GA-X99-Ultra Gaming
User's Manual
Rev. 1101
12ME-X99ULTG-1101R
For more product details, please visit GIGABYTE's website.
To reduce the impacts on global warming, the packaging materials of this product are
recyclable and reusable. GIGABYTE works with you to protect the environment.
