OPERATOR'S
MANUAL
DUST COLLECTOR
MODEL: DC-600C
Baileigh Industrial Holdings LLC,
P.O. Box 531
Manitowoc, WI 54221-0531
Phone: 920.684.4990
Fax: 920.684.3944
sales@baileigh.com
REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL
HOLDINGS LLC, IS PROHIBITED. Baileigh Industrial Holdings LLC, does not assume and hereby disclaims any
liability for any damage or loss caused by an omission or error in this Operator's Manual, resulting from accident,
negligence, or other occurrence.
Rev. 07/2019
© 2019 Baileigh Industrial Holdings LLC
Advertisement
Table of Contents
Related Manuals for Baileigh Industrial DC-600C
Summary of Contents for Baileigh Industrial DC-600C
- Page 1 REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL HOLDINGS LLC, IS PROHIBITED. Baileigh Industrial Holdings LLC, does not assume and hereby disclaims any liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurrence.
-
Page 2: Table Of Contents
Table of Contents THANK YOU & WARRANTY ..................1 INTRODUCTION ......................3 GENERAL NOTES ......................3 SAFETY INSTRUCTIONS ....................4 SAFETY PRECAUTIONS ....................6 Dear Valued Customer: ....................6 TECHNICAL SUPPORT ....................8 TECHNICAL SPECIFICATIONS ..................9 UNPACKING AND CHECKING CONTENTS ..............10 Cleaning ........................ -
Page 3: Thank You & Warranty
THANK YOU & WARRANTY Thank you for your purchase of a machine from Baileigh Industrial Holdings LLC. We hope that you find it productive and useful to you for a long time to come. Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or... - Page 4 We apologize for any discrepancies that may occur. Baileigh Industrial Holdings LLC reserves the right to make any and all changes deemed necessary in the course of business including but not limited to pricing, product specifications, quantities, and product availability.
-
Page 5: Introduction
INTRODUCTION The quality and reliability of the components assembled on a Baileigh Industrial Holdings LLC machine guarantee near perfect functioning, free from problems, even under the most demanding working conditions. However, if a situation arises, refer to the manual first. If a solution cannot be found, contact the distributor where you purchased our product. -
Page 6: Safety Instructions
IMPORTANT PLEASE READ THIS OPERATORS MANUAL CAREFULLY It contains important safety information, instructions, and necessary operating procedures. The continual observance of these procedures will help increase your production and extend the life of the equipment. SAFETY INSTRUCTIONS LEARN TO RECOGNIZE SAFETY INFORMATION This is the safety alert symbol. - Page 7 SAVE THESE INSTRUCTIONS. Refer to them often and use them to instruct others. PROTECT EYES Wear safety glasses or suitable eye protection when working on or around machinery. PROTECT AGAINST NOISE Prolonged exposure to loud noise can cause impairment or loss of hearing.
-
Page 8: Safety Precautions
Power Switch with Lock Out In the event of incorrect operation or dangerous conditions, the machine can be stopped immediately by pressing the Power Switch paddle downward. Remove the yellow lock key to prevent the machine from starting. Note: Resetting the Power Switch WILL start the machine. SAFETY PRECAUTIONS Wood working can be dangerous if safe and proper operating procedures are not followed. - Page 9 2. Only trained and qualified personnel should operate this machine. 3. Make sure guards are in place and in proper working order before operating machinery. 4. Remove any adjusting tools. Before operating the machine, make sure any adjusting tools have been removed. 5.
-
Page 10: Technical Support
20. Inspect power and control cables periodically. Replace if damaged or bare wires are exposed. Bare wiring can kill! 21. Maintain machine in top condition. Keep clean for best and safest performance. Follow instructions for lubricating and changing accessories. 22. Reduce the risk of unintentional starting. Make sure switch is in “OFF” position before plugging in power cord. -
Page 11: Technical Specifications
137lbs (62 KGS) G.W. 153lbs (69.5 KGS) CU FT (m 15.4’ (0.43607944 m Fan Curve Inlet Diameter of Tube (IN) 6" 5" 4" 3" 2" 1" 0" Static Pressure (mmH2O) DC-600C Curve Static Pressure (mmH2O) 6" 5" 4" 3" 2" 1" 0"... -
Page 12: Unpacking And Checking Contents
UNPACKING AND CHECKING CONTENTS Your Baileigh machine is shipped complete. Separate all parts from the packing material and check each item carefully. Make certain all items are accounted for before discarding any packing material. WARNING: SUFFOCATION HAZARD! Immediately discard any plastic bags and packing materials to eliminate choking and suffocation hazards to children and animals. -
Page 13: Transporting And Lifting
TRANSPORTING AND LIFTING NOTICE: Lifting and carrying operations should be carried out by skilled workers, such as a truck operator, crane operator, etc. If a crane is used to lift the machine, attach the lifting chain carefully, making sure the machine is well balanced. Follow these guidelines when lifting with truck or trolley: •... -
Page 14: Contents Of Package
• LEVELING: The machine should be sited on a level, concrete floor. Provisions for securing it should be in position to prevent the machine from moving inadvertently. • POWER SUPPLY PLACEMENT: The power supply should be located close enough to the machine so that the power cord is not in an area where it would cause a tripping hazard. - Page 15 Description Qty. Part List NO. Main Housing NO.18v1 Cone NO.32 Base NO.28 Drum Lid NO.39 Quick Handle NO.33 Drum NO.46 Stand NO.25 Hose NO.38 Canister Filter NO.52v1 Hose Clamp NO.37 Inlet Adapter NO.20 Handle NO.65v1 Bag Clamp NO.50 Wheel NO.27 Cone Clamp NO.30 PE Bag for Canister Filter...
-
Page 16: Hardware Package
HARDWARE PACKAGE Description Specification Qty. Part List No. 5/16” NO.90 Flange Bolts Screw 5/16”x 1/2” NO.24 Phillips Head Screw M5x 8 NO.34 Open Wrench 10x12mm NO.48 Allen Wrench NO.47 Flange Bolts Screw 5/16”x 3/4” NO.8... -
Page 17: Assembly And Set Up
ASSEMBLY AND SET UP WARNING: For your own safety, DO NOT connect the machine to the power source until the machine is completely assembled and you read and understand the entire instruction manual. 1. Use the Open Wrench (NO.48) to secure the Base (NO.28) and Wheels (NO.27). - Page 18 3. Tighten the Wheels (NO.27) under the drum (NO.46) into the thread nuts. See FIG. 2 Fig. 2 4. Using an assistant, Lift up the Main Housing (NO.18v1), then place on the Stand (NO.25). Using the Flange Bolt Screw 5/16” x 1/2” (NO.24) to tighten together.
- Page 19 5. Place and secure the Main Housing (NO.18v1) and Cone (NO.32) with Cone Clamp (NO.30) and Hex Screw (NO.31). See FIG. 4. Fig. 4 6. Assemble Handle (NO.65v1) inside the Canister Filter (NO.52v1) and tighten with Set Screw 5/16”x3/4” (NO.64) and Nut 5/16” (NO.63). See FIG.
- Page 20 7. Assemble the Canister filter (NO. 52v1) on the Main Housing (NO.18v1) and tighten with Flange Bolt Screw 5/16”x3/4” (NO.8) and Nut 5/16” (NO.90). See FIG. 6 Fig. 6 8. Assemble Inlet Adaptor (NO.20) on Main Housing (NO.18v1) and tighten with Phillips Head Screw 3/18”*3/8”...
- Page 21 10. Assemble and tighten Hose (NO.38) on Cone (NO.32) and Drum lid (NO.39) with Hose clamp (NO.37). See FIG. 8 Fig. 8 11. Put the PE Bag (NO. 85) into the Drum (NO. 46) first, then placed the inner frame inside the PE bag in order to press the bag down.
- Page 22 13. All the assembly steps are completed. See (FIG. 10) Fig. 10...
-
Page 23: Electrical
ELECTRICAL CAUTION: HAVE ELECTRICAL UTILITIES CONNECTED TO MACHINE BY A CERTIFIED ELECTRICIAN! Check if the available power supply is the same as listed on the machine nameplate. WARNING: Make sure the grounding wire (green) is properly connected to avoid electric shock. DO NOT switch the position of the green grounding wire if any electrical plug wires are switched during hookup. -
Page 24: Power Cord Connection
• Improper connection of the equipment-grounding conductor can result in risk of electric shock. The conductor with insulation having an outer surface that is green with or without yellow stripes is the equipment-grounding conductor. If repair or replacement of the electric cord or plug is necessary, do not connect the equipment-grounding conductor to a live terminal. -
Page 25: Exploded Diagram
EXPLODED DIAGRAM... -
Page 26: Part List
Part List Description Specification Qty. Motor 1-1/2HP Bushing 5/16” Spring Washer 5/16 6x6x25 Motor Packing Flange Bolt Screw 5/16”x3/4” Hanger 5/16” Motor Plate Switch Power Cord Hex. Bolt 5/16”x1” Impeller 13” Set Screw 5/16”x5/16”” Impeller Washer Cap Screw M6x20 18v1 Main Housing Philips Head Screw 3/16”x3/8”... - Page 27 Description Specification Qty. Hose Clamp 10-1/2” Hose 10” Drum Lid Long Nut 3/8” Drum Handle Flat Head Screw 1/4”x1/2” Packing Acrylic Board Rivet Φ420 Drum Allen Wrench Open Wrench 10x12mm Φ370x450 PE Bag Φ370 Bag Clamp Foam 52v1 Canister Filter 370x450 53v1 Flange Bolts...
