Minimize installation
time and problems by
being prepared!
GETTING READY
Have the right tools and
information before you begin:
1.Install Tuner Helper
software, available on the CR
Catalog CD or download from
crwww.com. You can also use
front-panel and RS-232
commands, but this is much
easier and faster.
2.Connect your computer to
the tuner with a null modem RS-
232 cable. Available anywhere or
build with two female DB-9
connectors, wire ground to pin 5,
reverse wires to pins 2 and 3 on
one end.
3.Determine the client's active
system channels, channel
names, and TV format
(Broadcast, CATV, IRC, or HRC).
4.Power tuner using the
included power supply.
Most tuner problems are
caused by selecting the
incorrect TV format and
using insufficient DC power.
17630 Davenport, Suite 113
Dallas, Texas 75252-5963
Phone 972-931-2728
www.crwww.com
support@crwww.com
QUICK START GUIDE
RS-232 Tuner Setup
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Contemporary Research 232-MTA
Summary of Contents for Contemporary Research 232-MTA
-
Page 1: Quick Start Guide
Minimize installation time and problems by being prepared! GETTING READY Have the right tools and information before you begin: 1.Install Tuner Helper software, available on the CR Catalog CD or download from crwww.com. You can also use front-panel and RS-232 commands, but this is much easier and faster. - Page 2 Basic Installation It’s best to set up the tuner at the job site, so you can test operation on the client’s cable system. HOOK UP TUNER 1.Connect DC power supply, at least 400 mA, do not power more than one tuner from the same supply.
