Chapter 1 Introduction

1.1

Product Overview

Designed for workgroups and departments, TP-Link JetStream L2/L2+ Managed Switch provides
wire-speed performance and abundant L2 management features. It provides a variety of service
features and multiple powerful functions with high security.
The EIA-standardized framework and smart configuration capacity can provide flexible solutions
for a variable scale of networks. ACL, 802.1x and Dynamic ARP Inspection provide robust security
strategies. QoS and IGMP snooping/filtering optimize voice and video application. Link aggregation
(LACP) increases aggregated bandwidth, optimizing the transport of business critical data. SNMP,
RMON, WEB and CLI Log-in bring abundant management policies. TP-Link JetStream L2/L2+
Managed Switch integrates multiple functions with excellent performance, and is friendly to manage,
which can fully meet the need of the users demanding higher networking performance.
TL-SG3210XHP-M2/TL-SG3428MP V2.0/TL-SG3428XMP/TL-SG3452P is also a Power Sourcing
Equipment (PSE*). All the RJ45 ports on the switch support Power over Ethernet (PoE*) function,
which can automatically detect and supply power to those powered devices (PDs*) complying with
IEEE 802.3af and IEEE 802.3at.
*PSE: a device (switch or hub for instance) that provides power through an Ethernet cable.
*PoE: This technology describes a system to transmit electrical power, along with data, to remote
devices over standard twisted-pair cable in an Ethernet.
*PD: a device powered by a PSE and thus consumes energy. Examples include powering network
cameras, wireless LAN access points, IP telephones, network hubs, embedded computers etc.
1.2

Appearance

Front Panel
■
The front panel of TL-SX3008F
Figure 1-1 Front Panel of TL-SX3008F
The front panel of TL-SG3210
Figure 1-2 Front Panel of TL-SG3210
PWR 1
TL-SG3210
SYS 2
L2+ Managed Switch
LED
is shown as the following figure.
LED Console Port
is shown as the following figure.
1000Mbps 1000Mbps
10/100/1000M 10/100Mbps SFP 100Mbps
Activity Activity
3 5 7 9
4 6 8 10
10/100/1000M SFP
Console Port
1G RJ45 Port
(RJ45/USB)
JetStream L2/L2+ Managed Switch
SFP+ Slot
(RJ45/USB)
SFP Slot
