- Page 1 INCANTO HD8919 EN USER MANUAL DE BENUTZERHANDBUCH ES MANUAL DEL USUARIO FR MODE D’EMPLOI IT MANUALE UTENTE NL GEBRUIKSAANWIJZING 4219.460.3600.1 HD8919 SAECO_INCANTO OTC EXTRA_WE_COVER_A5_FC.indd 1 01-09-16 15:22...
- Page 2 ESPRESSO CAPPUCCINO ESPRESSO LUNGO LATTE MACCHIATO AROMA STRENGTH MENU...
-
Page 3: Machine Overview
English Machine overview User interface Cover of bean hopper ESPRESSO button Bean hopper ESPRESSO LUNGO button Brew group AROMA STRENGTH button Inside of service door with cleaning instructions Standby button Coffee exit duct MENU button Coffee residues drawer LATTE MACCHIATO button Coffee grounds container CAPPUCCINO button Drip tray cover... -
Page 4: First Installation
English - This is the QR code. Scan this code to access instruction videos on how to brew the best coffees, how to clean the machine and for a list of frequently asked questions. (www.saeco.com/care) - The separate booklet with important safety information. First installation For first installation, follow the instructions on the separate quick start guide. -
Page 5: Replacing The Aquaclean Filter
English 2 Press the MENU button, select MENU and press the OK button to confirm. Scroll to AQUACLEAN FILTER. Press the OK button to confirm. The display shows the number of AquaClean filters that have been installed previously from 0 to 8 filters. NEW? 0 / 8 3 Select ON on the display, press the OK button to confirm. -
Page 6: Replacing The Aquaclean Filter After 8 Filters Were Used
English The display automatically updates the number of filters used. 4 Dispense 2 cups of hot water (0.5 l) to complete the activation. Discard AQUA CLEAN this water. FILTER 2 / 8 Replacing the AquaClean filter after 8 filters were used 1 When the filter icon starts flashing on the display, press the MENU button, scroll to AQUACLEAN FILTER and press the OK button to confirm. -
Page 7: Control Panel And Display
English Control panel and display This espresso machine has a self-explaining display for easy use. Read the sections below for a quick explanation of the buttons. One-touch beverage buttons Use the one-touch beverage buttons (ESPRESSO, ESPRESSO LUNGO, CAPPUCCINO and LATTE MACCHIATO) to quickly prepare one of the preset beverages. -
Page 8: Brewing Coffee With Beans
English Brewing coffee Brewing coffee with beans Caution: Only use espresso beans. Never put ground coffee, unroasted coffee beans or caramelized coffee beans in the bean hopper, as this may cause damage to the machine. To brew coffee, follow the instructions on the separate quick start guide. To brew two cups of espresso or espresso lungo, press the button of the desired beverage twice. -
Page 9: Dispensing Hot Water
English Dispensing hot water Caution: Steam and hot water may spray out of the hot water dispensing spout when brewing starts. Wait until brewing has ended before you remove the hot water dispensing spout. 1 Insert the hot water dispensing spout. 2 Press the MENU button. -
Page 10: Beverage Types And Lengths
English Beverage types and lengths Beverage types Beverage name Description How to select Espresso Coffee with thick crema served in a One-touch beverage button on small cup control panel Espresso Lungo A longer espresso with thick crema One-touch beverage button on served in a medium-sized cup control panel Cappuccino... -
Page 11: Adjusting Coffee Strength
English Note: To set the volume of espresso lungo, cappuccino and latte macchiato, follow the same procedure: press and hold the button of the beverage and press the OK button when the cup contains the desired amount. To adjust the volume of milk-based coffee beverages, first insert the milk carafe and save the milk volume and then save the coffee volume. -
Page 12: Cleaning And Maintenance
English Cleaning and maintenance Note: Consult the table below for when and how to clean all detachable parts of the machine. For more detailed information on how to clean the brew group and how to descale the machine, read the corresponding www.saeco.com/care chapters below or go to the dedicated website Cleaning table... -
Page 13: Cleaning The Brew Group Under The Tap
English Part description When to clean How to clean Pre-ground coffee Weekly Clean the top part with a spoon handle as shown compartment/coffee below. exit duct Cleaning the brew group www.saeco.com/care Note: Scan the QR code or go to for detailed instructions on how to disassemble and clean the brew group. -
Page 14: Reinserting The Brew Group
English 3 Put a coffee oil remover tablet in the pre-ground coffee compartment. 4 Press the ESPRESSO LUNGO button. The machine dispenses water from the coffee dispensing spout. 5 When the progress bar has reached the middle, set the main switch on the back of the machine to OFF. -
Page 15: Lubrication Frequency
English The hook is not positioned correctly if it is still in bottommost position. 3 Slide the brew group back into the machine along the guiding rails on the sides until it locks into position with a click. Caution: Do not press the PUSH button. 4 Close the service door. -
Page 16: Thorough Cleaning Of The Milk Carafe
English Note: Make sure the milk dispensing spout is pulled out. 3 Press the OK button to start dispensing hot water. Thorough cleaning of the milk carafe To clean the milk carafe thoroughly, you have to do the following regularly: 1 Remove the lid of the milk dispensing unit. -
Page 17: Monthly Cleaning Of The Milk Carafe
English 2 Turn the milk dispensing unit upside down and hold it firmly in your hand. Pull the milk tube off the rubber support. 3 Press the release buttons on the milk frother and remove the milk frother from the the rubber support. 4 Pull the milk frother connector out of the milk frother. -
Page 18: Descaling Procedure
English 9 Press the MENU button and select MILK FROTH in the DRINKS menu to start the carafe rinsing cycle. 10 Repeat step 9 until the milk carafe is empty. Note: Never drink the solution dispensed during this step. 11 Repeat steps 6-10. 12 When the machine stops dispensing water, the cleaning cycle is finished. -
Page 19: What To Do If The Descaling Procedure Is Interrupted
English The display reminds you that you have to open the milk dispensing spout. The display reminds you that you have to remove the AquaClean filter. REMOVE FILTER Note: You can press the escape button to skip descaling. If you want to start the descaling procedure later, press the MENU button, select MENU and scroll to select DESCALING. -
Page 20: Warning Icons And Error Codes
English machine. If the machine gets stuck during descaling, you can exit the descaling procedure by pressing the standby button. If this occurs, or in case of a power failure or accidental disconnection of the cord, do the following: 1 Empty and rinse the water tank thoroughly. 2 Fill the water tank up to the CALC CLEAN level indication and switch the machine back on. -
Page 21: Meaning Of The Error Codes
English Meaning of the error codes Below you find a list of the error codes that may appear on the display, their meaning and how to solve the problem. If these solutions do not help to remove the error code from the display and bring the machine back to normal working order, contact the Saeco hotline. - Page 22 English Problem Cause Solution Make sure the main switch is set to 'on' position (I). The machine is in DEMO You pressed the standby Switch the machine off and then on mode. button for more than 8 again with the main switch on the back seconds.
- Page 23 English Problem Cause Solution The machine is still in the You cannot remove the brew group descaling procedure. when the descaling procedure is active. First complete the descaling process and then remove the brew group. The coffee has too little The grinder is set to a too Adjust the grinder to a finer setting.
- Page 24 English Problem Cause Solution The frothed milk is too The cups are cold. Preheat the cups with hot water. cold. The milk does not froth. The milk carafe is dirty or not Clean the carafe and make sure that you inserted correctly.
- Page 25 English Problem Cause Solution The AquaClean filter icon You did not confirm activation Confirm the activation of the filter in the does not appear on the in the machine menu. machine menu. (see 'Activating the display after I replaced AquaClean filter') If the display shows the filter.
- Page 26 Milk circuit cleaner START DESCALING? 23 MIN...
