Baileigh Industrial DC-2300B Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

OPERATOR'S
MANUAL
DUST COLLECTOR
MODEL: DC-2300B
Baileigh Industrial Holdings LLC,
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: 920.684.4990
Fax: 920.684.3944
sales@baileigh.com
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL
HOLDINGS LLC, IS PROHIBITED. Baileigh Industrial Holdings LLC, does not assume and hereby disclaims any
liability for any damage or loss caused by an omission or error in this Operator's Manual, resulting from accident,
negligence, or other occurrence.
Rev. 07/2019
© 2019 Baileigh Industrial Holdings LLC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC-2300B and is the answer not in the manual?

Questions and answers

Related Manuals for Baileigh Industrial DC-2300B

Summary of Contents for Baileigh Industrial DC-2300B

  • Page 1 REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL HOLDINGS LLC, IS PROHIBITED. Baileigh Industrial Holdings LLC, does not assume and hereby disclaims any liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurrence.

  • Page 2: Table Of Contents

    Table of Contents THANK YOU & WARRANTY ..................1 INTRODUCTION ......................3 GENERAL NOTES ......................3 SAFETY INSTRUCTIONS ....................4 SAFETY PRECAUTIONS ....................6 Dear Valued Customer: ....................6 TECHNICAL SUPPORT ....................8 TECHNICAL SPECIFICATIONS ..................9 UNPACKING AND CHECKING CONTENTS ..............10 Cleaning ........................

  • Page 3: Thank You & Warranty

    THANK YOU & WARRANTY Thank you for your purchase of a machine from Baileigh Industrial Holdings LLC. We hope that you find it productive and useful to you for a long time to come. Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or...
  • Page 4 We apologize for any discrepancies that may occur. Baileigh Industrial Holdings LLC reserves the right to make any and all changes deemed necessary in the course of business including but not limited to pricing, product specifications, quantities, and product availability.

  • Page 5: Introduction

    INTRODUCTION The quality and reliability of the components assembled on a Baileigh Industrial Holdings LLC machine guarantee near perfect functioning, free from problems, even under the most demanding working conditions. However, if a situation arises, refer to the manual first. If a solution cannot be found, contact the distributor where you purchased our product.

  • Page 6: Safety Instructions

    IMPORTANT PLEASE READ THIS OPERATORS MANUAL CAREFULLY It contains important safety information, instructions, and necessary operating procedures. The continual observance of these procedures will help increase your production and extend the life of the equipment. SAFETY INSTRUCTIONS LEARN TO RECOGNIZE SAFETY INFORMATION This is the safety alert symbol.
  • Page 7 SAVE THESE INSTRUCTIONS. Refer to them often and use them to instruct others. PROTECT EYES Wear safety glasses or suitable eye protection when working on or around machinery. PROTECT AGAINST NOISE Prolonged exposure to loud noise can cause impairment or loss of hearing.

  • Page 8: Safety Precautions

    Power Switch with Lock Out In the event of incorrect operation or dangerous conditions, the machine can be stopped immediately by pressing the Power Switch paddle downward. Remove the yellow lock key to prevent the machine from starting. Note: Resetting the Power Switch WILL start the machine. SAFETY PRECAUTIONS Wood working can be dangerous if safe and proper operating procedures are not followed.
  • Page 9 2. Only trained and qualified personnel can operate this machine. 3. Make sure guards are in place and in proper working order before operating machinery. 4. Remove any adjusting tools. Before operating the machine, make sure any adjusting tools have been removed. 5.

  • Page 10: Technical Support

    21. Keep all cords dry, free from grease and oil, and protected from sparks and hot metal. 22. Inspect power and control cables periodically. Replace if damaged or bare wires are exposed. Bare wiring can kill! 23. DO NOT bypass or defeat any safety interlock systems. 24.

  • Page 11: Technical Specifications

    G.W. 166lbs (75 KGS) Fan Curve Inlet Diameter of Tube (IN) 6" 5" 4" 3" 2" 1" 0" Static Pressure (mmH2O) 1426 1271 DC-2300B Curve Static Pressure (mmH2O) 1600 1426 1400 1271 1200 1000 6" 5" 4" 3" 2" 1"...

  • Page 12: Unpacking And Checking Contents

    UNPACKING AND CHECKING CONTENTS Your Baileigh machine is shipped complete. Separate all parts from the packing material and check each item carefully. Make certain all items are accounted for before discarding any packing material. WARNING: SUFFOCATION HAZARD! Immediately discard any plastic bags and packing materials to eliminate choking and suffocation hazards to children and animals.

  • Page 13: Installation

    INSTALLATION IMPORTANT: Consider the following when looking for a suitable location to place the machine: • Overall weight of the machine. • Weight of material being processed. • Sizes of material to be processed through the machine. • Space needed for auxiliary stands, work tables, or other machinery. •...

  • Page 14: Contents Of Package

    CONTENTS OF PACKAGE Item Description Qty. Part No. Item Description Qty. Part No. Left Housing NO. 25 Support Rod NO. 23 Right Housing NO. 28 Bag Clamp NO. 22 Main Housing NO. 12 Base NO. 3 Connector NO. 27 Filter Bags NO.

  • Page 15: Hardware Package

    HARDWARE PACKAGE Description Specification QTY. Part List No. Flange Bolt 5/16” x 1/2” NO. 2 Phillips Head Screw 3/16” x 3/8” NO. 6 Allen Wrench NO. 32 Open Wrench 10mm x 12mm NO. 33 ASSEMBLY INSTRUCTION 1. Secure the Wheels (No.1) under Base (No.3) with Flange Bolt 5/16”...
  • Page 16 2. Secure Main Housing (NO.12) on Base (No.3) with Flange Bolt 5/16” x 1/2” (No.2). (See FIG. 2) (FIG.2) 3. Place the Packing (No.26) on Main Housing (No.12). (See FIG. 3) (FIG.3)
  • Page 17 4. Place Connector (No.27) on Packing (No.26) and then secure it with Flange Bolt 5/16” x 1/2” (No.2). (See FIG. 4) (Fig.4) 5. Place Packing (No.26) between Left Housing (No.25) and Connector (No.27) to avoid air leaking, and then secure the connector to the left housing with Flange Bolt 5/16”...
  • Page 18 6. Place Packing (No.26) between Right Housing (No.28) and Connector (No.27) to avoid air leaking, and then secure the connector to the right housing with Flange Bolt 5/16” x 1/2” (No.2). (See FIG. 6) (FIG.6) 7. Insert the Bag Supports (No.24) onto the Left Housing (No.25) and Right Housing (No.28).
  • Page 19 8. Installed the Upper Filter Bag (No.29) and Lower Filter Bag (No.21) on the Left Housing (No.25) and Right Housing (No.28) with Bag Clamp (No.22). (See FIG. 8) (FIG.8)

  • Page 20: Electrical

    ELECTRICAL CAUTION: HAVE ELECTRICAL UTILITIES CONNECTED TO MACHINE BY A CERTIFIED ELECTRICIAN! Check if the available power supply is the same as listed on the machine nameplate. WARNING: Make sure the grounding wire (green) is properly connected to avoid electric shock. DO NOT switch the position of the green grounding wire if any electrical plug wires are switched during hookup.

  • Page 21: Power Cord Connection

    • Improper connection of the equipment-grounding conductor can result in risk of electric shock. The conductor with insulation having an outer surface that is green with or without yellow stripes is the equipment-grounding conductor. If repair or replacement of the electric cord or plug is necessary, do not connect the equipment-grounding conductor to a live terminal.

  • Page 22: Exploded Diagram

    EXPLODED DIAGRAM...

  • Page 23: Part List

    Part List Item Description Specification Qty. Wheel 2-1/2” Flange Bolt 5/16” x 1/2” Base Inlet Phillips Head Screw 3/16” x 3/8” Phillips Head Screw 3/16” x 3/8” Cover Cap Screw M6 x 20 Impeller Washer Impeller 12” Flange Bolt 3/8” x 1/2” Main Housing Washer 5/16”...
  • Page 24 BAILEIGH INDUSTRIAL HOLDINGS LLC 1625 D , WI 54220 UFEK RIVE ANITOWOC : 920. 684. 4990 F : 920. 684. 3944 HONE www.baileigh.com BAILEIGH INDUSTRIAL HOLDINGS LTD. U WIFT OINT WIFT ALLEY NDUSTRIAL STATE UGBY , CV21 1QH U IDLANDS...

This manual is also suitable for:

1002692
