CAUTION: BE VERY CAREFUL NOT TO DAMAGE THE MIDRANGE DOMES OR SFE [SPATIAL FIELD EXPANDERS
ON THE SIDE OF THE CABINET WHILE HANDLING THE SOUNDBAR.
[INCLUDED IN THE BOX]
1. TEATRO
6. Table Top Mounting Feet Screws x4
TEATRO
OWNER'S MANUAL: TSB3.0
TSB3.0
®
2. Mounting Bracket x2
3. Mounting Pin x2
4. Leveling Screw x2
5. Table Top Mounting Feet x2
7. Table Top Mounting Screws x2
8. Euroblock Connectors x3
®
EVT
OFFO
N
Thank you for purchasing the Phase Technology TEATRO
This high-definition LCR soundbar incorporates PhaseTech's exclusive
Enhanced Voice Technology (EVT
(SFE
) to provide outstanding dialogue clarity along with an open, wide sound
™
stage.
The TEATRO
TSB-3.0 soundbar speaker is a an ultra thin design made to
®
fit seamlessly under a flat panel TV. Both table top and wall mounting options
are included with the product. For on-wall applications, the mounting bracket
has adjustments for lining up and vertically leveling the speaker with the TV.
The soundbar cabinet also has threaded inserts for mounting the TSB3.0 to a
display wall bracket mechanism.
Note: please check with the display mount manufacturer for compatibility and
ensure the display mount will support a 12 pound soundbar.
Regardless of application, serious audiophile listening or home theater, we
recommend that you take the time to read this manual thoroughly before
connecting speakers to your amplifier or receiver. In the highly unlikely event
that you should experience a problem with set-up or operation, please contact
one of our authorized dealers for assistance, or contact us directly.
Phase Technology Corporation
8005 W. 110th St., Suite 208
Overland Park, KS 66210
855.663.5600 (Domestic)
+1.913.663.5600 (International)
Fax: 913.663.3200
SAFETY INSTRUCTIONS
MOUNTING INSTRUCTIONS
WALL MOUNTING
TABLE TOP MOUNTING
CARING FOR YOUR SPEAKERS
MAINTENANCE AND SERVICE
TROUBLESHOOTING
WARRANTY
SPECIFICATIONS
] DRIVERS LOCATED
™
TSB3.0 soundbar.
®
™
) circuitry and Spatial Field Expanders
2
3
3
4
5
5
5
5
5
Advertisement
Related Manuals for MSE Audio Phase Tech Teatro TSB 3.0
Summary of Contents for MSE Audio Phase Tech Teatro TSB 3.0
- Page 1 TEATRO ® OWNER’S MANUAL: TSB3.0 OFFO CAUTION: BE VERY CAREFUL NOT TO DAMAGE THE MIDRANGE DOMES OR SFE [SPATIAL FIELD EXPANDERS ] DRIVERS LOCATED ™ ON THE SIDE OF THE CABINET WHILE HANDLING THE SOUNDBAR. Thank you for purchasing the Phase Technology TEATRO TSB3.0 soundbar.
- Page 2 Copyright © 2016 MS Electronics, LLC. All rights reserved. MSE Audio, Phase Technology and PhaseTech are registered trademarks and “Speakers for your Life” is a trademark of MSE Audio, Overland Park, Kansas USA. Phase Technology is part of MSE Audio ®...
-
Page 3: Step 2.1 - Wall Mounting
[MOUNTING INSTRUCTIONS] sure this mark is also 2.5” below the TV. Repeat this process on the right When selecting the speaker mounting location, it is prudent to take a few side of the display – making sure that this mark is level with the mark on extra minutes to carefully inspect and measure the wall where you intend to the left side. -
Page 4: Step 2.2 - Table Top Mounting
See step 3 for more detailed information on wiring the TSB3.0. Gently [FIGURE 5] slide the Mounting Pins into the vertical mounting slots on the Mounting Brackets. Removal of the flat panel display may be necessary before mounting the TSB3.0. The Leveling Screws may be inserted in the bottom of the Mounting Bracket and used to adjust the height and to make sure the TSB3.0 speaker is level. - Page 5 This warranty will be void if the products’ serial number has been altered or removed. Should your Phase Technology product require service, please call the MSE Audio customer service department for a return authorization. All merchandise ®...
