- Page 1 USER GUIDE 10507 - Version 1.0 / 08-2016...
-
Page 2: Safety Information
English PREZONE444 -Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs 1 - Safety information Important safety information This unit is intended for indoor use only. Do not use it in a wet, This product contains non-isolated electrical components. Do not or extremely cold/hot locations. - Page 3 PREZONE444 - Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs English Instructions and recommendations 12 - Cleaning precautions : 1 - Please read carefully : Unplug the product before attempting any cleaning We strongly recommend to read carefully and understand operation.
-
Page 4: Main Specifications
PREZONE444 -Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs 2 - Introduction The PREZONE444 was clearly thought-out for professionals, and offers 4 micros/line mono inputs via XLR or Jack and 4 stereo inputs via RCA or Jack. Each input can be sent independently to each zone, or to both zones simultaneously in order to offer maximum possibilities. -
Page 5: Front Panel
PREZONE444 - Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs English 4 - Presentation Front panel 10 11 Input equalization Output equalization Each channel features a 3-way signal equalization. - HIGH (High Frequency control): Allows you to adjust These knobs allow you to increase or decrease basses the output signal trebles from -15 to +15 dB at 12kHz. - Page 6 English PREZONE444 -Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs POWER LED Indicates your device is ON or OFF. POWER button Allows you to activate or deactivate your device. MONITOR knob Allows you to adjust monitoring levels. LEVEL knob Allow you to adjust sound levels of OUTPUT1, OUTPUT2, OUTPUT3 and OUTPUT4.
- Page 7 PREZONE444 - Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs English REAR PANEL Power input PHANTOM switches Connect here the supplied IEC power cord, then Allows you to add a +15V DC phantom power supply connect the other end to an electrical outlet after having to microphone channels 2 to 4 in order to connect electrostatic microphones.
-
Page 8: Schéma De Principe
English PREZONE444 -Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs 5 - Schéma de principe Microphone CD player WP-1 to power up and control 4 WP-1 to control zone 2 MIC-DESK4 for announcements via all zones AMP4120 Multi-channel amplifier... -
Page 9: Microphone Inputs
PREZONE444 - Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs English 6 - Connectors 6.1 - Microphone inputs The microphone inputs are accessible via XLR chassis and can receive both balanced and unbalanced low-level signals Both low-impedance condenser and dynamic microphones can be connected (channels 1 to 4). - Page 10 English PREZONE444 -Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs 7 - Synoptic Page 10...
-
Page 11: Technical Specifications
PREZONE444 - Multizone and rackable Mixer/Pre-amplifier with 8 inputs and 4 outputs English 8 - Technical specifications Power output and impedance Balanced OUTPUT 1 to 4 0 dB / 600 Ohms Microphone channels - 60 dB ~ -16 dB / 20 KOhms... - Page 12 That is why technical specifications and the products physical configuration might differ from the illustrations. ® Make sure you get the latest news and updates about the AUDIOPHONY products on www.audiophony.com AUDIOPHONY ®...
