5 Installation of QW Wall Sleeve Through a Window Opening INSULATION UNIT WALL SLEEVE SHOWN WITHOUT OUTSIDE GRILLE MOUNTING BRACKET SLEEVE SPACER FOR GRILLE CLEARANCE 2.500 *32.750 SILL HEIGHT= X SIDE SPACER TO MAINTAIN THE 32.750 RELATIONSHIP BETWEEN WALL SLEEVE AND UNIT OPENING SPACER SIZE UNDER UNIT= X + 2.5 - 32.750 *THIS DIMENSION MUST REMAIN CONSTANT WHEN FABRICATING UNIT AND WALL SLEEVE...

  • Page 31: Installation Through A Window Opening

    INSTALLATION THROUGH A WINDOW The sleeve should be test fit into the opening to make sure of the dimensions. The sleeve must be inserted OPENING into the opening from the outside of the building. The NOTE: Depending on the window sill height as bottom of the sleeve must be level from side-to-side, measured from the inside finished floor, a spacer may and the sleeve must be square in the opening.
  • Page 33 QW4S3DB QW5S3DB QW2S3DC QW3S3DC QW4S3DC QW5S3DC Earth Loop Fluid Temperatures 25 – 110 Ground Water Temperature 45 – 75 MIS-2736 MIS-2736 Bard Manufacturing Company, Inc. Manual No.: 2100-738A Bryan, Ohio 43506 Supersedes: 2100-738 Date: 1-29-20 www.bardhvac.com Page 1 of 71...
  • Page 34 CONTENTS Getting Other Information and Publications Closed Loop (Earth Coupled Ground Loop Applications) For more information, contact these publishers: ..4 Circulation System Design ........51 Copper Water Coil Application ......51 QW General Information Start Up Procedure for Closed Loop System ..52 QW Model Nomenclature........
  • Page 35 Figures Tables Figure 1 Unit Dimensions ........8 Table 1A Electrical Specifications ......6 Figure 2 Removal of Unit From Skid ....9 Table 1B Electrical Specifications ......7 Figure 3 Proper Handling of Unit After Removal Table 2 Operating Voltage Range ....... 20 from Skid ..........
  • Page 36 GETTING OTHER INFORMATION AND PUBLICATIONS FOR MORE INFORMATION, CONTACT THESE These publications can help with installing the heat pump. They can usually be found at the local library PUBLISHERS: or purchased directly from the publisher. Be sure to consult current edition of each standard. ACCA Air Conditioning Contractors of America 1712 New Hampshire Avenue...
  • Page 37 QW SERIES GEOTHERMAL R-410A STAGED CAPACITY GENERAL INFORMATION MODEL NUMBER | COIL OPTIONS FILTER OPTIONS Q-TEC™ Model C – Copper Coaxial Coil 0Z – OKW X – 2-Inch Pleated N – Cupronickel Coaxial (MERV8) CAPACITY | Coil 2 – 2 Ton NOTE: Copper coils 3 –...
  • Page 38 TABLE 1A Electrical Specifications Specifications - 2 and 3 Ton MODELS QW2S3-A QW2S3-B QW2S3-C QW3S3-A QW3S3-B QW3S3-C Electrical Rating - 60 Hertz 230/208-1 230/208-3 460-3 230/208-1 230/208-3 460-3 Operating Voltage Range 253-197 VAC 414-506 VAC 253-197 VAC 414-506 VAC Minimum Circuit Ampacity ++ Delay Fuse or Circuit Breaker Max COMPRESSOR - CIRCUIT A Voltage...
  • Page 39 TABLE 1B Electrical Specifications MAXIMUM MINIMUM NO. FIELD EXTERNAL FUSE FIELD POWER GROUND RATED VOLTS, CIRCUIT Model POWER OR CIRCUIT WIRE SIZE WIRE SIZE Hz & PHASE AMPACITY CIRCUITS BREAKER   QW2S3DA0Z 230/208-60-1 QW2S3DB0Z 230/208-60-3 QW2S3DC0Z 460-60-3 QW3S3DA0Z 230/208-60-1 QW3S3DB0Z 230/208-60-3 QW3S3DC0Z...
  • Page 40 Manual 2100-738A Page 8 of 71...

  • Page 41: Shipping Damage

    SHIPPING DAMAGE HANDLING UNIT AFTER REMOVAL FROM SKID Upon receipt of equipment, the carton should be checked for external signs of shipping damage. The WARNING skid must remain attached to the unit until the unit is ready for installation. If damage is found, the receiving party must contact the last carrier immediately, Exercise extreme caution when pushing the preferably in writing, requesting inspection by the...

  • Page 42: Removal Of Wall Bracket From Shipping Location

    FIGURE 3 Proper Handling of Unit after Removal from Skid Q-TEC UNIT (RIGHT SIDE) STRAP APPLIANCE CART COMPRESSOR REMOVAL OF WALL BRACKET FROM While these instructions are intended as a general recommended guide, they do not supersede any SHIPPING LOCATION (UNITS WITH national and/or local codes in any way.
  • Page 43 FIGURE 4 Installation of Unit through Wall with Wall Sleeve 14" to 5" WALL SLEEVE VENTILATION AIR DIVIDER QW2S, QW3S - 42.000" QW4S, QW5S - 48.000" 33 7/8" SUPPLY AIR 28 7/8" 18 9/16" OPTIONAL FREE BLOW PLENUM BOX HIGH VOLTAGE ELECTRICAL ENTRANCE (TOP-REAR-SIDE) 17 9/16"...
  • Page 44 FIGURE 5 Installation with Free Blow Plenum 8 FT. - 9 IN. 8 FT. - 8 IN. MINIMUM REQUIRED INSTALLATION HEIGHT FLOOR MIS-2740 FIGURE 6 Ducted Application SUSPENDED CEILING MODEL "A" DUCT FIXED CEILING QW2S, QW3S 25" "A" DUCT FLANGE QW4S, QW5S 30"...

  • Page 45: Duct Work

    The condensate drain hose is routed down from the evaporator drain pan on the right side of the unit The Q-TEC Series heat pumps are designed for use into the compressor compartment. There are three with free return (non-ducted) and either free blow locations that the drain can exit the cabinet.
  • Page 46 FIGURE 8A Condensate Drain LOOP TO FORM A "P" TRAP DRAIN HOSE EXTERNAL DRAIN TUBE ALTERNATE DRAINING FLOOR OPTION FRONT VIEW WITH CONDENSER DOOR REMOVED MIS-2743 The drain can be routed through the floor or through the wall. If the drain is to be routed through an unconditioned space, it must be protected from freezing.

  • Page 47: Mist Eliminator Service

    The rear drain can be used with wall thickness of up to MIST ELIMINATOR SERVICE 10 inches where a water trap can be installed between (Optional – only used with one of the the unit and the interior wall (see Figure 8B). The trap vent options) cannot extend beyond the edge of the unit or it will A mist eliminator is supplied with the wall sleeve.
  • Page 48 disconnect this plug, the tabs on both sides of the Q-TEC Energy Recovery Ventilator Option plug must be squeezed to release the plug. While Before starting the removal make sure that the power squeezing the tabs, pull the plug out of the socket. has been turned off.

  • Page 49: Installation

    INSTALLATION MOUNTING THE UNIT 7. Position side trim pieces to the wall and attach with field-supplied screws. There are two long and When installing a QW unit near an interior wall on the two short pieces supplied. The long pieces are to left side, a minimum of 8 inches is required;...
  • Page 50 FIGURE 11 Unit Mounting without Ventilation Wall Sleeve SIDE TRIM CUT TO LENGTH WALL MOUNTING BRACKET 41" ADJUSTABLE SIDE TRIM EXTENSION KIT -ORDERED SEPARATELY BASE TRIM SIDE TRIM EXTENSION BASE TRIM EXTENSION MIS-2744 A Manual 2100-738A Page 18 of 71...
  • Page 51 FIGURE 12 Component Location SIDE FIELD WIRE ENTRANCE REMOTE THERMOSTAT TERMINAL BLOCK INDOOR DUAL BLOWERS CONTROL BOX/ CIRCUIT BREAKER PANEL MIS-2745 Manual 2100-738A Page 19 of 71...

  • Page 52: Wiring - Main Power

    WIRING – MAIN POWER The standard Climate Control Option X is a remote thermostat connection terminal block. See Figure Refer to the unit rating plate and/or Table 1B (page 7) 14 on page 22 for wiring diagram. Compatible for wire sizing information and maximum fuse or circuit thermostats are listed in Table 3.

  • Page 53: Low Voltage Connections

    LOW VOLTAGE CONNECTIONS The “W2” terminal is the auxiliary heat signal and feeds through Pin #9 of Plug P2. The “R” terminal is the 24 VAC hot terminal and is The “W1/E” terminal is the emergency heat signal and supplied through Pin #10 of Plug P2. feeds through Pin #3 of Plug P2.
  • Page 54 FIGURE 14 Remote Thermostat Wiring Diagram “X” Option Temp. and Humidity Temp. and Humidity Controller Controller Low Voltage Part #8403-081 Part #8403-060 Terminal Strip Red/Yellow W1/E Purple Brown/White PLUG #2 Orange Yellow Blue Brown Red/White Black/White Pink D/YO CO2 Controller Terminal PLUG #1 Part #8403-067...
  • Page 55 FIGURE 15 Factory-Mounted Thermostat Wiring Diagram “D” Thermostat Option Purple/White D/YO Red/Yellow W1/E Purple Brown/White PLUG #2 Orange Yellow Blue Brown Red/White Black/White Pink Temp. and Humidity Controller Part #8403-060 4115-100 A Manual 2100-738A Page 23 of 71...
  • Page 56 FIGURE 16 Factory-Mounted Thermostat and CO Vent Control Wiring Diagram “H” Thermostat Option Purple/White D/YO Red/Yellow W1/E Purple Brown/White PLUG #2 Orange Temp. and Humidity Controller Yellow Part #8403-060 Blue Brown Red/White Black/White Pink CO2 Controller Part #8403-067 PLUG #1 24VAC Black Black...
  • Page 57 FIGURE 17 Remote Thermostat with Mounted/Wired CO Control Wiring Diagram “K” Thermostat Option Low Voltage Terminal Strip Red/Yellow Purple Brown/White PLUG #2 Orange Yellow Blue Brown Red/White Black/White Pink CO2 Controller Part #8403-067 PLUG #1 24VAC Black Black Yellow CO2-OUT Yellow Orange Green...
  • Page 58 Temperature/Humidity Control "1" & "3" Option Wiring Diagram Plug #2 9 Purple/White Brown/White Brown W1/E Red/Yellow Purple Yellow Blue Orange Red/White Black/White Black/White Gray Pink Gray COMPLETESTAT TEMPERATURE, HUMIDITY, AND OCCUPANCY CONTROLLER. BARD PART# CS9B-THO ALARM RELAY OR CS9BE-THO 4115-108 Manual 2100-738A Page 26 of 71...
  • Page 59 Control "2" & "4" Option Wiring Diagram Plug #2 9 Purple/White Brown/White Brown W1/E Red/Yellow Purple Yellow Blue Orange Red/White Black/White Black/White Gray Pink Gray COMPLETESTAT TEMPERATURE, HUMIDITY, OCCUPENCY, AND CO2 CONTROLLER. BARD PART# CS9B-THOC ALARM RELAY OR CS9BE-THOC 4115-109 Manual 2100-738A Page 27 of 71...

  • Page 60: Valve And Actuator Installation/Removal

    VALVE AND ACTUATOR INSTALLATION/REMOVAL VALVE INSTALLATION FIGURE 21 iSeries Smart Actuator Removal 1. The valve body may be installed in any orientation, as shown in Figure 20. However, the 3-way actuator’s power connections must be over the closed off port to ensure proper function and flow direction.

  • Page 61: Start Up

    START UP DESCRIPTION OF STANDARD the event of a high or low pressure switch lockout, a EQUIPMENT visual indication can be seen from the geothermal logic control board. See Troubleshooting section on page 62 for further explanation. Low Pressure Switch NOTE This unit is supplied with two low pressure Geothermal Compressor Control Module...

  • Page 62: Important Installer Note

    IMPORTANT INSTALLER NOTE Intelligent Reset The compressor logic control board has an intelligent For improved start up performance, wash the indoor reset feature after a safety control is activated. The coil with dishwashing detergent. controller locks out the unit for 5 minutes; at the end of this period, the controller checks to verify that all PHASE MONITOR faults have been cleared.

  • Page 63: Adjustments

    ADJUSTMENTS FIGURE 23 Control Configuration PRESS UP AND DOWN ARROWS TO ENTER CONFIGURATION MODE USE ARROWS TO SELECT SETTING. PUSH MIDDLE BUTTON TO CHANGE. CONTROLLER WILL SHOW SET. NOTE: MENU JUMPER MUST JUMPERS MUST BE BE SET TO "ON" POSITIONED AS SHOWN TO CHANGE ANY FOR PROPER OPERATION SETTINGS WITH...

  • Page 64: Pressure Service Ports

    SYSTEM START UP PRESSURE SERVICE PORTS Step 1 – Close disconnect switch(es) and set the High and low pressure service ports are installed on thermostat to cool and temperature to the all units so that the system operating pressures can be highest setting.
  • Page 65 FIGURE 24 Fluid Connections on Unit with Ventilation Wall Sleeve SIDE TRIM PIECES (SHIPPED WITH UNIT) IF THE WALL THICKNESS IS LESS THAN 14" BUT GREATER THAN 8", SIDE TRIM PEICES A SIDE TRIM EXTENSION KIT (SHIPPED WITH UNIT) QSTX42 IS REQUIRED. REFER TO UNIT SPEC.
  • Page 66 FIGURE 25 Fluid Connections on Unit without Ventilation Wall Sleeve TOP VIEW WALL BRACKET WALL BRACKET 4" WATER LINES WALL LOCATION BACK OF UNIT FLUID ACCESS FROM TOP 66 1/2" OPENING IN WALL BRACKET REAR OF UNIT (LEFT BRACKET 3" x 8" REMOVED FOR CLARITY) 8 1/2"...
  • Page 67 TABLE 5 Pressure Table Return Air FULL LOAD COOLING – Fluid Temperature Entering Water Coil °F Model Pressure Temperature 30°F 35°F 40°F 45°F 50°F 55°F 60°F 65°F 70°F 75°F 80°F 85°F 90°F 95°F 100°F 105°F 110°F 75° DB Low Side 62°...
  • Page 68 Manual 2100-738A Page 36 of 71...

  • Page 69: Sequence Of Operation

    SEQUENCE OF OPERATION COOLING Alarm Output The L terminal has 24 volts applied when a hard A 24V solenoid coil on the reversing valve controls lockout occurs. This can be used to drive a fault light the cooling cycle operation. There are two different or low voltage relay.

  • Page 70: Modulating Water Line Control

    MODULATING WATER LINE CONTROL opens, compressor will go into soft lockout mode and compressor operation will be terminated; red fault On a call for cooling or heat pump (Y signal from light illuminated. Logic control will then go through thermostat), the Y terminal has 24 volts applied and 5-minute delay on break plus random start sequence.

  • Page 71: Iseries Smart Actuator

    iSERIES SMART ACTUATOR Setpoint As previously mentioned, the iSeries Smart Actuator Power Up and Dehum Request operates the valve to maintain a fixed setpoint. The Whenever the iSeries-S is powered up, the LED turns setpoint temperature is set using the setpoint dial green and the control starts operation (see Figure located on top of the actuator.

  • Page 72: Dehumidification

    DEHUMIDIFICATION MODEL FEATURES latent capacities, water removal ratings and supply air delivery conditions. These models provide a unique dehumidification The dehumidification refrigerant reheat circuit is circuit for periods of high indoor humidity conditions. controlled by a 3-way valve in the refrigeration Additionally, an “energy recovery ventilator”...
  • Page 73 FIGURE 31 Cooling Mode and Dehumidification Mode Circuit Diagrams BULB HEAT PUMP COOLING MODE CIRCUIT DIAGRAM INDOOR COIL DISTRIBUTOR EXPANSION VALVE FILTER/ DRIER REHEAT COIL EXPANSION VALVE 4 WAY VALVE CHECK VALVE CHECK VALVE WATER OPEN CIRCUIT WATER 4 WAY COIL VALVE BULB...
  • Page 74 TABLE 7A QW2S3D Dehumidification Performance – Cooling Full Load (Full Load Capacities Based Upon Rated Flow of 7 GPM of 15% Methanol/Mass at 950 CFM Airflow) Pounds of Entering Total Sensible Latent Approximate Supply Air Entering Air Water per Sensible to Fluid Capacity Capacity...
  • Page 75 TABLE 7B QW2S3D Dehumidification Performance – Dehumidification Full Load (Full Load Capacities Based Upon Rated Flow of 7 GPM of 15% Methanol/Mass at 950 CFM Airflow) Pounds of Entering Total Sensible Latent Approximate Supply Air Entering Air Water per Fluid Temp. Capacity Capacity Capacity...
  • Page 76 TABLE 8A QW3S3D Dehumidification Performance – Cooling Full Load (Full Load Capacities Based Upon Rated Flow of 8 GPM of 15% Methanol/Mass at 1150 CFM Airflow) Pounds of Entering Total Sensible Latent Approximate Supply Air Entering Air Water per Sensible to Fluid Temp.
  • Page 77 TABLE 8B QW3S3D Dehumidification Performance – Dehumidification Full Load (Full Load Capacities Based Upon Rated Flow of 8 GPM of 15% Methanol/Mass at 1150 CFM Airflow) Pounds of Entering Total Sensible Latent Approximate Supply Air Entering Air Water per Fluid Temp. Capacity Capacity Capacity...
  • Page 78 TABLE 9A QW4S3D Dehumidification Performance – Cooling Full Load (Full Load Capacities Based Upon Rated Flow of 9 GPM of 15% Methanol/Mass at 1650 CFM Airflow) Pounds of Entering Total Sensible Latent Approximate Supply Air Entering Air Water per Sensible to Fluid Temp.
  • Page 79 TABLE 9B QW4S3D Dehumidification Performance – Dehumidification Full Load (Full Load Capacities Based Upon Rated Flow of 9 GPM of 15% Methanol/Mass at 1650 CFM Airflow) Pounds of Entering Total Sensible Latent Approximate Supply Air Entering Air Water per Fluid Temp. Capacity Capacity Capacity...
  • Page 80 TABLE 10A QW5S3D Dehumidification Performance – Cooling Full Load (Full Load Capacities Based Upon Rated Flow of 9 GPM of 15% Methanol/Mass at 1650 CFM Airflow) Pounds of Entering Total Sensible Latent Approximate Supply Air Entering Air Water per Sensible to Fluid Temp.
  • Page 81 TABLE 10B QW5S3D Dehumidification Performance – Dehumidification Full Load (Full Load Capacities Based Upon Rated Flow of 9 GPM of 15% Methanol/Mass at 1650 CFM Airflow) Pounds of Entering Total Sensible Latent Approximate Supply Air Entering Air Water per Fluid Temp. Capacity Capacity Capacity...
  • Page 82 Table 11 Dehumidification Relay Logic Board Inputs to the Board Outputs from the Board Energize on Unit Occupied/ Mode RAT Y B W2 A1 D G G1 BK RV TWV W YO A2 Terminal Strip Unoccupied Blower Unoccupied G, A Blower Occupied Y1, O, G...

  • Page 83: Closed Loop

    The design eliminates most causes of system failure. eliminate this problem. Surprisingly, the heat pump itself is rarely the cause. Bard supplies a work sheet to simplify head loss Most problems occur because designers and installers calculations and circulator selection. Refer to forget that a closed loop earth coupled heat pump “Circulating Pump Work sheet”...

  • Page 84: Start Up Procedure For Closed Loop System

    START UP PROCEDURE FOR CLOSED recheck the selection of the loop pump module LOOP SYSTEM model for sufficient capacity. If the module selection is correct, there is probably trapped air or 1. Be sure main power to the unit is OFF at a restriction in the piping circuit.
  • Page 85 12. For iSeries Smart Actuator and water valve installation, refer to the VALVE AND ACTUATOR INSTALLATION/REMOVAL section on page 28. 13. It is advised to rotate the manual operation button, located on the top of the iSeries Smart Actuator, several times to make sure the water valve is loose and not seized before operation.

  • Page 86: Open Loop (Well System Applications)

    OPEN LOOP (Well System Applications) NOTE It is highly recommended on ground water Drain cocks (8 and 10) and tees have been included to systems (pump & dump) that a cupronickel permit acid cleaning the refrigerant-to-water coil should coaxial coil is utilized on the source side of the such cleaning be required.

  • Page 87: Well Pump Sizing

    WELL PUMP SIZING A. Connect a water flow meter to the drain cock between the constant flow valve and the Strictly speaking, sizing the well pump is the solenoid valve. Run a hose from the flow responsibility of the well drilling contractor. It is meter to a drain or sink.

  • Page 88: Water Corrosion

    WATER CORROSION 4. Scale Formation. Of all the water problems, the formation of scale by ground water is by far the Two concerns will immediately come to light when most common. Usually this scale is due to the considering a water source heat pump, whether for formation of calcium carbonate, but magnesium ground water or for a closed loop application: Will carbonate or calcium sulfate may also be present.

  • Page 89: Lake And Pond Installations

    FIGURE 34 Cleaning Water Coil Hose Bib (B) Isolation Valve Hose Bib (A) TO WATER COIL Pump FROM WATER COIL MIS-2750 LAKE AND POND INSTALLATIONS D. Size the pump to provide necessary GPM for the ground water heat pump. A 12 GPM or greater Lakes and ponds can provide a low cost source of water water flow rate is required on all modes when used for heating and cooling with a ground water heat pump.
  • Page 90 Manual 2100-738A Page 58 of 71...

  • Page 91: Cooling Tower/Boiler Application

    In the heating mode, heat is absorbed from the source WARNING water loop. A boiler can be utilized to maintain the loop at the desired temperature. In milder climates a “flooded tower” concept is often used. This concept Thin ice may result in the vicinity of the involves adding makeup water to the cooling tower discharge line.
  • Page 92 FIGURE 36 Water Source Heat Pump Cooling Cycle Manual 2100-738A Page 60 of 71...
  • Page 93 FIGURE 37 Water Source Heat Pump Heating Cycle Manual 2100-738A Page 61 of 71...

  • Page 94: Service

    (CO = unused) has a normally open contact. If any of the four switches fault, their The Bard QW*S3D Series is equipped with a high corresponding light will blink and initialize a soft pressure switch, low pressure switch and flow switch.

  • Page 95: Troubleshooting Water Modulating Actuator Diagnostics

    System Supply Sensor Fault DIAGNOSTICS Flash, Pause, The iSeries-S operates at a The Bard QW*S3D Series is equipped with a water Flash, ... fixed output modulating actuator. The water modulation is achieved through the operation of a TACO iSeries Smart Testing the Sensors Actuator, attached to a TACO 3-way valve.
  • Page 96 while this test is performed. The wiring terminals resistance, there may be a broken wire, a poor wiring are easily removed by pulling them from the iSeries connection or a defective sensor. If the resistance Smart Actuator. Using the information found in is very low, the wiring may be shorted, there may be Table 15, estimate the temperature measured by moisture in the sensor or the sensor may be defective.

  • Page 97: Troubleshooting Modulating Water Line Control Board

    FIGURE 40 Modulating Water Line Control Board WATER LINE CONTROL BOARD The Bard QW*S3D Series is equipped with a water line control board. The TACO 3-way valve adjustment, conducted by the TACO iSeries Smart Actuator, is generated through the water line control board. The...

  • Page 98: Compressor Solenoid

    COMPRESSOR SOLENOID A nominal 24-volt direct current coil activates the internal compressor solenoid. The input control circuit voltage must be 18 to 28 volt ac. The coil power requirement is 20 VA. The external electrical connection is made with a molded plug assembly. This plug contains a full wave rectifier to supply direct current to the unloader coil.
  • Page 99 TROUBLESHOOTING GE ECM 5.0 MOTORS ™ CAUTION: Symptom Cause/Procedure • Noisy blower or cabinet • Check for loose blower housing, panels, etc. Disconnect power from unit before removing or replacing • High static creating high blower speed? connectors, or servicing motor. To avoid electric shock - Check for air whistling through seams in ducts, cabinets or panels from the motor’s capacitors, disconnect power and wait...
  • Page 100 Replacing ECM Control Module replacement list. USING THE WRONG CONTROL WILL RESULT IN IMPROPER OR NO BLOWER OPERATION. To replace the control module for the GE variable-speed indoor Orient the control module so that the 3-wire motor plug blower motor you need to take the following steps: can be inserted into the socket in the control.
  • Page 101 Manual 2100-532G Page 46 of 48 Manual 2100-738A Page 69 of 71...

  • Page 102: Ground Source Heat Pump Performance Report

      Ground Source Heat Pump Performance Report    Date:   ____________________   Technician:  __________________________________________    Company Reporting:  ________________________  Contact Phone:  ____________________________    Owner’s Name:  ____________________________  Owner’s Address:  ___________________________    1. Model/Serial Numbers: (For 3‐Pc. Geo‐Trio system, include coil/compressor/blower information)     Model Number(s):  ______________________________________________________________     Serial Number(s):  _______________________________________________________________    2. Accessory Information:     Thermostat  Mfgr.  _____________________   Model/Part Number:  ___________________     Flow‐Center*  Mfgr.  _____________________   Model/Part Number:  ___________________  *if applicable    3. Open‐Loop Water Source Information:        Where/how is water discharged ___________________________________________________    4.  Closed‐Loop Water Source Information:      Horizontal Trenches ...
  • Page 103 The following information is needed to verify performance of the system.  Note:  Before testing, disable desuperheater, auxiliary electric heat, and any ventilation equipment  that may allow outdoor air into the system.  Measurements should be taken after a minimum 10 min.  run time to ensure “steady‐state” of operation.    Temperature and pressure measurements should be  taken with a single thermometer and pressure gauge to eliminate discrepancies between multiple  devices.      Fluid Data:   Stg. Cool   Stg. Cool   Stg. Heat   Stg. Heat  5. Entering Fluid Temperature    °F __________  __________  __________  __________  6. Leaving Fluid Temperature  °F __________  __________  __________  __________  7. Entering Fluid Pressure psi __________  __________  __________  __________  8. Leaving Fluid Pressure psi __________  __________  __________  __________  9. Pressure Drop through coil (psi)  __________ ...
  • Page 104 Literature Assembly 911-0825 Contains the following: 7960-356(D) Installation Instruction 7960-359(H) Installation Instructions 7960-438(B) Installation Instructions 2110-1558 Replacement Parts Manual 7960-420 Warranty...
  • Page 106 QLG-10, QLG-11, QLG-15, QLG-20, QLG-21, QLG-25, QLG-30, QLG-31, QLG-35 Bard Manufacturing Company, Inc. OUTDOOR LOUVER GRILLE Bryan, Ohio 43506 INSTALLATION INSTRUCTIONS WALL SLEEVE OUTDOOR LOUVER GRILLE ATTACHMENT SCREWS WALL 1. Remove the four screws holding the weather panel. Save these screws, they will be used to attach the grille.
  • Page 108 Q-TEC unit flange as shown in Figure 1. The outside of the plenum box should be flush with the outside of the unit. Bard Manufacturing Company, Inc. Manual: 7960-359H Bryan, Ohio 43506 Supersedes: 7960-359G...
  • Page 109 Figure 1 Plenum Box NOTE below Side grilles available only on QPBS models (see Table 1) Remove screw and reuse Plenum Box to attach plenum box Q-TEC Unit Flange Remove screw and reuse to attach plenum box Top of Q-TEC Unit NOTE: Height of plenum box is 14"...
  • Page 110 CABINET EXTENSION INSTALLATION INSTRUCTIONS QCX10A-4 QCX15A-4 QCX10A-V QCX15A-V Bard Manufacturing Company, Inc. Bryan, Ohio 43506 QCX10A-X QCX15A-X SIDE ANGLE BACK SUPPORT BACK SUPPORT SCREWS FRONT ANGLE SIDE ANGLE QCX CABINET EXTENSION QCX CABINET EXTENSION SCREWS TO BE REMOVED AND REUSED TO ATTACH...
  • Page 112 Wall Sleeve Cabinet Components time to time.  Exploded View ........... 22  Usage List ..........23  A complete and current manual consists of pages shown in the following contents section. Bard Manufacturing Company, Inc. Manual: 2110-1558 Bryan, Ohio 43506 Supersedes: Date: 12-12-19 www.bardhvac.com...
  • Page 113 CABINET COMPONENTS SEXP-652 Manual 2110-1558 Page 2 of 23...
  • Page 114 CABINET COMPONENTS QW2S3DA, DB, DC QW4S3DA, DB, DC Drawing No. Part No. Description QW3S3DA, DB, DC QW5S3DA, DB, DC S507-279 Top Assembly S507-278 Top Assembly 111-142 Outlet Duct Flange 111-138 Outlet Duct Flange 117-285 Low Voltage Box Assembly 136-359 T.K.O. Plate 509-231 Back Assembly 509-230...
  • Page 115 FUNCTIONAL COMPONENTS SEXP-1018 Manual 2110-1558 Page 4 of 23...
  • Page 116 FUNCTIONAL COMPONENTS Drawing Part No. Description S900-380-001 Blower Assembly S900-381-001 Blower Assembly S900-382-001 Blower Assembly S900-382-002 Blower Assembly 5625-007 Distributor Cooling 5625-008 Distributor Cooling 5625-010 Distributor Cooling 917-0086BX Evaporator Coil 917-0166BX Evaporator Coil 917-0089BX Evaporator Coil 5400-005 Hinge 5650-038 Reversing Valve with 24V Solenoid Coil 5650-039 Reversing Valve with 24V Solenoid Coil 5650-040...
  • Page 117 CONTROL PANEL COMPONENTS SEXP-1015 Manual 2110-1558 Page 6 of 23...
  • Page 118 CONTROL PANEL COMPONENTS Drawing Part No. Description 3000-1331 Wire Assembly (Blower Power) 3000-1677 Wire Assembly (Blower Control) 8615-037 Circuit Breaker 2 Pole 30A 8615-055 Circuit Breaker 2 Pole 40A 8615-040 Circuit Breaker 2 Pole 50A 8615-041 Circuit Breaker 2 Pole 60A 126-550 Circuit Breaker Base 8611-006...
  • Page 119 CONTROL PANEL COMPONENTS SEXP-1016 Manual 2110-1558 Page 8 of 23...
  • Page 120 CONTROL PANEL COMPONENTS Drawing Part No. Description 3000-1331 Wire Assembly (Blower Power) 3000-1677 Wire Assembly (Blower Control) 8607-017 Terminal Block 8615-054 Circuit Breaker 2 Pole 20A 8615-052 Circuit Breaker 2 Pole 30A 8615-042 Circuit Breaker 2 Pole 35A 8615-043 Circuit Breaker 2 Pole 40A 8615-067 460V Toggle Disconnnect 127-549...
  • Page 121 BLOWER ASSEMBLY COMPONENTS SEXP-1017 Manual 2110-1558 Page 10 of 23...
  • Page 122 BLOWER ASSEMBLY COMPONENTS Drawing Part No. Description 5152-096 Blower Wheel 5152-011 Blower Wheel 5152-072 Blower Wheel 5152-012 Blower Wheel S8105-060-0198 1/3 HP Programmed Motor S8106-052-0199 1/2 HP Programmed Motor S8107-017-0200 3/4 HP Programmed Motor S8107-017-0201 3/4 HP Programmed Motor C8105-060-0198 Programmed Motor Control Only C8106-052-0199 Programmed Motor Control Only...
  • Page 123 PUMP MODULE COMPONENTS PUMP ASSEMBLY RELAY ASSEMBLY SEXP-574 Manual 2110-1558 Page 12 of 23...
  • Page 124 PUMP MODULE COMPONENTS Drawing Part No. Description 8300-008 Circulating Pump UPS15-42F 8300-007 Circulating Pump UP26-64F 8300-009 Circulating Pump UPS26-99FC 141-346 Water Pump Bracket 113-399 Pump Relay Bracket 8614-036 Mini Circuit Breaker 3 Amp 8201-048 Relay DPDT Manual 2110-1558 Page 13 of 23...
  • Page 125 OPTIONAL CLIMATE CONTROLS SEXP-560 Manual 2110-1558 Page 14 of 23...
  • Page 126 OPTIONAL CLIMATE CONTROLS UNITS Drawing Part No. Description S127-313-* Thermostat Plate S127-308-* Thermostat Plate S127-372-* Thermostat Plate S127-409-* Plate 8403-060 Electronic/Programmable Manual/Auto Changeover 8403-067 Sensor with Relay 4115-100 Wiring Diagram 4115-101 Wiring Diagram 4115-102 Wiring Diagram 4115-105 Wiring Diagram 8607-021 Terminal Strip 8 Terminal 8607-029 Terminal Strip...
  • Page 127 OPTIONAL CLIMATE CONTROLS SEXP-639 Manual 2110-1558 Page 16 of 23...
  • Page 128 OPTIONAL CLIMATE CONTROLS Drawing Part No. Description 117-325 Control Panel 8201-130 Relay, SPDT, Pilot Duty S910-1820 Condensate Overflow Assembly 8403-068 Siemens DDC Interface 3000-1414 Wire Harness 4115-106 Wiring Diagram 133-122 Control Panel Cover Manual 2110-1558 Page 17 of 23...
  • Page 129 OPTIONAL CLIMATE CONTROLS SEXP-646 Manual 2110-1558 Page 18 of 23...
  • Page 130 OPTIONAL CLIMATE CONTROLS Drawing Part No. Description 117-328 Control Panel 117-329 Low Voltage Control Box 8607-029 Low Voltage Terminal Strip 910-1822 Condensate Overflow Assembly 8201-130 Relay, SPDT Pilot Duty 3000-1415 Wire Harness 4115-107 Wiring Diagram 133-222 Control Panel Cover Manual 2110-1558 Page 19 of 23...
  • Page 131 OPTIONAL CLIMATE CONTROLS SEXP-645 Manual 2110-1558 Page 20 of 23...
  • Page 132 OPTIONAL CLIMATE CONTROLS Drawing Part No. Description 127-427-* Thermostat Mounting Plate CS9B-THO CompleteStat TEMP/HUM/OCC CS9B-THOC CompleteStat TEMP/HUM/OCC/CO2 CS9BE-THO CompleteStat TEMP/HUM/OCC with BACnet CS9BE-THOC CompleteStat TEMP/HUM/OCC/CO2 with BACnet 3000-1416 Wire Assembly 8201-130 Relay, SPDT Pilot Duty 117-330 Relay Box 133-226 Relay Box Cover Manual 2110-1558 Page...
  • Page 133 WALL SLEEVE CABINET COMPONENTS SEXP-377 Manual 2110-1558 Page 22 of 23...
  • Page 134 WALL SLEEVE CABINET COMPONENTS Drawing Part No. Description 142-076 Cover 121-350-X Top Partition 105-1103-X Angle 110-073-X Left Side 110-074-X 7003-056 Mist Eliminator 111-076-X Air Deflector 121-349-X Partition 110-072-X Right Side 165-566-X Upper Support Channel 110-075-X Base 165-567-X Lower Support Channel Manual 2110-1558 Page...
  • Page 136 If you can not show us the actual date of purchase, the time periods in this warranty will start on the date that we shipped your Bard product from our factory.
  • Page 137  Factory coated coils have a “5” year warranty in corrosive environments that are listed as approved. Internet Resources Recognized as a leader in the HVAC industry, Bard combines quality products and outstanding service with innovation and technological advances to deliver high- performance heating and cooling products around the world. Please visit www.bardhvac.com...

This manual is also suitable for:

Qw seriesQwvs42Qwvs42-19Qwvs42-hQw2s3daQw2s3db ... Show all

Table of Contents
