４－６．Setting HOLD SWITCHING TIME SELECT switch
DRIVE/ HOLD CURRENT automatic switching time is set up
with the DHT SEL switch.
(1) Set the DHT SEL [DH1/DH2] switch.
DRIVE/ HOLD Switching
DHT SEL
Time
ON
DH2(16ms)
OFF
DH1(150ms)
(Fuctory setting)
