Boss Audio Systems MR1525UI User Manual page 7

4. WIRING DIAGRAM (BUILT-IN ISO)
ISO
CONNECTOR
RCA-TO-RCA CABLE
(not supplied)
AMP
iPod
7 8 7
5 6 5
3 4 3
1
1 2
Figure 2
ISO CONNECTOR WIRING CHART
PIN WIRE COLOR
YELLOW
A4
A5
BLUE
RED
A7
A8 BLACK
VIOLET
B1
B2 VIOLET/BLACK
B3 GREY
B4 GREY/BLACK
B5 WHITE
B6 WHITE/BLACK
B7 GREEN
B8 GREEN/BLACK
WHITE
FRONT LINE OUT
BLACK
RED
WHITE
iPod READY CABLE
8
6
4
2
FUNCTION/LABEL
BATTERY(+)
POWER ANTENNA
IGNITION(ACC)
GROUND
RIGHT REAR SPEAKER (+)
RIGHT REAR SPEAKER (-)
RIGHT FRONT SPEAKER (+)
RIGHT FRONT SPEAKER (-)
LEFT FRONT SPEAKER (+)
LEFT FRONT SPEAKER (-)
LEFT REAR SPEAKER (+)
LEFT REAR SPEAKER (-)
6
ANTENNA
JACK
L
R
REAR
ANTENNA
EXTENDER
CABLE
