Fortinet FortiAP U421EV Quick Start Manual page 17

Manual IP
Configuration
& Controller
Discovery
To enable the FortiAP with a static IP address:
1. Connect the FortiAP device to a seperate private switch or hub.
2. Access the AP console through the serial port.
3. To configure FortiAP's own IP address, type ip config net static
address <ip-address> netmask <netmask ip-address> gateway
<gateway ip-address>.
4. [FortiWLC only] To discover the controller, type ip config l2l3
<l2only | l2preferred | l3only | l3preferred>.
5. To configure a designated wireless controller's IP address, type ip
config controller name <controller ip-address>.
6. Save the configuration by typing ip config save.
7. Unplug the FortiAP unit and plug it back in order for the
configuration to take effect.
8. Move the FortiAP to the intended deployment location and
connect the Ethernet cable.
16
