Page 2: Fcc Statement
HDBaseT Extender Preface Read this user manual carefully before using this product. Pictures shown in this manual are for reference only; different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. Trademarks Product model and logo are trademarks. -
Page 3: Safety Precautions
HDBaseT Extender SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ... -
Page 4: Table Of Contents
HDBaseT Extender Table of Contents 1. Introduction ......................... 1 1.1 Introduction to HDBaseT Extender ..............1 1.2 Features ......................1 1.3 Package Contents ..................... 1 2. Panel Description ......................2 2.1 Transmitter ......................2 2.2 Receiver ......................3 3. System Connection ..................... 5 3.1 Usage Precautions .................... -
Page 5: Introduction
HDBaseT Extender 1. Introduction 1.1 Introduction to HDBaseT Extender HDBaseT Extender is a mini-size extender set consisting of transmitter and receiver. HDBaseT technology is used to transmit high-resolution 1080p/ 4k signal from transmitter to the receiver via a CAT5e/CAT6a cable at a distance of up to 70/40m. Moreover, HDBaseT Extender support CEC, bi-directional RS232&IR control, and unidirectional PoH function. -
Page 6: Panel Description
HDBaseT Extender 2. Panel Description 2.1 Transmitter LINK HDCP RS232 Name Description HDBT Link status indicator: OFF: No Link ① LINK GREEN:Link Successful Blinking GREEN: Link abnormal HDCP compliant indicator OFF: No HDMI traffic (no picture) ②... -
Page 7: Receiver
HDBaseT Extender ⑨ DC 24V Connect with power supply Pictures shown in this manual are only for reference. 2.2 Receiver LINK HDCP RS232 Name Description HDBT Link status indicator: OFF: No Link ① LINK GREEN:Link Successful Blinking GREEN: Link abnormal HDCP compliant indicator ... - Page 8 HDBaseT Extender Connect to the HDBT OUT socket on the transmitter via CAT5e/ ⑧ HDBT IN CAT6a cable. Connect with power supply (Not necessary if transmitter connects ⑨ DC 24V with power). Pictures shown in this manual are only for reference.
-
Page 9: System Connection
HDBaseT Extender 3. System Connection 3.1 Usage Precautions 1) System should be installed in a clean environment and have controlled temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated 3) All devices should be connected before power on. 4) Use shielded straight-thru CAT5e/CAT6a cable with TIA/EIA T568B terminations for good transmission. -
Page 10: Application
HDBaseT Extender Step5. Connect the RS232 port of the devices to be controlled and the receiver or the transmitter. Step6. Connect with DC24V power adaptor(s) (One is enough if transmitter is connected with adapter as its PoH function). 3.4 Application HDBaseT Extender has a good application in various situations, such as computer realm, monitoring, big screen displaying, meeting room, education and bank &... -
Page 11: Specification
HDBaseT Extender 4. Specification Model Transmitter Receiver Spec Input Input Signal 1 HDMI,1 IR & 1 RS232 1 IR, 1 RJ-45 & 1 RS232 HDMI female, 3.5mm mini 3.5mm mini jack, RJ-45, 3p Input Connector jack, 3p captive screw captive screw connector connector Digital audio, transmit Digital audio, transmit... -
Page 12: Supported Resolution
HDBaseT Extender 4.1 Supported Resolution Aspect Ratio Resolution Refresh Rate 4096x2160 30Hz 4Kx 2K 3840x2160 24/25/30Hz 1920x1080 60Hz 1600x900 60Hz 16:9 1366x768 60Hz 1280x720 60Hz 1024x576 60Hz 1920x1200 60Hz 1680x1050 60Hz 16:10 1360x768 60Hz 1280x800 60Hz 1600x1200 60/65/70/75/85Hz 1280x1024 60/75/85/96Hz 1024x768 60/70/75/85Hz 800x600... -
Page 13: Panel Drawing
HDBaseT Extender 5. Panel Drawing 5-1 Transmitter 5-2 Receiver... -
Page 14: Troubleshooting & Maintenance
HDBaseT Extender 6. Troubleshooting & Maintenance No image on display: Ensure that the display device has been set to the correct input. Ensure that the HDMI cables used for both the source/transmitter and the receiver/display are properly connected and are working. Test the HDMI cables directly from a source to display and ensure their operation. -
Page 15: After-Sales Service
Remarks: For any questions or problems, please try to get help from your local distributor. 1. Limited warranty in respect of Alfatron Products Only 1.1 This limited warranty covers defects in materials and workmanship in this product. 1.2 Should warranty service be required, proof of purchase must be presented to the Company. - Page 16 maintenance, misuse, abuse, accident, neglect, exposure to excess moisture, fire, improper packing and shipping (such claims must be presented to the carrier), lightning, power surges, or other acts of nature. This limited warranty does not cover any damage, deterioration or malfunction resulting from the installation or removal of this product from any installation, any unauthorized tampering with this product, any repairs attempted by anyone unauthorized by the Company to make such repairs, or any other cause which does not relate directly to a defect in materials and/or workmanship of this product.
- Page 17 1.10.3 Issue a refund of the original purchase price less depreciation to be determined based on the age of the product at the time remedy is sought under this limited warranty. 1.11 The Company is not obligated to provide the Customer with a substitute unit during the limited warranty period or at any time thereafter.
