Page 1: Installation Instructions
E SERIES 1200 Installation Instructions 234 F , CA 92626 ISCHER VENUE OSTA (714) 424-6500 (800) 840-0288 (714) 424-6510 http://www.channelvision.com E-Mail: sales@channelvision.com © 2001, C ™ HANNEL ISION... -
Page 2: System Design Considerations
Simply follow the installation instructions below and you will enjoy the convenience of Channel Vision for years to come! Installation Instructions Step 1: Find an unused channel between 65-135 for cable or 14-78 for UHF. -
Page 3: System Installation Checklist
E Series 1200 Basic Setup Cable or Antenna 3102 Filter Channel Vision MULTI ROOM VIDEO TECHNOLOGY CVT - 15PIA HS-2 HS-8 To TV's FCC Regulations – the Cable TV Act “Cable home wiring” is the cable wiring located inside a Cable TV sub- scriber’s home or apartment that has been installed by a cable operator or... -
Page 4: Troubleshooting
2. When laying out your system, there will be approximately 5dB of signal loss per 100' of RG6. 3. Be sure ALL of your splitters and amplifiers are broadband. Splitters should be 5MHz to 1GHz, and amps should be 40MHz to 1GHz. - Page 5 leakage may occur or if the shielding braid is touching the center conductor. Install model CVT-15PIA amplifier after the combiner. Grainy Modulated Channel : Good Picture on the Cable Channels Disconnect cable channels from the system and check the modulated channels. A) If the modulated channels are good, use a low pass filter to "clean-up"...
-
Page 6: Specifications
Channel Vision Technology will repair or replace any defect in material or workmanship which occur during normal use of this product with new or rebuilt parts, free of charge in the USA, for two years from the date of original purchase. This is a no hassle warranty with no mail in warranty card needed. This warranty does not cover damages in shipment, failures caused by other products not supplied by Channel Vision Technology, or failures due to accident, misuse, abuse, or alteration of the equipment.
