SERVICE PARTS
76667T-E
1219396**
1208178
23096
1061576
1081607
1208177**
1208178
1061576
23096
**Color code must be specified when ordering.
1269273-AN2-A
AWAKEN
Slide Shower
1208176**
1195838**
1226887**
79680
1248781**
1194751**
1269272**
1128483
Installation INSTRUCTIONS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Observe local plumbing codes.
2. An inline water filter must be used with this product.
3. The highest working pressure for handshower is 0.5MPa(5 bar). If it exceeds 0.5MPa(5 bar), a pressure reducer
is needed. The highest water and environment temperature is 60°C. Please keep handshower, showerhead and
the shower arm away from heater, or it may become damaged and cause injury to the user.
4. All installations should comply with the relevant requirements of AS/NZS 3500 and AS/NZS 6400.
ROUGH-IN DIMENSIONS
4
1269273-AN2-A
76667T-E
Slide Shower
75
60
G1/2˝
Ø116
G1/2˝
G1/2˝
51
AWAKEN
59
44
G1/2˝
1
