MSE Audio PHASE TECH CIX IN-WALL Owner's Manual

MICRO-FLANGE GRILLE
Thank you for purchasing Phase Technology
speakers. This tenth generation of high performance ceiling mounted
speakers features the same superb sonic performance as our acclaimed PC
Series cabinet speakers in addition to great flexibility and easy installation.
The most striking change to the Series X is a new look with the off-axis
tweeter design. This feature maximizes the speaker's clarity and imaging
by creating an asymmetrical loading or diffraction pattern, reducing the
amount of diffraction normally caused by a flange-to-ceiling junction. The
net result is the best sonic realism you can buy in an in-ceiling speaker.
All CI Series speakers include self-resetting solid-state PTC protection
circuits. This unique system is able to detect when the speaker is being
over-driven and lowers the speaker volume until the problem is corrected.
The PTC device then resets itself for normal operation. Other features
include our new low profile Micro-Flange grille with magnetic retainers,
liquid-cooled tweeters for greater power handling, moisture-resistant
materials in all of the critical speaker components, galvanized steel speaker
grilles and corrosion resistance hardware.
Regardless of application, serious audiophile listening or home theater, we
recommend that you take the time to read this manual thoroughly before
CIX IN-WALL
OWNER'S MANUAL: CI20X • CI70X • CI-SURRX
CI custom installation
®
connecting speakers to your amplifier or receiver. In the highly unlikely
event that you should experience a problem with set-up or operation,
please contact one of our authorized dealers for assistance, or contact us
directly.
Phase Technology Corporation
8005 W. 110th St., Suite 208
Overland Park, KS 66210
855.663.5600 (Domestic)
+1.913.663.5600 (International)
913.663.3200 (Fax)
SAFETY INSTRUCTIONS
SPEAKER INSTALLATION
CARING FOR YOUR SPEAKER
MAINTENANCE AND SERVICE
WARRANTY
SPECIFICATIONS
SPEAKER
CLAMP (4x)
TWEETER
ADJUSTMENT
SPEAKER/ BAFFLE
ASSEMBLY
MAGNETS FOR
SECURING GRILLE (10x)
SPEAKER CLAMP
SCREWS (4x)
2
3
4
4
4
4
