- Page 1 Product Manual 232-ATSC HDTV Tuner January 19, 2009 S12 Control Version 1.8 HD Processor Version 0.68 17630 Davenport Road, Suite 113 • Dallas, TX 75252 Phone: 972-931-2728 • Toll-Free: 888-972-2728 • Fax: 972-931-2765 E-Mail: Sales@crwww.com • Website: www.crwww.com...
-
Page 2: Table Of Contents
Terminal Communication Commands ... 18 HD2-RC Remote Emulation ... 19 Response Strings ... 20 Response Strings ... 20 RS-232 Cable Connections... 21 Rack Mounting ... 22 Safety Instructions ... 23 Limited Warranty ... 24 Contemporary Research 232-ATSC Digital HDTV Tuner... -
Page 3: Overview
Overview The 232-ATSC HDTV Tuner is an integrator-friendly universal HDTV tuner, controllable via two-way RS-232 and discrete IR commands. Able to fit two-across in a 2RU rack space, the compact tuner outputs HDMI, RGB/Component, and composite video simultaneously. NTSC broadcasts are upscaled for HD display. Digital audio is available from HDMI, coax, and optical connections, as well as variable-level stereo audio. -
Page 4: Specifications
Sleeve= DC power+ from power jack input, limited to less than 100mA Ring=DC power– (GND) Tip= IR data signal Power In: 2.1mm coaxial jack (inside center conductor positive) 1.3 A maximum, 11.5 to 15 VDC, 12 VDC typical Contemporary Research 232-ATSC Digital HDTV Tuner... -
Page 5: Tuning
SVGA is a trademark of the Video Electronics Standard Association • HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. Manufactured under license from Dolby Laboratories, Dolby and the double-D symbol are trademarks of Laboratories Contemporary Research 232-ATSC Digital HDTV Tuner... -
Page 6: Quick Setup Guide
Fine Tune and Noise Reduction available for analog channels Set DST and Time Zone AC-3 (Dolby 5.1) or PCM 4:3 or 16:9 Press both Channel buttons Press both Volume buttons Include menu functions in touch panels for installer/user setup options. 232-ATSC Digital HDTV Tuner... -
Page 7: Troubleshooting
Line 21 (analog) Captioning on Video Output Symptom: Video out does not include captioning The 232-ATSC does not pass on closed captioning codes when tuned to an analog channel. However, all captioning from digital TV channels is converted to analog captioning on the video output. -
Page 8: Front Panel Setup
To Enter a Front Panel Programming Mode: 1. Press and hold the Power button, then press the Volume Up button. 2. Release all buttons, the 232-ATSC will now be in the front-panel programming mode. The Air LED will flash, indicating programming mode. -
Page 9: Hd2-Rc Ir Remote
HD2-RC IR Remote The HD2-RC IR Remote included with the 232-ATSC can be used to setup the tuner and for daily operation. All of the functions on the remote have equivalent commands in RS-232, Ethernet, and Wired IR formats. In... -
Page 10: On-Screen Menus
Tip: Normally, use Auto. Most cable channels will be in standard frequencies. If all the channels tune in STD but channels 5 and 6, scan for IRC. If few channels can be found, scan for HRC. 232-ATSC Digital HDTV Tuner... - Page 11 This page also displays from the Signal remote command. The graphic shows the current signal strength, and changes in real time. This allows you to monitor the strength of a channel as you adjust the antenna for best reception. 232-ATSC Digital HDTV Tuner...
-
Page 12: Caption Menus
Edge – 6 style options Version displays current version of tuner firmware Manages access to programming for US and Canadian standards. The default PIN number for access is 0000 (four zeros. Enter and confirm new PIN for access. 232-ATSC Digital HDTV Tuner... -
Page 13: Setup Menus
You can use RATIO on the remote – does the same setting. • Time • Sound Settings • Video Noise Reduction - On/Off (if tuned to analog) Set to On – helps to clean up analog channels • Menu Language – English, Spanish, French 232-ATSC Digital HDTV Tuner... - Page 14 • Digital Out – AC-3 (Dolby 5.1), PCM, or variable-level PCM. Set to PCM when using audio through the HDMI connection – most displays cannot decode AC-3 (Dolby 5.1). • Auto Volume – On or off 232-ATSC Digital HDTV Tuner...
-
Page 15: Pop-Up Menus
Time – current time and date • Program – Times and name (if digital) • Details – Resolution, Audio Mode, Captions, Rating Shows the day’s programming guide for current station. Use Up or Down arrows to move through Guide. 232-ATSC Digital HDTV Tuner... -
Page 16: Rs-232 Control Protocol
Each of the groups has one ASCII status response string containing all of the status data for that group. The current status string of a group is sent from the 232-ATSC whenever a valid command for that group is received by the 232-ATSC RS-232 port or front panel. A group's status may be requested at any time via the RS-232 port. -
Page 17: Control Commands
Example: ‘>XD=0,0’ removes current channel XA=<major>,<minor>,<physical> adds channel Example: ‘>XA=38,1,0’ Physical channel will be same as major Sets tuner for antenna (Off-Air) tuning Sets tuner for cable tuning Steps through favorite channels (selected in List menu) 232-ATSC Digital HDTV Tuner... -
Page 18: Terminal Communication Commands
Characters received will not be re-transmitted (power up default). Characters received will be re-transmitted. Example: ‘>EN’ Characters received will be re-transmitted. Returns the product model number and firmware version. Reconfigures unit for all factory default settings. 232-ATSC Digital HDTV Tuner... -
Page 19: Hd2-Rc Remote Emulation
149=Output RGB 151=Output YPbPr 153=Air 154=Cable 155=16:9 Ratio Pillar Box 4:3 Ratio Letterbox 156=16:9 Ratio Full Wide 4:3 Ratio Full 156=16:9 Ratio V Zoom 4:3 Ration H Zoom 158=AC-3(Dolby 5.1) 159=PCM 160=PCM Variable 161=Display 16:9 162=Display 4:3 232-ATSC Digital HDTV Tuner... -
Page 20: Response Strings
232-ATSC status response strings contain ASCII characters similar to those used for the same functions in command strings. An ASCII 'carriage return' and ‘line feed' follow each response string. Functions shown as N/A are not applicable or available in the 232-ATSC; characters will appear in status strings as lower-case x. Channel/Source Status Response String (T):... -
Page 21: Rs-232 Cable Connections
GND 5 Unit 3 TXD 3 9-pin D-sub RXD 2 female GND 5 Unit 2 TXD 3 9-pin D-sub female RXD 2 GND 5 Unit 1 TXD 3 9-pin D-sub RXD 2 female 9-pin D-sub female 232-ATSC Digital HDTV Tuner... -
Page 22: Rack Mounting
Rack Mounting Two options are available for rack-mounting tuners. RK1-HD • Insert 232-ATSC into RK1-HD frame. • Use screws included with kit to attach tuner to the side flanges. RK2-HD • Use supplied screws to attach left tuner to left and top flanges •... -
Page 23: Safety Instructions
Article 820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I), that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building as close to the point of cable entry as possible. Contemporary Research 232-ATSC Digital HDTV Tuner... -
Page 24: Limited Warranty
Limited Warranty Contemporary Research Corporation (CR) warrants this product to be free from defects in material and workmanship under normal use for a period of two years from the date of purchase from CR. Should such a defect occur CR will repair or replace, at their option, the defective product at no cost for parts or labor.
