- Page 1 ALFATRON ELECTRONICS GmbH GERMANY ALF-TP405PT Scaler Switcher...
- Page 2 Alfatron ALF-TP405PT Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage.
- Page 3 Alfatron ALF-TP405PT SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
-
Page 4: Table Of Contents
Alfatron ALF-TP405PT Contents 1. Introduction ......................... 1 1.1 Introduction to TPHD405PT-WPB ..............1 1.2 Features ......................1 1.3 Package List ...................... 1 2. Panel Description ......................2 2.1 Front Panel ......................2 2.2 Side Panel ......................3 2.3 Rear Panel ......................4 3. -
Page 5: Introduction
Alfatron ALF-TP405PT 1. Introduction 1.1 Introduction to TPHD405PT-WPB TPHD405PT-WPB is a Decora style transmitter that installs in a double-gang wall box to provide a convenient interface for HDMI / VGA input sources. It has 1 HDMI IN, 1 VGA IN and 1 HDBaseT OUT with PoC. It supports VGA with full HD scaler, and HDMI 1.4 with 4k&... -
Page 6: Panel Description
Alfatron ALF-TP405PT Notes： Please confirm if the product and the accessories are all included, if not, please contact with the dealers. 2. Panel Description 2.1 Front Panel Name Description Power Illuminates red when power on ① indicator Used as video source selection button (with backlight off): Press to select one source, press again to select next source, switching circularly between HDMI and VGA. -
Page 7: Side Panel
Alfatron ALF-TP405PT The indicator: illuminate yellow when there is VGA signal input illuminate green when the signal source is chosen as input source turn off when there is no VGA input signal Connect with the audio output socket of VGA source device,... -
Page 8: Rear Panel
Alfatron ALF-TP405PT 2.3 Rear Panel Name Description Power in port, 2-pin pluggable terminal block, connect with Power In ① DC 12V power adapter. Power out port, connect with Programmable Control Panel to Power Out ② energize it with a 12V power output. -
Page 9: System Connection
Alfatron ALF-TP405PT 3. System Connection 3.1 Usage Precautions System should be installed in a clean environment and has a prop temperature and humidity. All of the power switches, plugs, sockets and power cords should be insulated and safe. All devices should be connected before power on. -
Page 10: Energizing Programmable Control Panel
Alfatron ALF-TP405PT Step4. Connect a control terminal to the RS232 port on the front panel of HDBaseT Receiver. Step5. Connect control device (e.g. PC) to RS232 port of TPHD405PT-WPB or HDBaseT Receiver (bi-directional RS232 control, either is available). Step6. Connect DC 24V power adaptor to the power port of HDBaseT Receiver, TPHD405PT-WPB is able to get power from HDBaseT Receiver with PoC solution. -
Page 11: Application
Alfatron ALF-TP405PT DC 24V 3.6 Application TPHD405PT-WPB has a good application in various occasions, such as computer realm, monitoring, conference room, big screen displaying, television education, command & control center and smart home etc. -
Page 12: Operations
Alfatron ALF-TP405PT 4. Operations 4.1 Operations of front panel buttons TPHD405PT-WPB has a channel switching button on the front panel, through which users can switch input source signals. It supports both manual switching and auto switching. (Default: Auto switching) Press and hold the switching button for 3 seconds or send command “50770% “... -
Page 13: Rs232 Communication Commands
Alfatron ALF-TP405PT The interface of the control software is showed as below: Parameter Configuration area Monitoring area, indicates if the command sent works. Command Sending area Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit correctly, and then you are able to send command in Command Sending Area. - Page 14 Alfatron ALF-TP405PT Change the vertical polarity to the 50706% Vpolarity:0/1 opposite 1920x1080 Check the present resolution and 50707% Hpolarity:1 polarity Vpolarity:0 50770% Enable auto-switching Auto Switching 50771% Disable auto-switching Manual Switching Resolution Commands Change the resolution to 1360X768 50619% Resolution: 1360x768...
- Page 15 Alfatron ALF-TP405PT 50606% Auto-adjust the input parameter VGA Input Auto Color Temperature: xx (xx 50607% Adjust the color temperature can be medium, warm, user, or cool) Aspect Ratio: xx (xx can be 50608% Set the aspect ratio 16:9, 4:3, or auto.)
- Page 16 Alfatron ALF-TP405PT 50637% Check the contrast Contrast: xx 50638% Check the saturation Saturation: xx 50639% Check sharpness Sharpness: xx 50640% Check the color temperature Color Temperature: xx Adjustment Commands 50678% Enable screen output adjusting Enter Output Position Adjust 50679% Disable screen output adjusting...
- Page 17 Alfatron ALF-TP405PT Program EDID file, send EDID data Waiting for edid within 10 50799% within 10s secs! Note: Commands with grey background are for VGA sources only. EDID commands are for HDMI sources only.
-
Page 18: Specification
Alfatron ALF-TP405PT 5. Specification Video Input 1 HDMI, 1 VGA Output 1 HDBaseT Input 1 19-pin Type A HDMI Output 1 RJ45 Connector female; 1 15-pin VGA Connector Transmission HDBaseT Mode Audio Input 1 synchronous VGA audio Input 1 3.5mm stereo jack... -
Page 19: Panel Drawing
Alfatron ALF-TP405PT 6. Panel Drawing 88.72 mm LINK HDCP POWER RESET VGA IN SOURCE/AUTO AUDIO IN HDMI RS232 RS232 HDMI IN FIRMWARE 46.00 mm... -
Page 20: Troubleshooting & Maintenance
Alfatron ALF-TP405PT 7. Troubleshooting & Maintenance Problems Causes Solutions Color losing or no video signal output in HDMI display connecting cables No HDMI signal output in Check whether the cables may not be connected the device while local are connected correctly... -
Page 21: After-Sales Service
Alfatron ALF-TP405PT 8. After-sales Service If there appear some problems when running TPHD405PT-WPB, please check and deal with the problems reference to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: We warrant that our products will be free from defects in materials and workmanship for three years, which starts from the first day you buy this product (The purchase invoice shall prevail). - Page 22 Alfatron ALF-TP405PT 1. Limited warranty in respect of Alfatron Products Only 1.1 This limited warranty covers defects in materials and workmanship in this product. 1.2 Should warranty service be required, proof of purchase must be presented to the Company. The serial number on the product must be clearly visible and not have been tampered with in any way whatsoever.
- Page 23 Alfatron ALF-TP405PT warranty: 1.10.1 Elect to repair or facilitate the repair of any defective parts within a reasonable period of time, free of any charge for the necessary parts and labor to complete the repair and restore this product to its proper operating condition.; or 1.10.2 Replace this product with a direct replacement or with a similar product deemed...
